Description
Honeywell HC35WF6R1 6MP Outdoor Fisheye IP Security Camera with 1.22mm Lens and Built-In IR
The Honeywell HC35WF6R1 is a compact and rugged 6MP fisheye IP camera engineered for immersive 360° surveillance in outdoor and indoor environments. Equipped with a 1/2.8” CMOS sensor and a 1.22mm fixed lens, it delivers ultra-wide panoramic views with 180° x 180° field of view at up to 60 frames per second. This camera supports advanced H.265 compression, True WDR up to 120 dB, and built-in IR illumination with a range of up to 20 meters (66 feet), enabling effective day and night monitoring. The HC35WF6R1 offers audio and alarm I/O, supports edge recording via microSD (up to 1TB), and is rated IP67 and IK10 for protection against harsh weather and physical impacts. Its fisheye mode supports video analytics, providing intelligent monitoring for open-area applications.
Key Features:
- 6MP resolution at 60 FPS for smooth, detailed panoramic coverage
- 1.22mm fixed lens with 180° x 180° ultra-wide field of view
- Built-in IR illumination with a range up to 20 meters (66 feet)
- H.265, H.264, and MJPEG compression for optimized bandwidth and storage
- True Wide Dynamic Range up to 120 dB for challenging lighting conditions
- Supports video analytics in fisheye mode on a single channel
- IP67-rated for weather resistance and IK10-rated for vandal protection
- Audio input and output for two-way communication
- Alarm input and output for event-based responses
- microSD card support up to 1TB for edge video storage
- ONVIF compliant for integration with third-party VMS platforms
- Power via PoE or 12V DC with low consumption at 10.6W
Downloads
Additional Information
Camera Style:
|
Fisheye
|
Compression:
|
H.264
H.265
MJPEG
|
Day/Night:
|
|
Dimensions:
|
Ø130 x 51.5 mm (5.12" x 2.03")
|
Lens Size:
|
1.22mm
|
Protection Code:
|
IP66
IP67
IK10
|
Resolution:
|
6MP
|
Sensor Size:
|
1/2.8"
|
Sensor Type:
|
CMOS
|
Technology:
|
Network (IP)
|
Wide Dynamic Range (WDR):
|
True WDR 120dB
|
