Description
LTS CMR5662 Indoor Bullet CCTV Analog Security Camera - White
Key Features:
- 1/3" PixelPlus
- 4.6mm fixed lens
- 42 pcs IR LEDs, 80ft
- Indoor/Outdoor
- Aluminum housing
- DC 12V input
Popular Search
Specifications
Specifications
| Camera Series | Others |
|---|---|
| Camera Resolution | 1.3MP / 720P |
| Camera Technology | HD-TVI |
| Camera Housing | Bullet |
| Featured Product | No |
| Specifications | Model # CMR5662 CMR5662B Image Image Sensor 1/3" PixelPlus 1/3" PixelPlus Effective Pixels NTSC: 728(H) x 488(V) NTSC: 728(H) x 488(V) Horizontal Resolution 600 TVL 600 TVL Focal Length 4.6mm fixed lens 4.6mm fixed lens Electrical Video System NTSC/PAL NTSC Video Scanning Type 2:1 Interlace 2:1 Interlace Sync. System Internal Internal S/N Ratio > 50dB (AG C off) > 50dB (AGC off) Min. Illumination 0 Lux/F1.2 (IR On) 0 Lux/F1.2 (IR On) Video Output 1 BNC, 1.0 Vp-p, 75 Ohm Composite 1 BNC, 1.0 Vp-p, 75 Ohm Composite Function Electronic Shutter 1/60s ~ 1/100,000s 1/60s ~ 1/100,000s White Balance ATW ATW BLC Yes Yes AWB Auto Auto ICR Yes Yes Infrared LED Infrared Red Lamps 42 pcs IR LEDs 42 pcs IR LEDs IR Distance 80ft 80ft Power Input Voltage DC 12V DC 12V Power Consumption < 2W (LED OFF) / < 6W (LED ON) < 2W (LED OFF) / < 6W (LED ON) Environment Operating Temperature 14°F ~ 122 °F (-10? ~ 50 ?) 14°F ~ 122 °F (-10? ~ 50 ?) Storage Temperature 4°F ~ 144 °F (-20? ~ 60 ?) 4°F ~ 144 °F (-20? ~ 60 ?) Humidity RH90% Max. (Non-condensing) RH90% Max. (Non-condensing) Mechanical Chasis Material & Color Aluminum housing & Silver Aluminum housing & Black Product Net Weight - - Product Dimension 7.75(l) x 3(w) x 3 (h) 7.75(l) x 3(w) x 3 (h) |
Additional Information
|
Alternative SKUs:
|
LTCMR5662
|
|
Camera Style:
|
Bullet
|
|
Environmental:
|
Indoor
|
|
Night Vision Range (ft):
|
80
|
|
Resolution:
|
600TVL
|
|
Sensor Size:
|
1/3"
|
|
Technology:
|
CCTV (Analog CVBS)
|
