Pelco EXTE2-VF36-E0A00 640x512 Explosion-Proof Bullet Thermal Security Camera with 36mm Lens
The Pelco EXTE2-VF36-E0A00 represents advanced thermal imaging technology specifically engineered for hazardous industrial environments. This VGA (640x512) thermal security camera delivers exceptional infrared detection capabilities with a 36mm fixed lens, providing precise thermal imaging for critical monitoring applications in oil and gas facilities, chemical plants, and other explosion-prone areas.
Built with heavy-duty AISI 316L stainless steel construction, this camera meets stringent global explosion-proof certifications including ATEX, IECEx, UKEx, and UL standards for Class I Zone 1 and Zone 21 hazardous locations. The camera operates reliably in extreme temperature conditions from -58°F to 149°F (-50°C to +65°C) while maintaining thermal sensitivity of ≤50 mK NETD for superior detection accuracy even in challenging environmental conditions.
Enhanced with Pelco Smart Compression technology and 8-14μm spectral range thermal imaging, this camera provides efficient bandwidth management while delivering clear thermal detection up to 30 fps. The advanced thermal sensor features multiple color palettes including White Hot, Black Hot, and Rainbow modes, with automatic flat field correction for consistent image quality and 3D noise reduction for enhanced clarity in demanding industrial surveillance applications.
Key Features:
- VGA (640x512) thermal resolution with 36mm fixed lens
- Explosion-proof design with ATEX, IECEx, UKEx, UL certifications
- Class I Zone 1, Zone 21 hazardous location compliance
- ≤50 mK NETD thermal sensitivity for precise detection
- Heavy-duty AISI 316L stainless steel construction
- Operating temperature range: -58°F to 149°F (-50°C to +65°C)
- 8-14μm spectral range for optimal thermal imaging
- Pelco Smart Compression technology for bandwidth efficiency
- Multiple thermal palettes with 3D noise reduction
- ONVIF S, G, T, and M conformance for universal integration
Downloads
Additional Information
|
Camera Style:
|
Bullet
|
|
Compression:
|
H.264
MJPEG
H.265
|
|
Dimensions:
|
10.59x6.12x6.12in
|
|
Durability:
|
Explosion proof
|
|
Power Supply:
|
12 VDC
PoE (IEEE 802.3af)
24 VAC
|
|
Protection Code:
|
IP66
IP67
IP68
IP69
|
|
Resolution:
|
640 x 512
|
|
Sensor Type:
|
Thermal Sensor
|
|
Storage Temperature:
|
-40 °C to 55 °C (-40 °F to 131 °F)
|
|
Technology:
|
Network (IP)
|
|
Thermal Lens Size:
|
36mm
|
|
Thermal Resolution:
|
640 x 512
|
