Hanwha Vision XNF-A9014RV 12MP 185° Outdoor Fisheye IP Security Camera with 1.76mm Lens and Built-In IR

Hanwha Vision XNF-A9014RV 12MP 185° Outdoor Fisheye IP Security Camera with 1.76mm Lens and Built-In IR

The Hanwha Vision XNF-A9014RV is a 12MP outdoor AI fisheye IP camera that delivers full hemispherical 185° coverage from a single device. Built around a 1/1.6" CMOS sensor and a 1.76 mm fixed stereographic lens, it produces 3584x2688 video at up to 30 fps with extremeWDR (120 dB), WiseNRII AI-based noise reduction, and WiseStream AI-driven bandwidth optimization. A Dual NPU AI engine enables advanced analytics including object detection, IVA virtual line and area events, people, vehicle, and crowd counting, queue management, and heatmap generation.

Engineered for harsh outdoor environments, the XNF-A9014RV carries IP66 ingress protection, IK10 vandal resistance, NEMA 4X, and EN 50155 transportation certification. WiseIR illumination provides up to 66 ft (20 m) of night vision, while three built-in microphones, dual H.265/H.264/MJPEG streaming, ONVIF Profile S/G/T/M support, and a FIPS 140-3 Level 3 / CC EAL6+ certified secure element combine to deliver enterprise-grade analytics, audio, and cybersecurity in a wide -40 °C to 55 °C (-40 °F to 131 °F) operating range.

Key Features:

• 12MP (3584 x 2688) panoramic resolution at up to 30 fps; delivers high-resolution 360° hemispherical coverage from a single camera.
• 1/1.6" CMOS image sensor with 0.02 lux color and 0.001 lux B/W minimum illumination; produces clean images even in challenging low-light scenes.
• 1.76 mm fixed stereographic lens with 185° horizontal, vertical, and diagonal field of view; eliminates blind spots and reduces hardware count.
• Built-in WiseIR LED illumination with up to 66 ft (20 m) night vision range; provides reliable visibility in complete darkness.
• extremeWDR up to 120 dB; preserves detail in scenes with strong backlight.
• Dual NPU AI engine for AI-based image enhancement, WiseNRII noise reduction, and WiseStream bandwidth optimization; improves image quality and reduces storage demands.
• AI object detection for person, face, vehicle, and license plate with attribute extraction; enables advanced search and forensic review.
• Business intelligence analytics: people, vehicle, and crowd counting, queue management, and heatmap; provides actionable insights for retail and transit.
• Three built-in microphones with G.711, G.726, AAC-LC, and Opus audio compression; captures rich situational audio context.
• IP66 ingress protection, IK10 vandal resistance, and NEMA 4X rating; reliable in harsh outdoor environments.
• EN 50155 transportation certification with -40 °C to 55 °C (-40 °F to 131 °F) operating range; suitable for vehicle and rolling-stock installations.
• FIPS 140-3 Level 3 and CC EAL6+ certified secure element with TLS, MACsec, and 802.1X authentication; meets enterprise cybersecurity requirements.
• ONVIF Profile S, G, T, M and SUNAPI support; integrates with virtually any modern VMS.
• PoE (IEEE 802.3af Class 3), PoE+ (IEEE 802.3at Class 4), or 12VDC powering with max 19.8W consumption (PoE+); flexible installation options.
