Samsung Hanwha PNM-9322VQP H.265 Outdoor Multi-directional PTZ IP Security Camera

Samsung Hanwha PNM-9322VQP H.265 Outdoor Multi-directional PTZ IP Security Camera

Network vandal outdoor Multi-sensor Multi-Directional camera, (2MP/5MP X 4 sensors sold separately) 8MP ~20MP (2MP @ 60fps or 5MP @30fps) fixed focal lens modules + 2MP 32x optical zoom PTZ, triple codec H.265/H.264/MJPEG with WiseStream II technology, 150dB WDR @ 2MP or 120dB @ 5MP, defocus detection, built in analytics, 4x SD card, hallway view, HLC, fog detection, DIS(Gyro Sensor), PoE+, IP66/IK10, -35°C ~ +55°C (-31°F ~ +131°F)

• 2MP Lens modules: SLA-2M2400P (2.4mm), SLA-2M2800P (2.8mm), SLA-2M3600P (3.6mm), SLA-2M6000P (6mm), SLA-2M1200P (12mm)
• 5MP Lens modules: SLA-5M3700P (3.7mm), SLA-5M4600P (4.6mm)

Key Features:

Multi-directional camera

• Exchangeable 4ea x 2MP / 5MP lens modules
  8MP to 20MP resolution depend on the combination of lens modules
• WDR 150dB with 2MP lens module, 120dB with 5MP lens module
• 2.4mm, 2.8mm, 3.6mm, 6mm, 12mm fixed lens (2MP module)
• 3.7mm, 4.6mm, 7mm fixed lens (5MP module)

PTZ camera

• Maximum 2MP (1920 x 1080) resolution
• 4.44~142.6mm (Optical 32x) lens
• WDR 150dB, Day & Night (ICR)

Common:

• Maximum 60fps@2MP, Maximum 30fps@5MP (H.265 / H.264)
• H.265, H.264, MJPEG codec support
• Video Analytics, WiseStream II support
• SD / SDHC / SDXC memory 5 slots
• Lens modules are required, not included with the camera

4 + 1 cameras in one

Multi-directional plus PTZ camera has five sensors in one camera. When using the camera you can monitor a 360° wide area simultaneously with multi-directional camera while the PTZ camera zooms into the desired area for closer inspection. The four sensors in the multi-directional camera move independently of one another.

Advance handover to PTZ

When the multi-directional camera detects an event, it automatically links to PTZ camera which carries out zoom-in and track functions. When using preset mode, PTZ camera zooms in to the position that the users preset, while smart zoom mode automatically zooms into the area where event is detected.

Improve bandwidth by up to 99% using WiseStream II

When Hanwha Techwin’s original video compression technology WiseStream II is combined with H.265 compression, the bitrate data is reduced by up to 99% compared to current H.264 technology. The costs of configuring and maintaining the system are also greatly reduced, while still maintaining the same pixels and high quality.

True WDR(150dB with 2MP and 120dB with 5MP)

Even with backlight, Wisenet’s cutting-edge WDR technology addresses a limitation found in conventional WDR cameras while producing clear and vivid images. WDR improves the accuracy of an image by resolving the difference in brightness.

Hallway View

In a vertical shaped environment, traditional horizontal shaped videos focus on unnecessary edges of the area causing bandwidth and storage waste. The Hallway view creates 3 : 4 and 9 : 16 ratio image which is vertically oriented and maximizes image quality in a narrow environment.

A comprehensive range of intelligent video analytics

Wisenet P series multi-sensor cameras support a variety of exclusive video and audio analytics, providing enhanced monitoring solutions and market intelligence.

* Supported video analytics may vary depending on the camera.

Selectable and changeable multiple lens (PNM-9322VQP only)

Users can choose a wide variety of lenses from 2M 2.4mm to 5M 7.0mm for PNM-9322VQP to create the most optimal field of view for their desired monitoring areas. Choose the 4 lenses of your choice and create a combination of lens module up to 20MP resolution for multi-directional camera.
