Vivotek CC9381-HV-V2 5MP Outdoor Compact Panoramic IP Security Camera with 1.47mm Lens and Built-In IR

Brand: Vivotek
Part Number: CC9381-HV-V2
Write a Review
New Product!
Top Deals
Deal Ends: 09/30
$800.00
$502.43
— You save $297.57

? Help me pick a security camera

Free shipping over $300 Free Shipping
Technical Support Technical Support
  • Lens Type : Fixed Lens
  • Lens Size : 1.47mm Lens
  • Sensor Type : CMOS
  • Sensor Size : 1/2.8" Sensor
  • Protection Code : IP66 IK10
  • Aperture : F2.7

Description

Vivotek CC9381-HV-V2 5MP Outdoor Compact Panoramic IP Security Camera with 1.47mm Lens and Built-In IR

Experience comprehensive 180-degree surveillance with the Vivotek CC9381-HV-V2 compact panoramic camera. This innovative 5MP camera delivers wide-area coverage through its ultra-wide panoramic lens, making it perfect for monitoring corridors, retail spaces, and areas requiring extensive field of view with minimal camera installations.

The specialized 1.47mm fixed lens provides true 180-degree horizontal coverage, eliminating blind spots and reducing the number of cameras needed for comprehensive area monitoring. Built-in IR illuminators extend surveillance capabilities up to 20 meters, ensuring effective nighttime monitoring across the entire panoramic view.

Enhanced with AI-powered analytics and WDR Pro technology, this compact camera delivers intelligent surveillance capabilities including object detection, intrusion analysis, and crowd monitoring. The robust IP66/IK10 construction and compact form factor make it ideal for discreet installation in demanding outdoor environments.

Key Features:

  • 5MP panoramic resolution with 180-degree field of view; provides comprehensive wide-area coverage with minimal blind spots
  • Ultra-compact design with 1.47mm specialized lens; enables discreet installation while maximizing surveillance coverage
  • Built-in IR illuminators effective up to 20 meters; ensures complete panoramic night vision across the entire field of view
  • AI-powered analytics with object detection; delivers intelligent event recognition and attribute analysis
  • WDR Pro technology with 120dB dynamic range; handles challenging lighting conditions for optimal image quality
  • Compact form factor with professional durability; combines space-saving design with IP66/IK10 protection ratings
  • Advanced video compression and Smart Stream; optimizes bandwidth usage while maintaining high-quality panoramic footage
  • Flexible mounting options with tilt adjustment; enables precise positioning for optimal panoramic coverage
Replacement of: CC9381-HV

Downloads

Additional Information

Aperture:
F2.7
Camera Style:
Panoramic
Day/Night:
Dimensions:
6.30x2.36x2.83in
Lens Size:
1.47mm
Lens Type:
Fixed Lens
Max Power Consumption:
10.26 Watts
Night Vision Range (ft):
66
Operating Humidity:
0% to 98% RH (non-condensing)
Operating Temperature:
-30 °C to 60 °C (-22 °F to 140 °F)
Power Supply:
PoE (IEEE 802.3af)
Protection Code:
IP66 IK10
Resolution:
5MP (3K)
SD Card Support:
Sensor Size:
1/2.8"
Sensor Type:
CMOS
Technology:
Network (IP)
Wide Dynamic Range (WDR):
