LTS BF22-3 NDAA Compliant IP Security System with 12x 4MP Turret Cameras and 32 Channel NVR and 3TB HDD, Pro-VS

Brand: LTS Security
Part Number: BF22-3
Write a Review
Replacement: There is no direct replacement. Ask a representative.
Check other similar products:
LTS Security Camera Systems
LTS IP Security Camera Systems
NDAA Compliant Cameras
LTS Pro-VS Series
12 Camera Security Systems
Discontinued
  • LTS BF22-3 NDAA Compliant IP Security System with 12x 4MP Turret Cameras and 32 Channel NVR and 3TB HDD, Pro-VS
  • LTS BF22-3 NDAA Compliant IP Security System with 12x 4MP Turret Cameras and 32 Channel NVR and 3TB HDD, Pro-VS
  • LTS BF22-3 NDAA Compliant IP Security System with 12x 4MP Turret Cameras and 32 Channel NVR and 3TB HDD, Pro-VS
  • LTS BF22-3 NDAA Compliant IP Security System with 12x 4MP Turret Cameras and 32 Channel NVR and 3TB HDD, Pro-VS
  • LTS BF22-3 NDAA Compliant IP Security System with 12x 4MP Turret Cameras and 32 Channel NVR and 3TB HDD, Pro-VS
  • LTS BF22-3 NDAA Compliant IP Security System with 12x 4MP Turret Cameras and 32 Channel NVR and 3TB HDD, Pro-VS
  • LTS BF22-3 NDAA Compliant IP Security System with 12x 4MP Turret Cameras and 32 Channel NVR and 3TB HDD, Pro-VS
  • LTS BF22-3 NDAA Compliant IP Security System with 12x 4MP Turret Cameras and 32 Channel NVR and 3TB HDD, Pro-VS

? Help me pick a security camera

Free shipping over $300 Free Shipping
Technical Support Technical Support
3 Year Warranty 3 Year Warranty
  • Compression : H.264, MJPEG, H.265, Ultra 265,
  • Field of View (Horizontal) : 107.8°Field of View
  • Max. FPS and Resolution : 30fps at 4MP
  • Lens Type : Fixed Lens
  • Lens Size : 2.8mm Lens
  • Sensor Type : CMOS
  • Sensor Size : 1/3" Sensor
  • Pre-Installed Storage : No HDD included
  • Video Output : 1x HDMI 1x VGA
  • Max. Recording Resolution : 8MP (4K)
  • Hard Drive Ports : 4 SATA Ports
  • Max. Storage Capacity : 256 GB Storage Capacity 14 TB Storage Capacity
  • Protection Code : IP67
  • Color : White Black
  • Material : Metal Plastic
  • Environmental : Outdoor Indoor
  • Number of PoE Ports : 16 PoE Ports
  • Audio Support : Built-in Microphone
  • Buffer (MB Cache) : 64
  • Capacity : 3 TB
  • Form Factor : 3.5"
  • RPM : 5400
  • Storage Types : Internal HDD

Related Products

Description

LTS BF22-3 NDAA Compliant IP Security System with 12x 4MP Turret Cameras and 32 Channel NVR and 3TB HDD, Pro-VS

VSIP3442W-28MA Key Features:

  • Resolution: 4MP, 2688 x 1520@30fps
  • Fixed Lens: 2.8mm
  • Lux: 0.01 lux @F2.0
  • Compression: Ultra 265/H.265/H.264/MJPEG
  • IR: Smart IR LED up to 98ft
  • Features: 120dB WDR, 2D/3D DNR, BLC, HLC, Digital Defog
  • Audio: Built-in Mic
  • Storage: Edge storage MicroSD up to 256GB, Automatic Network Replenishment
  • Axis: 3 Axis
  • Rating: IP67, 2KV Surge Protection
  • Power: DC 12V, PoE

VSN7432-P16 Key Features:

  • Resolution: 4MP, 2688 x 1520@30fps
  • Fixed Lens: 2.8mm
  • Lux: 0.01 lux @F2.0
  • Compression: Ultra 265/H.265/H.264/MJPEG
  • IR: Smart IR LED up to 98ft
  • Features: 120dB WDR, 2D/3D DNR, BLC, HLC, Digital Defog
  • Audio: Built-in Mic
  • Storage: Edge storage MicroSD up to 256GB, Automatic Network Replenishment
  • Axis: 3 Axis
  • Rating: IP67, 2KV Surge Protection
  • Power: DC 12V, PoE
  • Video Input: 32CH IP@160Mbps
  • Video Output: HDMI up to 4K(3840 x 2160) / VGA up to 1080P
  • Max. Recording Resolution: Up to 8MP(3840x2160)
  • Decoding Format: H.265/H.264
  • Decoding Capability: 2CH@4K / 8CH@1080P
  • Max. Playback Resolution: Up to 8MP(3840x2160)
  • Audio In/Out: 1CH/1CH, RCA
  • Alarm In/Out: 16CH/4CH
  • Built-in PoE: 16CH
  • Network: 10/100/1000M, 1 RJ45
  • Storage: 4 SATA up to 14TB for each disk
  • Backup: 1 USB 2.0, 1 USB 3.0
  • Dimensions: 15.7”(W)x14.2”(D)x2.9”(H)
  • Recorder Case: 1.5U

DHWD30PURX Key Features:

  • Capacity 3 TB
  • Interface SATA 6Gb/s
  • Form Factor 3.5 Inch
  • 5400RPM
  • 64MB Cache

Downloads

Datasheet wd30purx-A1.pdf

Popular Search

LTS Security Camera Systems
LTS IP Security Camera Systems
NDAA Compliant Cameras
LTS Pro-VS Series
12 Camera Security Systems

Additional Information

4K Support:
4K Supported
Alarm Input:
16 Channel
Alarm Output:
4 Channel
Audio Capability:
Two-Way Audio
Audio Compression:
G.711
Audio Input:
1x RCA
Audio Output:
1x RCA
Audio Support:
Built-in Microphone
Buffer (MB Cache):
64
Camera Style:
Turret
Capacity:
3 TB
Capacity for each disk:
up to 14TB
Channel Capacity:
32 Channels
Color:
White Black
Compatible Integration (API):
API ONVIF Profile G ONVIF Profile S ONVIF Profile T
Compliance:
NDAA Compliant
Compression:
H.264 MJPEG H.265 Ultra 265
Day/Night:
ICR (True Day/Night)
Detect (ft):
206.69 295
Dimensions:
400 x 362 x 74 mm (15.7 x 14.2 x 2.9 in)
Drive Interface:
SATA III
Durability:
Weatherproof
Environmental:
Outdoor Indoor
Field of View (Horizontal):
107.8
Form Factor:
3.5"
Hard Drive Ports:
4 SATA Ports
Identify (ft):
20 29
Lens Size:
2.8mm
Lens Type:
Fixed Lens
Material:
Metal Plastic
Max. FPS and Resolution:
30fps at 4MP
Max. Incoming Bandwidth:
160Mbps
Max. Recording Resolution:
8MP (4K)
Max. Storage Capacity:
256 GB 14 TB
Minimum Illumination (B/W):
0 lux with IR illumination on
Minimum Illumination (Color):
0.01 Lux at F2.0 AGC ON
Network Interface:
1x RJ-45 10M/100M Base-TX Ethernet 1x RJ-45 10M/100M/1000M self-adaptive Ethernet Interface
Night Vision Range (ft):
98
Night Vision Type:
Smart IR Night Vision (IR)
Noise Reduction:
2D DNR 3D DNR
Number of PoE Ports:
16 PoE Ports
Number of Security Cameras:
12 camera system
Observe (ft):
118 82
Operating Humidity:
0% to 95% RH (non-condensing) 0% to 90% RH (non-condensing)
Operating Temperature:
-30 °C to 60 °C (-22 °F to 140 °F) -10 °C to 55 °C (14 °F to 131 °F)
Outgoing Bandwidth:
64 Mbps
Power Supply:
12 VDC PoE (IEEE 802.3af) 100 to 240 V AC
Pre-Installed Storage:
No HDD included
Product Series:
LTS Pro-VS Series
Protection Code:
IP67
Protocols:
DHCP NTP P2P PPPoE UPnP
RPM:
5400
Rack Unit (U):
1.5U
Recognize (ft):
39 59
Recorder Technology:
Network Video Recorder (NVR)
Remote Users:
Up to 128
Resolution:
4MP
S/N Ratio:
>56 dB
SD Card Support:
SD Card Supported
Sensor Size:
1/3"
Sensor Type:
CMOS
Serial Interface:
1x RS485
Shutter Speed:
1-1/100000s
Storage Humidity:
0% to 95% RH (non-condensing)
Storage Temperature:
-30 °C to 60 °C (-22 °F to 140 °F)
Storage Types:
Internal HDD
Synchronous Playback:
16 Channel
Technology:
Network (IP)
USB Interface:
1x USB 2.0 1x USB 3.0
Video Output:
1x HDMI 1x VGA
Warranty:
3-year Manufacturer Warranty
Wavelength (nm):
850
Wide Dynamic Range (WDR):
True WDR 120dB
