Hikvision DS-2CC12D9T-IT3E 3.6MM TurboHD 2MP Outdoor Ultra-Low Light Bullet Analog Security Camera, 3.6mm Fixed Lens, White
The Hikvision DS-2CC12D9T-IT3E 2 MP Outdoor Ultra-Low Light Power-over-Coax (PoC) Bullet Camera provides high definition analog output. TurboHD means that the analog signal can be sent over existing coaxial cable, eliminating the need to run new cables for high definition video.
EXIR is Hikvision’s proprietary IR extended range technology, which has a range of 130 feet (40 meters).
The 2.8 mm, 3.6 mm, or 6 mm lens options is optimized for viewing angles that fit any situation. True 120 db WDR (Wide Dynamic Range) ensures that ideal images are captured regardless of the lighting conditions.
Key Features:
- 2 MP High Performance CMOS
- Analog HD Output, up to 1080p Resolution
- Ultra-Low Light Pro
- 2.8 mm, 3.6 mm, or 6 mm Fixed Focal Lens
- 120dB True WDR, 3D DNR
- EXIR 2.0 with up to 130 ft (40 m) IR Range
- Dual Output: 1 HD Analog Output and 1 CVBS Output
- PoC.at, Smart Voltage Detection
- 1 Alarm Input and Output
- Up-the-Coax (HIKVISION-C)
- IP67 Protection
Downloads
Compatible products
Camera mounts - enclosures are essential to install security cameras. Each surface will require different type of mount and bracket combination. Please check with our sales team if you need help. You can call us at (866) 441-2288 or email us at sales@a1securitycameras.com with any design questions.
Additional Information
|
Aperture:
|
F1.2
|
|
Camera Style:
|
Bullet
|
|
Color:
|
White
|
|
Connection Type:
|
Wired
|
|
Day/Night:
|
ICR (True Day/Night)
|
|
Dimensions:
|
86.7 x 81.6 x 226 mm (3.4 x 3.2 x 8.9 in)
|
|
Durability:
|
Weatherproof
|
|
Environmental:
|
Outdoor
|
|
Field of View (Horizontal):
|
82.6
|
|
Image Enhancements:
|
Defog
Auto Gain Control (AGC)
Backlight Compensation (BLC)
Highlight Compensation (HLC)
|
|
Image Settings:
|
Mirror
Sharpness
|
|
Lens Mount:
|
M12
|
|
Lens Size:
|
3.6mm
|
|
Lens Type:
|
Fixed Lens
|
|
Manufacturer Website:
|
https://us.hikvision.com/en
|
|
Material:
|
Metal
|
|
Max Power Consumption:
|
4 Watts
|
|
Max. FPS and Resolution:
|
30fps at 1080P
|
|
Minimum Illumination (B/W):
|
0 lux with IR illumination on
|
|
Minimum Illumination (Color):
|
0.003 Lux at F1.2 AGC On
|
|
Night Vision Range (ft):
|
131
|
|
Night Vision Type:
|
Night Vision (IR)
|
|
Power Supply:
|
12 VDC
PoC.at
|
|
Privacy Mask:
|
8 area
|
|
Product Series:
|
Hikvision Turbo HD Series
|
|
Protection Code:
|
IP67
|
|
Resolution:
|
2MP
|
|
Sensor Type:
|
CMOS
|
|
Shutter Speed:
|
1/30-1/50000s
|
|
Technology:
|
HD CCTV
|
|
Warranty:
|
3-year Manufacturer Warranty
|
|
Wide Dynamic Range (WDR):
|
True WDR 120dB
|
