Ubiquiti US-16-XG UniFI 10G 16-Port Managed Aggregation Switch

Ubiquiti US-16-XG UniFI 10G 16-Port Managed Aggregation Switch

10G Aggregation Switch for Enterprise Networks: Build and expand your network with Ubiquiti Networks® UniFi® Switch 16 XG, part of the UniFi Enterprise System. The US‑16‑XG is a fully managed, 16-port, 10G fiber switch that enhances network capacity by providing high-bandwidth aggregation connectivity to multiple switches in your network. The US‑16‑XG offers an extensive suite of advanced Layer-2 switching features and protocols.

Switching Performance: The US‑16‑XG offers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss. The total non-blocking throughput is up to 160 Gbps.

10G High-Capacity Links: The US‑16‑XG offers maximum performance and low latency as an aggregation switch. For fiber connectivity, it features 12 SFP+ ports. For copper connectivity, the US‑16‑XG offers four RJ45 ports that support 10GBASE-T, the standard for 10 Gbps connections using Cat6 (or higher) cabling and RJ45 connectors.

UniFi Controller: Designed for convenient management, the UniFi Controller software allows admins to configure and monitor the UniFi Switch and other UniFi devices using a graphical user interface.

Multi-Site Management: A single instance of the UniFi Controller running in the cloud can manage multiple UniFi sites within a centralized interface. Each site is logically separated and has its own network monitoring, configuration, maps, statistics, and admin accounts.

Key Features:

• (12) 1G/10G SFP+ Ports
• (4) 1G/10G RJ45 Ports
• (1) RJ45 Serial Console Port
• Non-Blocking Throughput: 160 Gbps
• Switching Capacity: 320 Gbps
• Forwarding Rate: 238.10 Mpps
• Rack Mountable with Mount Brackets (Included)
• DC Input Option (Redundant or Stand-Alone)

Switch Configuration: You can access any managed UniFi Switch through the UniFi Controller to configure a variety of features:

• Operation mode (switching, mirroring, or aggregate) per port
• Network/VLAN configuration
• Jumbo frame and flow control services
• Network settings
• Storm control setting per port • Spanning tree configuration
• 802.1x control and RADIUS VLAN
• Debug terminal option for command-line interface Switch Port Status You can also view status information for each port:
• Connection speed and duplex mode
• TX/RX data rates
• Network/VLAN setting

The US‑16‑XG connects to the following:

• Multiple UniFi Switches and a 1G/10G router via SFP+ ports
• VM, Server, NAS, or other network devices via 1G/10G RJ45 ports
