Description
LTS CMIP7553W4-SZ8 4x 5MP Outdoor Multi-sensor IP Security Camera - LTCMIP7553W4-SZ8
Key Features:
- 20 MP (4x 5MP)
- 1/2.7" Progressive Scan CMOS
- Varifocal lens, 2.8 to 8 mm
- Horizontal FOV 100° to 49°
- 2560 x 1920 @ 25fps
- H.265, H.264, H.265+, H.264+
- Up to 30m IR range
- 4 Flexible lens
- 120dB WDR
- Weatherproof IP67,
- Vandal Proof IK10
- Motion detection
- Built-in microSD/SDHC/SDXC card (up to 128 GB)
- ONVIF
- Only need 1 Network Cable. Save Labor, Save Money
Replacement of:
CMIP7553W4-SZ
Compatible products
Camera mounts - enclosures are essential to install security cameras. Each surface will require different type of mount and bracket combination. Please check with our sales team if you need help. You can call us at (866) 441-2288 or email us at sales@a1securitycameras.com with any design questions.
Additional Information
|
Alternative SKUs:
|
CMIP75xx
LTCMIP75xx
CMIP7553W4-SZ8
|
|
Analytics:
|
Motion Detection
|
|
Aperture:
|
F1.9
|
|
Audio Compression:
|
G.711
G.722.1
G.726
MP2L2
PCM
|
|
Audio Input:
|
1x 3.5mm
|
|
Audio Output:
|
1x 3.5mm
|
|
Camera Style:
|
Multi-sensor
|
|
Compatible Integration (API):
|
ONVIF Profile S
ONVIF Profile G
ONVIF Profile T
ISAPI
SDK
|
|
Compression:
|
H.265 Plus
H.264 Plus
H.265
H.264
|
|
Day/Night:
|
ICR (True Day/Night)
|
|
Detect (ft):
|
196
393
|
|
Durability:
|
Weatherproof
Vandal Proof
|
|
Environmental:
|
Outdoor
|
|
Field of View (Horizontal):
|
100
49
|
|
Identify (ft):
|
19
39
|
|
Languages:
|
English
Spanish
Turkish
Russian
German
Italian
French
|
|
Lens Size:
|
2.8~8mm
|
|
Lens Type:
|
Varifocal (Manual Zoom) Lens
|
|
Max. FPS and Resolution:
|
25fps at 2560 x 1920
|
|
Max. Storage Capacity:
|
128 GB
|
|
Minimum Illumination (B/W):
|
0.0025 Lux at F1.9 AGC ON
|
|
Minimum Illumination (Color):
|
0.0125 Lux at F1.9 AGC ON
|
|
Network Interface:
|
1x RJ-45 10M/100M/1000M self-adaptive Ethernet Interface
|
|
Night Vision Range (ft):
|
98
|
|
Night Vision Type:
|
Night Vision (IR)
|
|
Noise Reduction:
|
3D DNR
|
|
Observe (ft):
|
75
154
|
|
Product Series:
|
LTS Platinum Series
|
|
Protection Code:
|
IP67
IK10
|
|
Recognize (ft):
|
39
78
|
|
Remote Users:
|
Up to 32
|
|
Reset Button:
|
|
|
Resolution:
|
5MP (3K)
|
|
S/N Ratio:
|
>52 dB
|
|
SD Card Support:
|
SD Card Supported
|
|
Sensor Size:
|
1/2.7"
|
|
Sensor Type:
|
CMOS
|
|
Serial Interface:
|
1x RS232
1x RS485
|
|
Shutter Speed:
|
1-1/100000s
|
|
Storage Humidity:
|
0% to 95% RH (non-condensing)
|
|
Storage Temperature:
|
-30 °C to 60 °C (-22 °F to 140 °F)
|
|
Technology:
|
Network (IP)
|
|
Warranty:
|
3-year Manufacturer Warranty
|
|
Wavelength (nm):
|
850
|
|
Web Browser:
|
Internet Explorer 8 or above
Chrome 41.0 to 44
Firefox 30.0 to 51
Safari 8 to 11
|
|
Wide Dynamic Range (WDR):
|
True WDR 120dB
|
