Description
AXIS Q3546-LVE 4MP Outdoor Dome IP Security Camera with 13-51mm Lens, 3.8x Optical Zoom and Built-In IR – 02972-001
The AXIS Q3546-LVE is a 4MP outdoor dome IP security camera designed for high-performance surveillance with precision zoom and deep learning-based analytics. Featuring a 51mm varifocal lens with 3.8x optical zoom, it delivers a narrow horizontal field of view from 33° to 9°, making it ideal for long-range detailed monitoring. Built on the ARTPEC-9 chipset, it includes a deep learning processing unit to support edge-based AI functions such as AXIS Object Analytics, Scene Metadata, and Live Privacy Shield. OptimizedIR provides up to 70 meters of infrared illumination, while Forensic WDR and Lightfinder 2.0 ensure visibility in complex lighting conditions. Housed in a rugged IP66/IP69K and IK10-rated dome, it is built for reliable operation in harsh environments.
Key Features:
- 4MP resolution (2688 × 1512); delivers up to 30fps video
- 51mm varifocal lens; provides horizontal field of view from 33° to 9°
- 3.8x optical zoom with P-Iris control, remote focus, and zoom
- OptimizedIR illumination; supports IR range up to 70 meters
- Lightfinder 2.0 and Forensic WDR (up to 120dB); enables excellent performance in low light and high-contrast scenes
- AI analytics; includes AXIS Object Analytics, Scene Metadata, Live Privacy Shield, and Image Health Analytics
- Axis Edge Vault; secure boot, signed video, and encrypted storage ensure robust cybersecurity
- Supports AV1, H.265, H.264, and MJPEG video compression
- Built-in microphone; two-way audio support available
- IP66/IP69K- and IK10-rated housing; NEMA 4X compliant for extreme outdoor environments
- Power via PoE (IEEE 802.3at Type 2); max power consumption 25.5W
- Operating temperature range from -50°C to 55°C
- ONVIF Profiles G, S, T, and M compliant; integrates with major VMS platforms and Axis Camera Station
Downloads
Additional Information
Aperture:
|
F1.7
F2.1
|
Camera Style:
|
Dome
|
Compliance:
|
TAA (Trade Agreements Act)
|
Compression:
|
H.264
H.265
MJPEG
|
Day/Night:
|
|
Dimensions:
|
Ø175 mm × 148 mm (Ø6.9" × 5.7")
|
Durability:
|
Weather Resistant
Vandal Resistant
|
Environmental:
|
Outdoor
|
Iris:
|
P-iris
|
Lens Size:
|
13-51mm
|
Power Supply:
|
Poe (IEEE 802.3at))
8 to 28 VDC
|
Protection Code:
|
IP66
IK10
NEMA 4X
IP6K9K
|
Resolution:
|
4MP
|
SD Card Support:
|
SD Card Supported
|
Sensor Size:
|
1/1.8"
|
Sensor Type:
|
CMOS
|
Storage Humidity:
|
5% to 95% RH (non-condensing)
|
Storage Temperature:
|
-40 °C to 65 °C (-40 °F to 149 °F)
|
Technology:
|
Network (IP)
|
Wide Dynamic Range (WDR):
|
True WDR 120dB
|
