Mobotix MX-BFM-MX-N51-F1.8 BlockFlexMount Sensor Module 5MP - 1/2.5 CMOS, Night, Integrated microphone and status LEDs

Brand: Mobotix
Part Number: MX-BFM-MX-N51-F1.8
Write a Review
Check other similar products:
Technical Support Technical Support
2 Year Warranty 2 Year Warranty
  • Lens Type : Fixed Lens


Mobotix MX-BFM-MX-N51-F1.8 BlockFlexMount Sensor Module for Mobotix MX-BFM-MX-N51-F1.8

The installation options have been expanded further with the new BlockFlexMount sensor modules. Because the image sensor (color or B/W) and lens (from telephoto to Hemispheric plus CSVario) is integrated in a robust aluminum block with prepared mounting holes and surfaces suitable for simple mounting, the concealed mounting of a MOBOTIX HiRes camera can be carried out quickly and easily in devices such as ATMs, machines for function and production monitoring, or very discreetly in paneling, columns etc.

  • For S15D
  • Enhanced S15D system solution based on the latest MOBOTIX technology (5 MP, MxLEO etc.)
  • Mixed operation with the BlockFlexMount and standard sensor module possible
  • Protection class IP30 (protected against access with a tool);
  • Ambient temperature range: 0°C to +50°C/32°F to 122°F

Key features:

  • Suitable for: S15
  • Image sensor: 1/2.5“ CMOS, 5 megapixels (2592 x 1944)
  • Integrated microphone and status LEDs
  • Camera connection via MOBOTIX sensor cable


Additional Information

Accessory Type:
Sensor Module
Lens Type:
Fixed Lens
2-year Manufacturer Warranty
