AXIS P3277-LVE 5MP Outdoor Dome IP Security Camera with 3.0–8.5mm Lens and Built-In IR - 03153-001
The AXIS P3277-LVE is a robust 5MP outdoor dome IP security camera engineered to deliver sharp video surveillance and advanced AI-powered analytics in challenging environments. Built on the ARTPEC-9 system-on-chip and equipped with a deep learning processing unit, this model enables edge-based applications such as AXIS Object Analytics for real-time detection and classification of people, vehicles, and behavioral patterns. It features a 3.0–8.5 mm varifocal lens with P-Iris and remote zoom, providing a 104°–34° horizontal field of view. OptimizedIR technology supports visibility up to 40 meters in complete darkness, while Forensic WDR and Lightfinder 2.0 ensure excellent image quality under variable lighting conditions. The camera’s rugged design is IP66-, IK10-, and NEMA 4X-rated, making it suitable for exposed outdoor installations. With TAA compliance and full ONVIF support, the P3277-LVE offers secure, interoperable, and privacy-conscious monitoring for public safety, critical infrastructure, and enterprise-grade perimeter security.
Key Features:
- 5MP resolution; delivers crisp 2560x1440 video for detailed monitoring.
- 3.0–8.5 mm varifocal lens; provides wide-angle and focused views with remote zoom/focus.
- Built-in IR with OptimizedIR; supports up to 40 meters of infrared night vision.
- AI-enabled edge analytics; includes AXIS Object Analytics for behavior-based event detection.
- Forensic WDR up to 120 dB; captures clear imagery in scenes with both dark and bright areas.
- Lightfinder 2.0; enhances visibility and color detail in low-light environments.
- ARTPEC-9 SoC with DLPU; supports efficient AI processing directly on the device.
- Weather and vandal resistant; IP66, IK10, and NEMA 4X rated for outdoor durability.
- Axis Edge Vault; hardware-secured boot and encryption protect device integrity and data.
- TAA compliant; meets U.S. federal government acquisition requirements.
- ONVIF Profiles S, G, M, and T; ensures seamless integration with third-party systems.
- Multiple video streams; supports up to 20 configurable streams for various user needs.
- Audio capabilities; includes support for audio input/output and analytics-based sound detection.
- Privacy masking; AXIS Live Privacy Shield enables dynamic masking for real-time compliance.
- Wide operating range; functions in temperatures from -40 °C to 50 °C with high humidity tolerance.
Downloads
Additional Information
Aperture:
|
F1.38
F2.58
|
Camera Style:
|
Dome
|
Compliance:
|
TAA (Trade Agreements Act)
|
Compression:
|
H.264
H.265
MJPEG
|
Day/Night:
|
|
Dimensions:
|
4.2" x 5.86"
|
Environmental:
|
Outdoor
|
Iris:
|
P-iris
|
Lens Size:
|
3~8.5mm
|
Lens Type:
|
Varifocal Lens
|
Power Supply:
|
PoE (IEEE 802.3af)
PoE (IEEE 802.3.at)
|
Protection Code:
|
IP66
IK10
|
Resolution:
|
5MP
|
SD Card Support:
|
SD Card Supported
|
Sensor Size:
|
1/2.8"
|
Sensor Type:
|
CMOS
|
Storage Humidity:
|
5% to 95% RH (non-condensing)
|
Storage Temperature:
|
-40 °C to 65 °C (-40 °F to 149 °F)
|
Technology:
|
Network (IP)
|
Wide Dynamic Range (WDR):
|
True WDR 120dB
|
