Description
Luminys N5D-8LA2 8MP (4K) Outdoor Dome IP Security Camera with 2.8mm Fixed Lens
The Luminys N5D-8LA2 combines professional 8MP (4K) resolution with innovative LumiLuxSmart dual illumination technology in a compact dome design. This advanced security camera features IR and white-light LEDs that automatically switch based on motion detection, providing optimal lighting while preventing unnecessary light pollution.
Enhanced with LumiTracking-E technology for electronic tracking of people and vehicles, this camera delivers intelligent surveillance capabilities. The comprehensive analytics suite includes face detection, people counting, heat map analysis, and queue management for advanced business intelligence and security monitoring.
Designed for demanding environments, this dome camera features IP67/IK10 ratings and operates in extreme temperatures from -40°F to 140°F. The built-in microphone and speaker enable two-way audio communication, while LumiPower technology supports extended PoE transmission distances.
Key Features:
- 8MP (3840 × 2160) maximum resolution with progressive CMOS sensor
- LumiLuxSmart technology with motion-activated IR and white-light switching
- 2.8mm fixed lens providing 110° horizontal field of view
- LumiTracking-E for advanced electronic tracking of moving targets
- Comprehensive LumiAnalytics including face detection and people counting
- Two-way audio with built-in microphone and speaker
- IP67/IK10 weatherproof and vandal-resistant design
- NDAA compliant for government and enterprise applications
Downloads
Additional Information
|
Alarm Input:
|
1 Channel
|
|
Alarm Output:
|
1 Channel
|
|
Aperture:
|
F1.4
|
|
Audio Capability:
|
Two-Way Audio
|
|
Audio Compression:
|
G.711a
G.711Mu
PCM
|
|
Audio Input:
|
1x RCA
|
|
Audio Output:
|
1x RCA
|
|
Audio Support:
|
Built-in Microphone
Built-in Speaker
|
|
Camera Style:
|
Dome
|
|
Certifications:
|
FCC
IC
|
|
Compliance:
|
NDAA Compliant
|
|
Compression:
|
Smart H.264 Plus
Smart H.265 Plus
H.264
H.265
MJPEG
|
|
Dimensions:
|
5.0x4.0x4.0in
|
|
Durability:
|
Vandal Proof
Waterproof
|
|
Environmental:
|
Outdoor
|
|
Lens Size:
|
2.8mm
|
|
Lens Type:
|
Fixed
|
|
Material:
|
Metal
|
|
Max Power Consumption:
|
9.8 Watts
|
|
Noise Reduction:
|
3D DNR
|
|
Power Supply:
|
12 VDC
PoE
|
|
Protection Code:
|
IK10
IP67
|
|
Resolution:
|
8MP (4K)
|
|
S/N Ratio:
|
>50 dB
|
|
Sensor Size:
|
1/1.8"
|
|
Sensor Type:
|
CMOS
|
|
Technology:
|
Network (IP)
|
|
Wide Dynamic Range (WDR):
|
True WDR 120dB
|
