Description
Mobotix Mx-v26B-6D v26B Indoor Dome Camera Body with 6MP Day Sensor
The dome camera, which is available in black or white, can be fitted with six different MOBOTIX HD premium lenses with fields of view of 103° to 15°. An on-wall set with an integrated microphone and speaker is optionally available, as is a vandalism set for increased camera protection featuring a stainless steel ring and reinforced dome. With the MxIOBoard-IC available as an accessory, the camera receives an additional MxBus connection, two inputs and two 12V outputs.
Key Features:
- v26B camera module (body) with image sensor and lens mount
- Lens to be ordered individually (B036 to B237, focal length 3.6 to 23.7 mm, f/1.8)
- Manually adjustable lens tilt angle 0° to -90°
- ONVIF-compliant Mx6 system platform (2nd generation) with H.264, MxPEG+ and M-JPEG
- 6 Megapixel Moonlight Sensor, color (day)
- Max. image size: 6MP (3072 x 2048)
- IP20, 0 to 40°C (32 to 104°F)
- Lens cover with sealing ring (polycarbonate, 1.5 mm)
- Internal DVR: 4 GB microSD
- Temperature sensor, illumination sensor, movement sensor, MxActivitySensor, MxAnalytics, shock detector
- Ethernet patch cable 0.5 m/1.6ft
- Interfaces: Ethernet 10/100 (RJ45), MxBus (via Mx-A-IO-IC), USB, slot for MxIOBoard-IC (Mx-A-IO-IC)
- Housing color: white
Compatible products
Camera mounts - enclosures are essential to install security cameras. Each surface will require different type of mount and bracket combination. Please check with our sales team if you need help. You can call us at (866) 441-2288 or email us at sales@a1securitycameras.com with any design questions.
Additional Information
|
Audio Support:
|
Built-in Microphone
Built-in Speaker
|
|
Camera Style:
|
Dome
|
|
Color:
|
White
|
|
Compression:
|
MxPEG
MJPEG
H.264
|
|
Day/Night:
|
Day (Color)
Night (B/W)
|
|
Digital Zoom:
|
8
|
|
Durability:
|
Vandal Proof
|
|
Environmental:
|
Indoor
|
|
Internal Storage:
|
4 GB
|
|
LED Indicator:
|
|
|
Languages:
|
English
|
|
Lens Size:
|
No Lens
|
|
Lens Type:
|
No Lens
|
|
Max Power Consumption:
|
5 Watts
|
|
Mounting:
|
Ceiling Mount
|
|
NDAA Compliance:
|
NDAA Compliant
|
|
Power Supply:
|
PoE (IEEE 802.3af)
|
|
Processor (CPU):
|
i.MX 6 Dual Core incl. GPU
|
|
Protection Code:
|
IP20
IK10
|
|
RAM:
|
1GB
|
|
Resolution:
|
6MP
|
|
SD Card Support:
|
SD Card Supported
|
|
Sensor Size:
|
1/1.8"
|
|
Sensor Type:
|
CMOS
|
|
Technology:
|
Network (IP)
|
|
Warranty:
|
3-year Manufacturer Warranty
|
