Description
LTS LTN8704Q-P4N 4 Channel 4K Network Video Recorder, 4 PoE Ports, H.265+
Key Features:
- Up to 4-ch IP camera inputs
- No HDD included
- H.265+/H.265/H.264+/H.264 video formats
- Up to 1-ch@8 MP/5-ch@1080p decoding capacity
- Up to 40 Mbps incoming bandwidth
Replacement of:
LTN8704Q-P4
Downloads
Datasheet
LTS-Security-LTN8704Q-P4N-Datasheet-A1
User Manual
LTS-Security-LTN8704Q-P4N-User-Manual-A1
Quick Start Guide
LTS-Security-LTN8704Q-P4N-Quick-Start-Guide-A1
Popular Search
Compatible products
Video recorders will require additional parts in order to perform their function. CCTV Power supply, PoE Switches, hard drives, wireless mouse, recorder mount accessories and cables are just few to be mentioned. If you have any questions to complete your security camera system, please check with our sales team first. You can call us at (866) 441-2288 or email us at sales@a1securitycameras.com with any design questions.
Additional Information
|
4K Support:
|
4K Supported
|
|
Audio Capability:
|
Two-way Audio
|
|
Audio Compression:
|
G.711ulaw
G.711alaw
G.722
G.726
|
|
Audio Input:
|
1x Channel
|
|
Audio Output:
|
1x Channel
|
|
Channel Capacity:
|
4 Channels
|
|
Compression:
|
H.265 Plus
H.265
H.264
H.264 Plus
|
|
Hard Drive Ports:
|
1 SATA Port
|
|
Max Power Consumption:
|
10 Watts
|
|
Max. Recording Resolution:
|
8MP (4K)
|
|
Max. Storage Capacity:
|
8 TB
|
|
Network Interface:
|
1x RJ-45 10M/100M Base-TX Ethernet
|
|
Number of PoE Ports:
|
4 PoE Ports
|
|
PoE Standards:
|
IEEE 802.3af
IEEE 802.3at
|
|
Power Supply:
|
48 VDC 1.35A
|
|
Pre-Installed Storage:
|
No HDD included
|
|
Product Series:
|
LTS Platinum Professional Series
|
|
Recorder Technology:
|
Network Video Recorder (NVR)
|
|
Synchronous Playback:
|
4 Channel
|
|
USB Interface:
|
2x USB 2.0
|
|
Video Output:
|
1x HDMI
1x VGA
|
|
Warranty:
|
3-year Manufacturer Warranty
|
