Axton Smart Series IR - 30-degree Coverage 230' Distance x 119' Width, AT16S2830
- Field of View (Horizontal) : 30°Field of View
- Color : Black
- Environmental : Outdoor
- Input Voltage : 36VDC 24VAC
Description
Axton Smart Series IR AT16S2830
The Smart AT-16S Infrared illuminator is built around 850nm high-output SMT LEDs, delivering superior performance and longevity. Besides excellent performance vs. size ratio, the AT-16S also features an automatic day/ night switch, I/O Ports, and extended range Low Voltage power input.
The I/O ports allow for seamless and precise synchronization with a camera, alarm, motion detector, or any other device with an output signal. Designed specifically for outdoor use, the IP-67 rated housing is completely sealed from the elements; it is rugged and vandal-proof.
Manufactured in the USA and covered by a lifetime warranty with advanced replacement.
Key Features:
- I/O Ports for seamless camera synch
- Day/ night switch
- Low Voltage
- Designed and built in the USA
- Lifetime Warranty
Product Group | AT-16S, Smart Series | |||
Wavelength | 850 nm | |||
Angles | 10° | 30° | 60° | 130° |
AT-16S p/n | AT16S2810 | AT16S2830 | AT16S2860 | AT16S28130 |
Range | 340'/103m | 230'/70m | 155'/47m | 85'/ 26m |
Horizontal FOV | 71'/23m | 119'/36m | 141'/43m | 158'/48m |
Input Voltage | (12-36) VDC or (12-24) VAC | |||
Power Consumption | 16 Watts | |||
Operating Temperature | -58°F...+140°F/-50°C...+60°C | |||
Dimensions | 5″ x 4.9″ x 2.5″ / 127 x 125 x 64 mm | |||
Weight | 2 lbs/0.95kg | |||
Environmental | IP67 | |||
Housing | Vandal resistant | |||
Bracket | Adjustable Pan/ Tilt Bracket |
Downloads
Additional Information
Accessory Type: |
Infrared Illuminators
|
Color: |
Black
|
Environmental: |
Outdoor
|
Field of View (Horizontal): |
30
|
Input Voltage: |
36VDC
24VAC
|
Night Vision Range (ft): |
230ft
|
Power Consumption: |
16 Watts
|
Warranty: |
Life-time Warranty
|
Wavelength (nm): |
850
|
