Description
Mobotix 6MP Indoor Fisheye IP Security Camera with Microphone and Speaker - MX-c26B-AU-6D036
The C26B Indoor 360° is the smallest and lightest MOBOTIX hemispheric complete video system for ceiling installation indoors. Its features include a light-sensitive 6MP day or night sensor and MxAnalytics video analysis tools, which can be used for depicting customer movements in sales rooms, for instance. With the MxIOBoard-IC available as an accessory, the camera receives an additional MxBus connection, two inputs and two 12V outputs.
Key Features:
- IP indoor camera for ceiling mounting
- ONVIF-compliant Mx6 system platform (2nd generation) with H.264, MxPEG+ and M-JPEG
- 6 Megapixel Moonlight Sensor, color (day)
- Ultra wide lens B036 (focal length 3.6 mm, f/1.8, 103° x 77°)
- Max. image size: 6MP (3072 x 2048)
- IP20, 0 to 40°C (32 to 104°F)
- 4 GB microSD
- HD Audio with integrated microphone and speaker
- Temperature sensor, illumination sensor, movement sensor, MxActivitySensor, MxAnalytics (incl. behavioral detection), shock detector
- 0.5 m/1.6 ft Ethernet patch cable
- Interfaces: Ethernet 10/100 (RJ45), MxBus (via Mx-A-IOA-IC), USB, slot for MxIOBoard-IC (Mx-A-IOA-IC)
- Color: white
Downloads
Datasheet
Mobotix-MX-c26B-AU-6D036-Datasheet-A1
Additional Information
|
Aperture:
|
F1.8
|
|
Audio Support:
|
Built-in Microphone
Built-in Speaker
|
|
Camera Style:
|
Fisheye
|
|
Color:
|
White
|
|
Compatible Integration (API):
|
ONVIF Profile S
|
|
Compliance:
|
NDAA Compliant
|
|
Compression:
|
H.264
MJPEG
MxPEG
|
|
Day/Night:
|
Day (Color)
|
|
Environmental:
|
Indoor
|
|
Field of View (Horizontal):
|
103
|
|
Internal Storage:
|
4 GB
|
|
Iris:
|
Fixed Iris
|
|
Languages:
|
English
|
|
Lens Angle Type:
|
Ultra Wide Lens
Panoramic
|
|
Lens Type:
|
Fixed Lens
|
|
Max Power Consumption:
|
5 Watts
|
|
Mounting:
|
Ceiling Mount
Wall Mount
|
|
Network Interface:
|
1x RJ45 100 M self-adaptive Ethernet interface
|
|
Processor (CPU):
|
i.MX 6 Dual Core incl. GPU
|
|
Product Series:
|
Mobotix C26 Series
|
|
Protection Code:
|
IP20
IK06
|
|
RAM:
|
1GB
|
|
Resolution:
|
6MP
|
|
SD Card Support:
|
SD Card Supported
|
|
Sensor Size:
|
1/1.8"
|
|
Sensor Type:
|
CMOS
|
|
Technology:
|
Network (IP)
|
|
Warranty:
|
3-year Manufacturer Warranty
|
