Vivotek AW-IHH-0410 Industrial 2xGE 95W PoH/PoE + 2xGE SFP Switch

Vivotek AW-IHH-0410 Industrial 2xGE 95W PoH/PoE + 2xGE SFP Switch

Key Features:

• Gigabit Ethernet 10/100/1000Mbps (RJ45): 2
• Gigabit Ethernet 100/1000Mbps (SFP): 2
• IEEE 802.3 10-BASE-T (Ethernet):Supported
• IEEE 802.3u 100-BASE-TX (Fast Ethernet): Supported
• IEEE 802.3ab 1000-BASE-T (Gigabit Ethernet): Supported
• IEEE 802.3af/at Power over Ethernet: Supported
• 10Base T: Cat. 3, 4, 5 UTP/STP
• 100Base TX: Cat. 5, 5e UTP/STP
• 1000Base T: Cat. 5e,6,7 UTP/STP
• Number of PoE Out Ports: 2
• Max. PoE Output Power/Per Port: 54VDC/95W
• Over Current Protection: Supported
• Circuit Shorting Protection: Supported
• Total PoE Power Budget: 190W
• Power Pin Assignment: 1/2(-), 3/6(+), 4/5(+), 7/8(-)
• PoE PD Auto Detection: Supported
• Power Input: 48~56VDC for 30W 802.3 af/at, 52~56VDC for 95W PoH/PoE
• Power Consumption: 195W
• Surge Protection/Per PoE Port: 12KV
• Mounting: DIN Rail, Wall Mount
• Dimensions: 120 (L) x 87 (W) x 33 (H) mm
• Weight: 0.3 kg
• Certifications: CE, FCC, LVD EN62368-1, VCCI
• Operating Temperature: -40°C ~ 75°C (-40°F ~ 167°F)
• Storage Temperature: -40°C ~ 85°C (-40°F ~ 185°F)
• Operating Humidity: 10~90% non-condensing
• Warranty: 24 months
