Description
Samsung Hanwha XNZ-6320A 2MP Indoor Box IP Security Camera with 32x Optical Zoom, Wisenet X
Key Features:
- 2 Megapixel (1920 x 1080) resolution
- 4.44 ~ 142.6mm Optical 32x zoom, Digital 32x zoom
- Max. 60fps@all resolutions (H.265 / H.264)
- H.265, H.264, MJPEG Codec, Multiple streaming
- Day & Night (ICR), WDR (150dB), Defog
- DIS with built-in Gyro sensor
- Video & Audio Analytics
- PoE, SFP,
- SD/SDHC/SDXC memory slot
Downloads
Firmware
Firmware
Quick Start Guide
Hanwha-Techwin-(Samsung)-XNZ-6320A-Quick-Start-Guide-A1
Compatible products
Camera mounts - enclosures are essential to install security cameras. Each surface will require different type of mount and bracket combination. Please check with our sales team if you need help. You can call us at (866) 441-2288 or email us at sales@a1securitycameras.com with any design questions.
Additional Information
|
Alarm Input:
|
1 Channel
|
|
Alarm Output:
|
2 Channel
|
|
Aperture:
|
F1.6
F4.4
|
|
Audio Compression:
|
G.711ulaw
G.726
AAC
|
|
Audio Input:
|
1x Channel
|
|
Camera Style:
|
Box
|
|
Color:
|
Dark Gray
|
|
Compatible Integration (API):
|
ONVIF Profile S
ONVIF Profile G
ONVIF Profile T
SUNAPI
Wisenet open platform
|
|
Compression:
|
H.265
H.264
MJPEG
|
|
Day/Night:
|
Auto
ICR (True Day/Night)
|
|
Digital Zoom:
|
32
|
|
Environmental:
|
Indoor
|
|
Field of View (Horizontal):
|
64.66
2.29
|
|
Image Enhancements:
|
Digital Image Stabilizer (DIS)
|
|
Iris:
|
Auto (DC-iris)
|
|
Languages:
|
English
|
|
Lens Size:
|
4.44~142.6mm
|
|
Lens Type:
|
Motorized (Automatic Zoom) Lens
|
|
Manufacturer Website:
|
https://hanwhavisionamerica.com/
|
|
Material:
|
Aluminum
|
|
Max Power Consumption:
|
7.5 Watts
|
|
Max. FPS and Resolution:
|
60fps at 1080P
|
|
Max. Storage Capacity:
|
512 GB
|
|
Minimum Illumination (B/W):
|
0.005 Lux 1/30sec F1.6
|
|
Minimum Illumination (Color):
|
0.05 Lux 1/30sec F1.6
|
|
Noise Reduction:
|
SSNRV
|
|
Optical Zoom:
|
32x Optical Zoom
|
|
Power Supply:
|
12 VDC
PoE (IEEE 802.3af)
|
|
Product Series:
|
Samsung Hanwha Wisenet X Series
|
|
RAM:
|
1GB
|
|
Resolution:
|
2MP
|
|
SD Card Support:
|
SD Card Supported
|
|
Sensor Size:
|
1/2.8"
|
|
Sensor Type:
|
CMOS
|
|
Serial Interface:
|
1x RS485
|
|
Storage Humidity:
|
0% to 90% RH (non-condensing)
|
|
Storage Temperature:
|
-50 °C to 60 °C (-58 °F to 140 °F)
|
|
Technology:
|
Network (IP)
|
|
USB Interface:
|
1x USB Type B
|
|
Video Output:
|
1x CVBS
|
|
Wide Dynamic Range (WDR):
|
WDR 150dB
|
