Vivotek ND8301 8CH Full HD RAID Network Video Recorder
Upgrade to a more sophisticated video recording with the Vivotek ND8301 8CH Full HD RAID Network Video Recorder. This network video recorder from Vivotek is the ideal solution to have a more reliable storage of recorded videos that operate independently from a PC or other operation system. With this 8-channel network video recorder, you can simultaneously record, monitor, and manage video data through a network with ease. Designed with a brilliant Dual-Core Intel Atom Processor, it is capable of delivering maximum recording up to 96 Mbps. Its RAID 0, 1, Storage Solution even allows you to protect valuable digital data when there is a hard drive failure. The 2 Bay Hot-swap HDD Tray, on the other hand, lets you install two 3.5″ hard disk drives and secure as much as 6 TB of storage. Plus, it comes with an external eSATA interface so that you can easily connect other storage devices.

For a high-efficiency surveillance system, get the Vivotek ND8301 8CH Full HD RAID Network Video Recorder.

Key Features of the Vivotek ND8301 8CH Full HD RAID Network Video Recorder

  • 8 Channels: allows live view from 8 security cameras
  • No HDD included
  • Dual-Core Intel Atom Processor: offers maximum recording throughput up to 96 Mbps
  • RAID 0, 1 Storage Solution: keeps copies of data on one or more additional hard drives to prevent data loss or system downtime
  • 2 Bay Hot-swap HDD Tray: supports storage of up to 6 TB
  • External eSATA Interface: provides seamless connection to external storage devices

vivotek nd8301 8ch full hd raid network video recorder

vivotek nd8301 8ch full hd raid network video recorder>

This product is also associated with:


Product Type:
2-year Manufacturer Warranty

Video Recorder Features

4K Support:
Recorder Technology:
Network Video Recorder (NVR)
Number of camera channels:
  • 8 camera channels
Video Output:
  • No video output
ePoE Technology :
Hard Drive Ports:
2 SATA Ports
Pre-Installed Storage (Recorders):
No HDD included
Technical Specs

Vivotek ND8301 8CH Full HD RAID NVR Specifications

  • CPU: Dual-core Intel processor
  • OS: Windows 7 embedded
  • Channels: 8-CH selectable
  • Storage: 2 x 3.5" HDD, up to 6 TB, 2 x hot-swappable hard disk tray, HDD S.M.A.R.T.(Self-Monitoring Analysis and Reporting Technology), RAID 0, 1, External eSATA storage
  • Connectors: 1 x VGA for Full HD local display, 2 x Gigabit RJ45 Ethernet port, 4 x USB 2.0 port, 1 x RS232, 1 x eSATA, 1 x MIC in and line in, 1 x line out
  • Camera Compatibility: Full integration with VIVOTEK network cameras, Integration with ONVIF network cameras (by project), Setup Wizard for network/HDD/camera easy setup, IW2 for search internal camera, Shepherd for duplicating the camera's configuration to multiple cameras
  • Throughput: Max. 96 Mbps
  • Recording policy: scheduled (event/continuous modes) and manual recording
  • Video compression -H.264/MJPEG/MPEG-4
  • Audio compression -AMR/G.711/AAC
  • Resolution: Up to 5-Megapixel recording
  • Format: 3GP
  • Auto recycling: buffer size setting, time setting
  • Activity adaptive recording: Yes
  • Format: AVI/3GPP/EXE
  • Display layout: 1X1, 2X2, 3X3, 4X4, 1+5, 1+12
  • Rotate: Yes
  • Snapshot: Yes
  • Two way audio control: Yes
  • PiP video control: Yes
  • Stream selectable: Yes
  • Set DO control: Yes
  • Video enhancement: Yes
  • Pan/Tilt/Zoom control of VIVOTEK cameras
  • Preset location: Yes
  • Auto pan/patrol: Yes
  • Event popup windows: Yes
  • Instant event notification: Yes
  • Display performance: MJPEG: 16-CH, 30 fps at CIF, MPEG4: 16-CH, 30 fps at CIF or 2-CH, 30 fps at 1080P, H.264: 7-CH, 30 fps at CIF or 1-CH, 30 fps at 1080P
  • Auto stream size: Yes
  • Local Playback: Display layout: 1X1
  • Playback mode: play, pause, stop, next/frame, next/previous, speed control
  • Search mode: browsing, time, event, bookmark
  • Graphical timeline: Yes
  • Snapshot: Yes
  • Bookmark design: Yes
  • PiP video control: Yes
  • Video enhancement: Yes
  • Log viewer: Yes
  • Remote Liveview: Display layout: 1X1, 2X2, 3X3, 4X4, 1+5, 1+12
  • Actions: email, start recording, move to the preset position, set DO, GSM short message & send CGI command
  • Security: Multi-level user access with password protection, 5 levels of user roles
  • Backup: Manual/scheduled backup
  • Mobile APP Support: VIVOTEK iViewer (iOS/Android)
  • Dimension: 315 mm (W) X 220 mm (D) X 75 mm (H)
  • Weight: Net: 2.27 kg (without HHD)
  • LED Indicator: 1 x power status, 1 x HDD status
  • Input: AC 100-240 V, 50-60 Hz
  • Output: DC 12V 5A (60 W)
  • Power consumption: Max. 31 W
  • Approvals: CE, FCC Class B, VCCI, C-Tick
  • Temperature: 0°C ~ 40°C
  • Humidity: 20%~95% RH
  • Warranty: 24 months
  • Language: English, French, German, Italian, Spanish, Traditional Chinese, Simplified Chinese, Japanese, Portuguese, Czech
  • Included Accessories: CD content: user's manual, quick installation guide, installation wizard 2, LiveClient (remote), Playback (remote)
  • Others: quick installation guide, warranty card, power adaptor, power cord

Manual (nd8301datasheets_en.pdf, 0) [Download]
