Description
Honeywell HC60WZ4R40KI 4MP Outdoor PTZ IP Security Camera with 5.3–212mm Lens and Built-In IR
The Honeywell HC60WZ4R40KI is a rugged 4MP PTZ IP camera designed for precision outdoor surveillance in challenging environments. Equipped with a 1/1.8” CMOS sensor and a 40x optical zoom lens (5.3–212mm), it delivers sharp 2592 × 1520 resolution video at up to 30 fps. The camera supports triple streaming using H.265, H.264, and MJPEG compression formats and features up to 450 meters of IR illumination for night vision. Smart analytics include face detection, intrusion, loitering, and people counting. Built to endure harsh weather and physical impact, it comes with IP66/IP67 and IK10-rated housing and supports PoE++ or 24VAC power input.
Key Features:
- 4MP resolution at up to 30 fps with 1/1.8” CMOS sensor
 - 40x optical zoom with 5.3–212mm focal length and F1.5–F4.8 aperture
 - IR illumination up to 450 m using 8 Smart IR LEDs
 - 140 dB wide dynamic range for challenging lighting environments
 - Advanced AI analytics including face detection, people counting, loitering, and intrusion detection
 - Triple stream support with H.265, H.264, and MJPEG codecs
 - MicroSD card slot supporting up to 1 TB for onboard recording
 - Pan range 360° endless and tilt range -10° to 90° with auto-flip
 - Rugged weatherproof and vandal-resistant design, rated IP66/IP67 and IK10
 - ONVIF Profile G/S/T/M compliant
 - Secure authentication chipset with firmware encryption and TLS 1.2
 - Power options include PoE++ (IEEE 802.3bt) or 24VAC
 - Compatible with Honeywell MAXPRO, ADPRO, and Pro-Watch NVRs

Downloads
                            Datasheet
                            Honeywell-HC60WZ4R40KI-Datasheet-A1

                    Additional Information
|
                 Aperture:
             |


                            F1.5


             |

|
                 Camera Style:
             |


                            PTZ


             |

|
                 Compression:
             |


                            Smart Codec


             |

|
                 Day/Night:
             |


                            Auto


             |

|
                 Dimensions:
             |


                            Ø8.90x14.28in


             |

|
                 Environmental:
             |


                            Outdoor


             |

|
                 Lens Size:
             |


                            5.3~212mm


             |

|
                 Lens Type:
             |


                            Motorized


             |

|
                 Max Power Consumption:
             |


                            45 Watts


             |

|
                 Minimum Illumination (B/W):
             |


                            0 lux @ F1.6 (IR on)


             |

|
                 Minimum Illumination (Color):
             |


                            0.005 lux @ F1.6


             |

|
                 Night Vision Range (ft):
             |


                            1476


             |

|
                 Optical Zoom:
             |


                            40x Optical Zoom


             |

|
                 Power Supply:
             |


                            PoE++ (IEEE 802.3bt)


             |

|
                 Protection Code:
             |


                            IK10


             |

|
                 Resolution:
             |


                            4MP


             |

|
                 SD Card Support:
             |

                 |

|
                 Sensor Size:
             |


                            1/1.8"


             |

|
                 Sensor Type:
             |


                            CMOS


             |

|
                 Storage Humidity:
             |


                            0% to 95%


             |

|
                 Storage Temperature:
             |


                            -60°C to 60°C (-76°F to 140°F)


             |

|
                 Technology:
             |


                            Network (IP)


             |

|
                 Wide Dynamic Range (WDR):
             |


                            WDR 140dB


             |
