| Camera |
| Image Sensor | 1/3" Progressive Scan CMOS |
| Min. Illumination | Color: 0.01 Lux @ (F1.2, AGC ON), 0.018 Lux @ (F1.6, AGC ON), 0 Lux with IR |
| Shutter Speed | 1/3 s ~ 1/10,000 s |
| Slow Shutter | Support |
| Lens | 4 mm: horizontal FOV: 78° |
| 6 mm: horizontal FOV: 48° |
| Lens Mount | M12 |
| Day & Night | IR cut filter with auto switch |
| WDR | 120dB |
| Compression Standard |
| Video Compression | H.265+/H.265/H.264+/H.264/MJPEG |
| H.264 Type | Main Profile |
| Video Bit Rate | 32 Kbps – 16 Mbps |
| Image |
| Max. Resolution | 2560 x 1440 |
| Frame Rate | 50Hz:25fps (2560 × 1440, 2304 × 1296, 1920 × 1080) |
| 60Hz: 30fps (2560 × 1440, 2304 × 1296, 1920 × 1080) |
| Image Enhancement | BLC/3D DNR |
| Image Setting | Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser |
| Day/Night Switch | Auto/Schedule |
| Network |
| Network Storage | Support for microSD / SDHC / SDXC card (128G), local storage, NAS (NFS,SMB/CIFS), ANR |
| Alarm Trigger | Motion Detection, tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP™, SMTP,SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| General Function | Anti-Flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filtering |
| System Compatibility | ONVIF (PROFILE S, PROFILE G), ISAPI |
| Smart Feature-set |
| Behavior Analysis | Line crossing detection, Intrusion detection |
| Line Crossing Detection | Cross a pre-defined virtual line |
| Intrusion Detection | Enter and loiter in a pre-defined virtual region |
| Recognition | Face Detection |
| General |
| Communication Interface | 1 RJ45 10M/100M Ethernet interface |
| Operating Conditions | -22 °F – 140 °F |
| Humidity 95% or less (non-condensing) |
| Power Consumption | 12 VDC, 0.6A, max. 7.5W |
| PoE (802.3af, 37V to 57V), 0.2A to 0.1A, max. 9.5W |
| Ingress Protection level | IP67 |
| IR Range | 165ft |
| Dimensions | Camera: Φ 105 × 299.7 mm (Φ 4.1" × 11.8") |
| Package: 386 × 156 × 155 mm (15.2" × 6.14" × 6.1") |
| Weight | 2.65lbs |
Network (IP)
8MP (4K)
White
