Description
Luminys N5T-4CA2 4MP LumiColor IP Turret Camera
The Luminys N5T-4CA2 delivers exceptional 4MP surveillance performance with advanced LumiColor technology for full-color imaging in complete darkness. This professional-grade turret camera features a 2.8mm fixed lens providing 110° horizontal field of view, making it ideal for comprehensive area monitoring.
Built with a 1/1.8" progressive CMOS sensor, this camera captures crystal-clear 2688 × 1520 resolution video at 30 fps with remarkable low-light performance down to 0.0005 Lux. The integrated white-light LEDs extend night vision capabilities up to 98 feet, ensuring vibrant color footage even in total darkness.
Advanced Video Content Analytics+ includes line crossing detection, intrusion detection, loitering detection, and parking detection. The camera supports LumiSearch for intelligent target tracking and LumiAnalytics for comprehensive behavioral analysis including face detection, people counting, and heat mapping.
Key Features:
- 4MP resolution with 2688 × 1520 maximum recording quality
- LumiColor technology for full-color night vision at 0 lux
- 2.8mm fixed lens with 110° horizontal field of view
- White-light LEDs with 98-foot illumination range
- IP67 weatherproof rating for outdoor installations
- Wide Dynamic Range (130dB) for challenging lighting conditions
- Smart Video Analytics+ with AI-powered detection features
- Multiple compression formats: H.265+, H.265, H.264+, H.264
- PoE and DC12V power options for flexible installation
- NDAA compliant for government and enterprise use
Downloads
Additional Information
|
Analytics:
|
Video Content Analytics+
|
|
Aperture:
|
F1.0
|
|
Audio Input:
|
Built-in Microphone
|
|
Camera Style:
|
Turret
|
|
Compliance:
|
NDAA Compliant
|
|
Compression:
|
H.264
H.264 Plus
H.265
H.265 Plus
MJPEG
|
|
Dimensions:
|
4.4in x 4.8in
|
|
Environmental:
|
Outdoor
|
|
Field of View (Diagonal):
|
130°
|
|
Field of View (Horizontal):
|
110°
|
|
Field of View (Vertical):
|
59°
|
|
Lens Size:
|
2.8mm
|
|
Material:
|
Metal
|
|
Max Power Consumption:
|
9.8W
|
|
Max. FPS and Resolution:
|
30fps at 4MP
|
|
Minimum Illumination (Color):
|
0.0005 Lux
|
|
Night Vision Range (ft):
|
98ft
|
|
Noise Reduction:
|
3D NR
|
|
Protection Code:
|
IP67
|
|
Resolution:
|
4MP
|
|
S/N Ratio:
|
>56dB
|
|
SD Card Support:
|
512GB
|
|
Sensor Size:
|
1/1.8"
|
|
Sensor Type:
|
CMOS
|
|
Shutter Speed:
|
1/3-1/100000s
|
|
Specialized Camera Feature:
|
LumiColor White-Light LEDs
|
|
Storage Temperature:
|
-40°F to 140°F
|
|
Technology:
|
Network (IP)
|
|
Wide Dynamic Range (WDR):
|
WDR 130dB
|
