Pelco TI2314-1 384x288 Outdoor Bullet Thermal IP Security Camera, 14mm Fixed Lens, 9Hz

Pelco TI2314-1 384x288 Outdoor Bullet Thermal IP Security Camera, 14mm Fixed Lens, 9Hz

T he Sarix TI Series Thermal Fixed Camera is Pelco’s most advanced thermal IP imaging system designed for easy integration into any new or existing IP video security application. The system is designed to detect, recognize, and identify people and vehicles in any lighting condition, including complete darkness. Every Sarix TI Series Thermal Fixed Camera features both visible light and thermal channels in an integrated environmentally protected IP66 rated enclosure. Additionally, the Sarix TI Series Thermal Fixed Camera features video motion analytics designed- for-thermal imaging.

Key Features:

• HD visible light and VGA/QVGA thermal channels in one compact unit
• Advanced thermal optics with 14 mm lens
• Built-in image processing algorithms and analytics
• PoE and VDC flexible power options
• Ruggedly designed to withstand the harshest environmental conditions
• Easy installation into new and existing infrastructures
• IP Connectivity
• ONVIF S Conformant
• Full 3-Year Warranty and Support

Thermal Imaging

At the core of the Sarix TI Camera is an uncooled 17µ Pixel Pitch, ASi microbolometer sensor that delivers up to 640 x 480 VGA or 384 x 288 QVGA+ thermal video.

The Sarix TI Camera provides outstanding sensitivity below 40 mK. The Sarix TI Camera is available with 14 mm, 35 mm, or 50 mm athermalized lens options for effective deployment in a wide range of applications.

Fully Featured

HD visual and VGA/QVGA thermal channels are all included in one compact unit. The visual channel has a 720p day light camera with a 52° fixed HFoV autofocus lens for complete situational awareness. The camera has an input power of 12-32 VDC or PoE+ (IEEE802.3at). The Sarix TI cameras are designed for flexible power options between either power supply. Connect both PoE+ and 24 VDC to the camera simultaneously.

The Sarix TI Series Thermal Fixed Camera uses a standard Web browser for powerful remote setup and administration. The Sarix TI Camera supports two simultaneous video streams. The streams can be compressed in MJPEG or H.264 formats across several resolution configurations to provide a variety of frame and bit rates. The enclosure makes the Sarix TI Series Thermal Fixed Camera ideal for either indoor or outdoor applications. The system has a sustained operating temperature range of –40° to 55°C (–40° to 131°F) and is IP66 rated for dust and water ingress protection.

Built-in Analytics

Advanced image processing and edge analytics enhance the flexibility and performance of the Sarix TI camera. Built into the Sarix TI camera are six highly customizable image processing algorithms creating scene-by-scene optimized images for analytics delivering improved detection, classification, and recognition. These include: polarity, brightness, temporal noise filter, contrast, sharpness, and ROI.

The Sarix TI Camera analytics capabilities are designed to work 24/7. Analytics are accurate and capable of monitoring and analyzing human, vehicle, or a pre-learned object per view. Analytic features include self- scene learning, real-time scene analysis and alarms based on user definable configuration. There is also user defined regions of interest and user-defined fences (up to 15 per scene). Analytics are easy to configure for alarm notification when used with VideoXpert or a third- party system that supports alarms using ONVIF S.
