Ubiquiti UAP-BeaconHD-US Wireless Range Extender

Brand:
Part Number: UAP-BeaconHD-US
Write a Review
Call for availability!
  • Ubiquiti UAP-BeaconHD-US Wireless Range Extender
  • Ubiquiti UAP-BeaconHD-US Wireless Range Extender
  • Ubiquiti UAP-BeaconHD-US Wireless Range Extender
  • Ubiquiti UAP-BeaconHD-US Wireless Range Extender
  • Ubiquiti UAP-BeaconHD-US Wireless Range Extender
  • Ubiquiti UAP-BeaconHD-US Wireless Range Extender
  • Ubiquiti UAP-BeaconHD-US Wireless Range Extender
  • Ubiquiti UAP-BeaconHD-US Wireless Range Extender
$134.99
OR
Fast Shipping Fast Shipping
Technical Support Technical Support

Description

Ubiquiti UAP-BeaconHD-US Wireless Range Extender

The UniFi AP BeaconHD is the fastest way to extend Wi-Fi coverage and increase throughput in your home and office. The sleek design integrates easily into any environment and plugs in to a standard US wall outlet. Compared to a standard Wi-Fi device, the powerful BeaconHD uplink results in more than 4x larger Wi-Fi coverage range in an open space.

Key Features:

  • 802.11ac Wave 2, 4x4 MU-MIMO technology
  • 300+ Mbps performance over a wireless mesh hop
  • Works with UniFi AP or Dream Machine
  • Automatically discovered for adoption by UniFi Network Controller
  • The Fastest Way to Extend Wi-Fi Coverage and Increase Throughput
  • High-Capacity Mesh Uplink
  • Bi-directional uplink to nearby UniFi AP
  • 5 GHz radio rate of up to 1.733 Gbps
  • Enhanced Signal Levels
  • Improves radio data rates for nearby Wi-Fi devices

UniFi HD Family

UniFi® nanoHD
UAP-nanoHD
UniFi® AP HD
UAP-HD
UniFi® AP SHD
UAP-SHD
UAP-FlexHD
UAP-BeaconHD
Use Case For high-density environments with numerous clients but a smaller space, like a theatre for example. Smaller size and availability of different skins make it blend into the environment. For high-density environments, such as a concert venue or outdoor fair, we recommend the UniFi AP HD. Secure, high-density deployments where user data safety must be actively monitored: banks, hospitals, universities, or corporate environments to name a few. For high-density environments with numerous clients. Its compact and sleek design along with its numerous installation options allows placement near users where it is needed. For high-density environments with numerous clients, where infrastructure demands more coverage, with flexible network-expanding options. The easy plug and adopt installation, makes this stylish UAP the right choice for modern offices and homes that need a little more flexible coverage.
Dimensions
∅ 160 x 32.65 mm
∅220 x 48.1 mm ∅220 x 48.1 mm Ø 48.50 x 159.49 mm 169.7 x 112.15 x 32.2 mm
Environment Indoor Indoor/Outdoor Indoor/Outdoor Indoor/Outdoor Indoor
2.4 GHz Radio Rate 300 Mbps 800 Mbps 800 Mbps 300 Mbps 300 Mbps
5 GHz Radio Rate 1733 Mbps 1733 Mbps 1733 Mbps 1733 Mbps 1733 Mbps
PoE Mode
802.3af PoE
802.3at PoE+ 802.3at PoE+ 802.3af PoE NA
Power Supply UniFi Switch (PoE) UniFi Switch (PoE) UniFi Switch (PoE) 802.3af 48V, 0.32A Gigabit PoE Adapter AC (standard US power outlet)
Ports
(1) 10/100/1000 Ethernet
(2) 10/100/1000 Ethernet (2) 10/100/1000 Ethernet (1) 10/100/1000 Ethernet Port  None
Wi‑Fi Client Associations 200+ 1000+ 1000+ 200+ 200+
View AllClose

Specifications

Dimensions169.7 x 112.15 x 32.2 mm (6.68 x 4.42 x 1.27")
Weight260 g (9.17 oz)
Networking InterfacesWi-Fi
ButtonsReset
LEDSystem Status
Processor880 MHz MIPS 1004KEc
System Memory128 MB SDRAM
Maximum Power Consumption11.5W
Supported Voltage Range100 - 240VAC, 0.3A Max., 50/60 Hz
Power MethodAC
Power SupplyAC
Power SaveSupported
BeamformingSupported
Operating Frequency2.4 GHz
5 GHz
TX Power* (EIRP)
2.4 GHz
5 GHz

24.8 dBm
30 dBm
Wi-Fi Standards802.11 a/b/g/n/ac/ac-wave2
Wireless SecurityWEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES), 802.11w/PMF
BSSIDUp to 8 per Radio
Operating Temperature-10 to 60° C (14 to 140° F)
Operating Humidity5 to 95% Noncondensing
CertificationsCE, FCC, IC
ANTENNA GAIN OF 4 SINGLE-POLARITY ANTENNAS
(2) Dual-Band2.4 GHz — 4.5 dBi
5 GHz — 5 dBi
(2) Single-Band5 GHz — 5 dBi
ADVANCED TRAFFIC MANAGEMENT
VLAN802.1Q
Advanced QoSPer-User Rate Limiting
Guest Traffic IsolationSupported
WMMVoice, Video, Best Effort, and Background
SUPPORTED DATA RATES (MBPS)
802.11a6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
802.11ac Wave 26.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80)
58 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 160)
802.11b1, 2, 5.5, 11 Mbps
802.11g6, 9, 12, 18, 24, 36, 48, 54 Mbps
