Dahua N82AL32 8MP IR H.265+ Outdoor Dome IP Security Camera with 2.8mm Fixed Lens, Arctic Pro Series
The Dahua 8 MP Lite Series cameras offer high-resolution video and cutting-edge technology in a compact and accessible package. The cameras feature Smart H.265+ video compression, reducing bandwidth and storage requirements without sacrificing video quality. The camera's elegant blend of aesthetics combined with a range of easy mounting solutions provides an excellent choice for a variety of small to mid-size applications at an affordable price.
Key Features:
- 1/2.7-in. 8 MP Progressive-scan CMOS Sensor
- Dual Stream Encoding
- Smart H. 265+ and Smart H.264+ Dual Codecs
- 8 MP (3840 x 2160) at 15 fps Maximum Resolution
- 2.8 mm Fixed Lens
- Starlight Technology for Low Light Sensitivity
- True WDR (120 dB) and Day/Night (ICR)
- Maximum IR LED Length 30 m (98.43ft) with Smart IR
- Intelligent Video System
- ArcticPro Series Camera – Operational down to –40°
- IP67 Ingress Protection and IK10 Vandal Resistance
- Five-year Warranty (for products sold through an authorized Dahua Dealer)
Starlight Technology
For challenging low-light applications, Dahua’s Basic Starlight Technology offers best-in-class light sensitivity, capturing details in low light down to 0.009 lux. The camera uses a set of optical features to balance light throughout the scene, resulting in clear images in dark environments.
Smart H.265+
Smart H.265+ is the optimized implementation of the H.265 codec that uses a scene-adaptive encoding strategy, dynamic GOP, dynamic ROI, flexible multi-frame reference structure and intelligent noise reduction to deliver high-quality video without straining the network. Smart H.265+ technology reduces bit rate and storage requirements by up to 70% when compared to standard H.265 video compression.
Wide Dynamic Range (WDR)
The camera achieves vivid images, even in the most intense contrast lighting conditions, using industry-leading wide dynamic range (WDR) technology. For applications with both bright and low lighting conditions that change quickly, True WDR (120 dB) optimizes both the bright and dark areas of a scene at the same time to provide usable video.
Intelligent Video System
IVS is a built-in video analytic algorithm that delivers intelligent functions to monitor a scene for Tripwire violations and intrusion detection. A camera with IVS quickly and accurately responds to monitoring events in a specific area and offers tamper detection by recognizing a dramatic scene change and generating a warning message to inspect the camera.
Smart IR Technology
With IR illumination, detailed images can be captured in low light or total darkness. The camera’s Smart IR technology adjusts the intensity of the camera’s infrared LEDs to compensate for the distance of an object. Smart IR technology prevents IR LEDs from whitening out images as they come closer to the camera. The camera’s integrated infrared illumination provides high-performance in extreme low-light environments up to 30 m (98.43ft).
ArcticPro
The Dahua ArcticPro Series of extreme-environment cameras combine temperature-tolerant components with a waterproof enclosure to ensure flawless operation in temperatures as low as –40°F (–40°C) without the need for an internal heater. The lack of a heater reduces the camera’s power consumption and saves operating costs. For applications that demand high-resolution video with advanced features in extremely cold environments, the Dahua ArcticPro Series offers a camera to satisfy the most demanding requirements.
Cybersecurity
Dahua network cameras are equipped with a series of key cybersecurity technologies including: security authentication and authorization, access control, trusted protection, encrypted transmission, and encrypted storage. These technologies improve the camera’s ability to prevent malicious access and to protect data.
Environmental
The camera complies with the IK10 Vandal Resistance impact rating making it capable of withstanding the equivalent of 5 kg (11.02 lbs) of force dropped from a height of 40 cm (15.75 in.). Subjected to rigorous dust and water immersion tests and certified to the IP67 Ingress Protection rating makes it suitable for demanding outdoor applications. Supporting a ±30% input voltage tolerance, this camera suits even the most unstable power supply conditions.
Downloads
Compatible products
Additional Information
Analytics:
|
Intrusion Detection
|
Aperture:
|
F2.0
|
Camera Style:
|
Dome
|
Color:
|
White
|
Compatible Integration (API):
|
ONVIF Profile S
ONVIF Profile G
ONVIF Profile T
CGI Conformant
P2P
Milestone
Genetec
|
Compression:
|
Smart H.265 Plus
Smart H.264 Plus
H.265
H.264
H.264B
MJPEG
|
Day/Night:
|
ICR (True Day/Night)
|
Detect (ft):
|
245
|
Dimensions:
|
109.90 x 81.0 mm (4.33 x 3.19 in)
|
Durability:
|
Weatherproof
Vandal Proof
|
Environmental:
|
Outdoor
|
Field of View (Horizontal):
|
105
|
IR LED Quantity:
|
3
|
Identify (ft):
|
24
|
Lens Mount:
|
M12
|
Lens Size:
|
2.8mm
|
Lens Type:
|
Fixed Lens
|
Max Power Consumption:
|
6.2 Watts
|
Max. FPS and Resolution:
|
15fps at 3840 x 2160
|
Minimum Illumination (B/W):
|
0 lux at F2.0 with IR on
|
Minimum Illumination (Color):
|
0.009 lux at F2.0
|
Mobile Apps:
|
iOS
Android
|
Network Interface:
|
1x RJ-45 10M/100M Base-TX Ethernet
|
Night Vision Range (ft):
|
98
|
Noise Reduction:
|
3D DNR
|
Observe (ft):
|
98
|
Power Supply:
|
PoE (IEEE 802.3af)
12 VDC
|
Product Series:
|
Dahua Lite Series
|
Protection Code:
|
IP67
IK10
|
Protocols:
|
HTTP
HTTPS
TCP
ARP
RTP
RTSP
UDP
SMTP
FTP
DHCP
DNS
DDNS
PPPoE
QoS
UPnP
NTP
IPv4
IPv6
ICMP
IGMP
SNMP
Multicast
Bonjour
|
Recognize (ft):
|
48
|
Remote Users:
|
Up to 20
|
Resolution:
|
8MP (4K)
|
SD Card Support:
|
SD Card Supported
|
Sensor Size:
|
1/2.7"
|
Sensor Type:
|
CMOS
|
Special Technologies:
|
Dahua Starlight Technology
|
Storage Temperature:
|
-40 °C to 60 °C (-40 °F to 140 °F)
|
Technology:
|
Network (IP)
|
Warranty:
|
5-year Manufacturer Warranty
|
Wide Dynamic Range (WDR):
|
True WDR 120dB
|
