Pelco IXP23 2MP H.265 Indoor Box IP Security Camera, No Lens included

Brand: Pelco
Part Number: IXP23
Write a Review
  • Pelco IXP23 2MP H.265 Indoor Box IP Security Camera, No Lens included
  • Pelco IXP23 2MP H.265 Indoor Box IP Security Camera, No Lens included
  • Pelco IXP23 2MP H.265 Indoor Box IP Security Camera, No Lens included

Help me pick a security camera

Free shipping over $300 Free Shipping
Technical Support Technical Support
3 Year Warranty 3 Year Warranty
  • Compression : H.265, H.264, MJPEG,
  • Max. FPS and Resolution : 30fps at 1080P
  • Lens Type : No Lens
  • Lens Size : No Lens Lens
  • Sensor Type : CMOS
  • Sensor Size : 1/2.8" Sensor
  • Max. Storage Capacity : 2 TB Storage Capacity
  • Color : Black
  • Material : Aluminum
  • Environmental : Indoor
  • Sensor Size : 1/2.8"
  • Aperture : F1.3


Pelco IXP23 2MP H.265 Indoor Box IP Security Camera, No Lens included

Powerful, versatile, and affordable, the Sarix ® Professional (P) range cameras pack the most popular features and functionality of Sarix technology into a wide range of indoor and outdoor options, including bullet cameras and domes. There is also a vandal resistant wedge camera and a box camera. Mix and match the performance options and form factor you need for almost any lighting condition, environment, and application.

Key Features:

  • H.265, H.264 Main, High, MJPEG video encoding
  • Up to 5 megapixel (MP) resolution at 30 frames per second
  • Up to 60 images per second (ips) at 4 MP for 5MP cameras
  • Micro SDHC & SDXC 2TB addressable, 128 GB testable
  • Pelco Pro Analytics Suite including Adaptive Motion, Object Counting, Motion Detection, Camera Sabotage
  • Operating temperature from –10° to 55°C (14° to 131°F)
  • 24 VAC, 12 VDC, IEEE802.3af Power over Ethernet (PoE)
  • Pelco Smart Compression Technology
  • Choice of standard CS megapixel lenses
  • Compatible with Pelco and third-party video management systems
  • ONVIF Profile S, Profile G, Profile Q, and Profile T conformant
  • Full 3-year warranty and support

Within the Sarix Professional Range, the IXP Series Box Cameras are compatible with a choice of standard CS mount megapixel lenses for wide angle or long range surveillance needs. The box cameras feature an auto back focus mechanism to accommodate this range of lenses and to ensure that the camera automatically stays in perfect focus. The Sarix IXP Series features advanced color science and true WDR for increased visibility in difficult lighting situations.


Sarix Professional provides options for three simultaneous video streams. The three streams can be compressed with efficient H.265, H.264 High or Main profiles, or MJPEG formats. The streams can be configured to a variety of frame rates and variable bit rates to optimize image quality with bandwidth and storage efficiency. Pelco Smart Compression is available on both H.264 and H.265, minimizing storage and bandwidth utilization.

Edge Storage

Sarix Professional range cameras feature onboard edge storage with a micro SDHC/SDXC card. Video clips of varying lengths can be stored to the card upon alarm, or video can be written continuously to the SD card in the case of network outage. Video can be retrieved from the card through the FTP protocol or by using an ONVIF Profile G compliant client.

Open and Integrated

Sarix Professional range cameras seamlessly connect to Pelco video management systems such as VideoXpert ™ , VXToolbox, Endura ® version 2.0 (or later), and Digital Sentry ® version 7.3 (or later). Sarix Professional range cameras integrate with major third-party systems through the open Pelco API or the ONVIF Profile S, Profile G, Profile Q, and Profile T standards.

Standard Web Interface

Pelco cameras use a standard Web browser interface for easy remote setup and administration. Controls are optimized for convenient one-step camera configuration for features including color, exposure, flicker control, backlight compensation, and streaming.

Additional Information

Audio Capability:
Two-way Audio
Audio Compression:
G.711alaw G.711ulaw
Audio Input:
1x Channel
Audio Output:
1x Channel
Camera Style:
Compatible Integration (API):
ONVIF Profile S ONVIF Profile G ONVIF Profile Q ONVIF Profile T
H.265 H.264 MJPEG
ICR (True Day/Night)
Auto (DC-iris)
English Turkish Italian
Lens Size:
No Lens
Lens Type:
No Lens
Max. FPS and Resolution:
30fps at 1080P
Max. Storage Capacity:
2 TB
Mobile Apps:
Pelco Mobile
Operating Temperature:
-10 °C to 55 °C (14 °F to 131 °F)
Power Supply:
24 VAC 12 VDC PoE (IEEE 802.3af)
Product Series:
Sarix Professional IXP Series
S/N Ratio:
>50 dB
SD Card Support:
Sensor Size:
Sensor Type:
Special Technologies:
Pelco Pro Analytics Suite
Network (IP)
3-year Manufacturer Warranty
Web Browser:
Internet Explorer Chrome Firefox
Wide Dynamic Range (WDR):
True WDR 120dB
