Description
AXIS VB-H47B 1.3MP Indoor PTZ IP Security Camera, 20x Optical Zoom, Black - 5715C002
The Canon VB-H47 Full HD PTZ IP security camera combines a powerful 320x zoom with excellent low-light capability, WDR (Wide Dynamic Range) function and fast auto-focus. The product offers flexible installation options for indoor use.
Key Features:
- Full HD 60 fps video stream and H.265 and H.264 support
- 20x optical with 16x digital zoom and fast autofocus
- Remarkable low-light performance with color at 0.02 lux and mono at 0.003 lux
- Excellent WDR performance
- Two color options: Titanium white and Black
New image sensor and video network engine
Canon's popular network cameras have further evolved with the latest specifications and performance, equipped with a new image sensor and video network engine, while maintaining various functions, compactness, and ease of use.
Replacement of:
2541C001AA
2541C002
Downloads
Datasheet
AXIS-5715C002-Datasheet-A1
Firmware
AXIS-5715C002-Firmware-A1
Installation Guide
AXIS-5715C002-Installation-Guide-A1
Additional Information
|
Alternative SKUs:
|
VB-H47B
VB-H47
|
|
Aperture:
|
F1.6
F3.5
|
|
Audio Compression:
|
G.711ulaw
AAC
|
|
Audio Input:
|
1x 3.5mm
|
|
Audio Output:
|
1x 3.5mm
|
|
Camera Style:
|
PTZ
|
|
Color:
|
Black
|
|
Compatible Integration (API):
|
ONVIF Profile G
ONVIF Profile S
ONVIF Profile T
|
|
Compression:
|
H.264
H.265
JPEG
|
|
Connection Type:
|
Wired
|
|
Day/Night:
|
ICR (True Day/Night)
|
|
Digital Zoom:
|
16
|
|
Environmental:
|
Indoor
|
|
Field of View (Horizontal):
|
62.4
3.3
|
|
Lens Size:
|
4.7~94mm
|
|
Max Power Consumption:
|
9.7 Watts
|
|
Max. FPS and Resolution:
|
60fps at 1920 x 1080
|
|
Minimum Illumination (B/W):
|
0.003 Lux
|
|
Minimum Illumination (Color):
|
0.02 Lux
|
|
Network Interface:
|
1x RJ-45 100Base-TX
|
|
Optical Zoom:
|
20x Optical Zoom
|
|
Power Supply:
|
12 VDC
PoE+ (IEEE802.3at)
|
|
Product Series:
|
AXIS Canon Series
|
|
Remote Users:
|
Up to 30
|
|
Resolution:
|
1.3MP
|
|
SD Card Support:
|
SD Card Supported
|
|
Sensor Size:
|
1/2.8"
|
|
Sensor Type:
|
CMOS
|
|
Technology:
|
Network (IP)
|
