Ikegami ISD-A35S-31WH 525TVL Hyper Wide Light Dynamic Outdoor Dome CCTV Analog Security Camera

Brand:
Part Number: ISD-A35S-31WH
Write a Review
  • Ikegami ISD-A35S-31WH 525TVL Hyper Wide Light Dynamic Outdoor Dome CCTV Analog Security Camera
  • Ikegami ISD-A35S-31WH 525TVL Hyper Wide Light Dynamic Outdoor Dome CCTV Analog Security Camera
  • Ikegami ISD-A35S-31WH 525TVL Hyper Wide Light Dynamic Outdoor Dome CCTV Analog Security Camera
$435.00
OR
Free shipping over $300 Free Shipping
Technical Support Technical Support
  • Lens Type : Varifocal (Manual Zoom) Lens
  • Lens Size : 2.8~11mm Lens
  • Sensor Type : CMOS
  • Sensor Size : 1/3.2" Sensor
  • Color : White
  • Environmental : Indoor and Outdoor
  • Weatherproof : Yes
  • Sensor Size : 1/3.2"

Description

Ikegami ISD-A35S-31WH 525TVL Hyper Wide Light Dynamic Outdoor Dome CCTV Analog Security Camera

As the newest addition to the Ikegami Hyper Dynamic Camera Series, Model ISD-A35S features an extremely wide light dynamic range, high sensitivity and high resolution enabled by a 1/3-inch CMOS sensor and Ikegami's digital processing technology. This camera is equipped with an auto iris vari-focal lens, back-light compensation, automatic iris control and phase adjustable AC line lock or crystal controlled internal sync lock system. It is a Hyper Wide Light Dynamic Range Dome Camera that reproduces a clear and natural image even in locations where there is a significant difference in the intensity of illumination, such as window areas, or in lobby entrance of building. ISD-A35S employs a vandal resistant dome housing that is IP66 compliant for outdoor use.

  • All-in-One Ergonomic Compact Dome Housing: This dome camera comes with an aesthetic dome housing.
  • All-in-One 3 Axis Adjustable and Vari-focal Lens: This camera comes with all-in-one 3 Axis directional design and vari-focal lens. 3 axis adjustable design allows good positioning for omni-directional viewing from a ceiling, or even on a side wall.
  • Hyper Wide Light Dynamic Range (Hyper WDR): The Hyper WDR function provides for very effective compensation of high light and dark areas in screen. This situation may occur generally outside or viewing from indoor to outside scenes. Even in large light fluctuations, bright-and-dark objects can be captured and viewed clearly with a natural color.
  • Automatic White Balance: Thanks to the automatic tracking white balance control (ATW), the white balance control adjusts itself no matter how great the subject's color temperature fluctuates.
  • High-quality Picture and High Resolution: The camera is designed for smear-free imaging and low noise. The well-designed DSP, Digital Signal Processor, effectively enhances details, which achieves crisp and sharp images with a high signal-to-noise ratio. The high resolution of a horizontal resolution of 520 TVL (690 HTVL-Effective) is assured.
  • High Sensitivity: Various modes of Automatic Gain control (AGC) are available to finely adjust the camera settings depending on the subject's illumination conditions. With the AGC and a slow shutter in combination, high sensitivity of up to 0.025 lux/F1.6 is achieved.
  • Optimum Monitor Output Select Function: The optimum picture quality can be obtained with this function for CRT or LCD monitors. You may choose this output selection to provide the best pictures on the monitor screen.
  • Scene File Function (4 positions): Along with a normal setting (NORMAL), 4 position scene file (preset file) for each particular scene is provided. Using this function enables an easy setup suitable for a scene without any special adjustment.
  • Focus EZ Function: Thanks to the Level Indicator, a focusing point is visibly recognized. The auto iris lens aperture will be kept open, even in broad daylight. This ensures that an accurate focus can be set readily with the best depth of field.
  • Defog Function: Defog functions to capture clear images when the entire video looks foggy

Key features:

  • 525TVL
  • 1/3" CMOS
  • 2.8~11mm Varifocal Lens
  • Hyper Wide Light Dynamic
  • Weatherproof IP66
  • Angle of View: 88.2° 28.7°
  • ATW, AGC, Defog
  • NTSC
  • 6-year Manufacturer Warranty
Mode Lens Type Electronic
Sensitivity
Control
VBS
Output
Minimum Illumination
Color 2.9-10mm OFF 50% 0.22Lx/F1.2
ON (x32) 0.0069Lx/F1.2
9-22mm OFF 0.34Lx/F1.5
ON (x32) 0.011Lx/F1.5
B/W 2.9-10mm OFF 0.081Lx/F1.2
ON (x32) 0.0025Lx/F1.2
OFF 25% 0.022Lx/F1.2
ON (x32) 0.00069Lx/F1.2
9-22mm OFF 50% 0.13Lx/F1.5
ON (x32) 0.004Lx/F1.5
OFF 25% 0.034Lx/F1.5
ON (x32) 0.0011Lx/F1.5
View AllClose

Additional Information

Camera Style:
Dome
Color:
White
Environmental:
Indoor and Outdoor
Key Features:
Weatherproof
Lens Size:
2.8~11mm
Lens Type:
Varifocal (Manual Zoom) Lens
Resolution:
525TVL
SD Card Support:
Sensor Size:
1/3.2"
Sensor Type:
CMOS
Technology:
CCTV (Analog)
Vandal Proof:
Weatherproof:
View AllClose
