IQSIGHT DINION inteox 7100i NBI-7803-AX 2MP Outdoor Bullet IP Security Camera with 3.9-10mm Lens and Built-In IR

Bosch DINION inteox 7100i NBI-7803-AX 2MP Outdoor Bullet IP Security Camera with 3.9-10mm Lens and Built-In IR

The IQSIGHT DINION inteox 7100i is a 2MP outdoor bullet IP security camera built on the CPP16 platform, purpose-engineered for perimeter, parking, and long-range outdoor surveillance where a directional bullet form factor is preferred over a dome. The 3.9–10mm motorized varifocal lens delivers flexible framing across a wide range of outdoor coverage scenarios — from building facades and access roads to loading docks and open parking areas — with remote autofocus for installation without on-site lens adjustment. Built-in IR illumination provides 24/7 coverage in complete outdoor darkness, while HDR X technology captures moving objects at up to 120 dB dynamic range without motion blur or artefacts in high-contrast scenes.

The camera ships with IVA Pro Buildings and IVA Pro Perimeter pre-installed on the CPP16 platform — Bosch's deep-learning video analytics engine providing highly reliable detection and tracking of persons and vehicles. IVA Pro is specifically resilient against environmental false triggers including rain, wind, shadows, insects, and vegetation movement, making it particularly effective in demanding outdoor perimeter applications. Built-in 3D auto-calibration converts 2D pixels into real-world size, speed, and geolocation data with a single click, enabling accurate behavioral analytics without manual calibration. The camera integrates with Bosch Remote Portal for centralized management across large-scale deployments.

The NBI-7803-AX features a FIPS 140-3 Level 3 / CC EAL6+ certified secure element (TPM) for hardware-level cybersecurity including secure boot, encrypted firmware, and AES-256 certificate storage. It is IP66 and IK10 rated for full outdoor weatherproofing and vandal resistance, operates from -40°C to 60°C (-40°F to 140°F), and is powered via PoE+ (IEEE 802.3at), PoE (IEEE 802.3af), or 24VAC. Both NDAA and TAA compliant for government and enterprise procurement.

Key Features:

• 2MP Bullet with 3.9–10mm Motorized Varifocal Lens; provides directional outdoor coverage with remote focus adjustment across building perimeters, parking areas, and long-range zones.
• IVA Pro Buildings and Perimeter Pre-installed (CPP16); delivers deep-learning person and vehicle detection with industry-leading false-alarm immunity against environmental triggers.
• HDR X 120 dB; captures sharp, artefact-free imagery of moving objects in high-contrast outdoor scenes without multi-exposure motion blur.
• 3D Auto-Calibration; converts pixels to real-world measurements with a single click for accurate speed, size, and geolocation data without manual setup.
• Built-In IR Illumination; provides 24/7 outdoor night coverage in complete darkness with manually adjustable IR intensity.
• IP66 + IK10 Rated; delivers comprehensive outdoor weatherproofing and high-impact vandal resistance for permanent exposed installations.
• FIPS 140-3 Level 3 / CC EAL6+ Secure Element; hardware-rooted cybersecurity with TPM certificate storage, secure boot, and AES-256 encryption.
• NDAA and TAA Compliant; meets federal procurement requirements for government, defense, and enterprise installations.
