Bosch Autodome 300 VG4-322-ECE0C Outdoor 18x PTZ IP Security Camera

Bosch Autodome 300 VG4-322-ECE0C Outdoor 18x PTZ IP Security Camera

Bosch Autodome 300 VG4-322-ECE0C is among Boschrsquo;s elite line of security cameras. Bosch security cameras boast industry leading quality and performance. Bosch security cameras include exceptional features making them the perfect solution for any video surveillance system. Below are the key features for Bosch VG4-322-ECE0C.

Bosch Autodome 300 VG4-322-ECE0C Main Features:

• •& 1/4" Exview HAD CCD image sensor and 4.1-73.8 mm lens
• •& Resolution of 470TVL
• •& Autoscaling (proportional zoom) and Autopivot features enable the camera to automatically rotate and flip
• •& Can record operator's movements such as PTZ activities which can be played back continuously
• •& Removable IR cut filter to switch between color and B&W as per the changes in ambient lighting
• •& Preset tour feature is capable of handling 99 pre-positions with a configurable dwell time between pre-positions
• •& Customize the order and frequency of each preset
• •& Supports 2 recording tours with up to 15 minutes recording duration
• •& MPEG-4 compression technology and supports 4 CIF resolutions at 30 ips
• •& Innovative CTFID (Configuration Tool for Imaging Devices) for remotely changing the camera's settings as well as update firmware
• •& Camera uses rules-based logic to manage alarms
• •& Inputs and outputs with pre-defined and user-specified keyboard commands can be combined for performing advanced dome functions
• •& Handles 7 alarm inputs including 2 analog inputs that are programmed for EOLR for real-time security applications
• •& Supports 3 outputs wherein 1 relay is rated at 2A, and 3 additional open collectors for driving external devices
• •& Privacy masking is used to mask specific portions of a scene for security reasons
• •& Up to 8 masks can be displayed on the same scene
• •& Each masked area can be programmed with 3, 4, or 5 corners to hide more complex shapes
• •& Optional hybrid/IP configuration allows the camera to simultaneously stream IP video via LAN or WAN and CVBS video via coaxial cabling
• •& IP66-rated outdoor pendant enclosure
• •& Optional XT (Extended Temperature) kit allows the camera to operate in temperatures down to -76°F (-60°C)
• •& Includes a rugged polycarbonate clear bubble for enhanced image clarity
• •& Operates on 24 VAC
• •& Includes a corner mount for easy mounting
• •& Built-in diagnostics ensure easy servicing and minimize downtime
• •& Use the OSD to quickly check the critical parameters such as internal temperature and input voltage level and verify if the dome is functioning within acceptable operating limits
• •& Ethernet communication for standard video and data transmission methods such as TCP/IP
