Samsung Hanwha QND-6022R 2MP H.265 IR Indoor Dome IP Security Camera

(No reviews yet) Write a Review
SKU:
QND-6022R
UPC:
8801089169211
  • Samsung Hanwha QND-6022R 2MP H.265 IR Indoor Dome IP Security Camera
  • Samsung Hanwha QND-6022R 2MP H.265 IR Indoor Dome IP Security Camera
$337.53
$186.69
Technical Support
3 Year Warranty
  • Compression : H.265,
  • Lens Type : Fixed Lens
  • Lens Size : 4mm Lens
  • Sensor Type : CMOS
  • Sensor Size : 1/2.8" Sensor
  • Color : White
  • Environmental : Indoor
  • Sensor Size : 1/2.8"

Description

Samsung Hanwha QND-6022R 2MP H.265 IR Indoor Dome IP Security Camera

The QND-6022R from Hanwha's Q Series affordable network camera line is a 2 Megapixel indoor dome network camera featuring WiseStream II, Hanwha's compression technology, triple codec H.265/H.264/MJPEG, 4mm lens, IR, PoE/12VDC, 120dB True WDR, Intelligent Video Analytics, Hallway View, one-way audio and SD card slot (SD/SDHC/SDXC up to 128GB).

Key Features:

  • Max. 2megapixel (1920 x 1080) resolution
  • 0.1Lux (Color), 0Lux (B/W, IR LED on)
  • 4mm fixed lens
  • Max. 30fps@2M all resolutions (H.265/H.264)
  • H.265, H.264, MJPEG codec supported, Multiple streaming
  • Motion detection, Tampering, Defocus detection
  • Hallway view (90/270), LDC support
  • Micro SD/SDHC/SDXC memory slot (Max. 128GB)
  • IR viewable length 20m,
  • PoE
  • Built-in microphone


View AllClose

Specifications

Video
Imaging Device1/2.8" 2MP CMOS
Effective Pixels1920(H)x1080(V)
Min. IlluminationColor: 0.03Lux(F1.6, 1/30sec)
BW: 0Lux(IR LED on)
Video OutCVBS: 1.0 Vp-p / 75Ω composite, 720x480(N), 720x576(P) for installation
Lens
Focal Length (Zoom Ratio)4.0mm fixed focal
Max. Aperture RatioF1.6
Angular Field of ViewH: 87.6 / V: 46.4° / D: 104.5°
Focus ControlFixed
Pan / Tilt / Rotate
Pan / Tilt / Rotate Range0˚~350˚ / 0˚~67˚ / 0˚~355˚
Operational
IR Viewable Length20m(65.62ft)
Camera TitleDisplayed up to 85 characters
Day & NightAuto(ICR)
Backlight CompensationBLC, WDR, SSDR
Wide Dynamic Range120dB
Digital Noise ReductionSSNR
Motion Detection4ea, polygonal zones
Privacy Masking6ea, rectangular zones
Gain ControlLow / Middle / High
White BalanceATW / AWC / Manual / Indoor / Outdoor
LDCSupport
Electronic Shutter SpeedMinimum / Maximum / Anti flicker (1/5~1/12,000sec)
Video RotationFlip, Mirror, Hallway view(90˚/270˚)
AnalyticsDefocus detection, Directional detection, Motion detection, Enter/Exit, Tampering, Virtual line
Alarm I/OInput 1ea / Output 1ea
Alarm TriggersAnalytics, Network disconnect, Alarm input
Alarm EventsFile upload via FTP and e-mail
Notification via e-mail
SD/SDHC/SDXC or NAS recording at event triggers
Alarm output
Audio InBuilt-in mic
Network
EthernetRJ-45(10/100BASE-T)
Video CompressionH.265/H.264: Main/High, MJPEG
Resolution1920x1080, 1280x960, 1280x720, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360
Max. FramerateH.265/H.264: Max. 30fps/25fps(60Hz/50Hz)
MJPEG: Max. 15fps/12fps(60Hz/50Hz)
Smart CodecWiseStreamⅡ
Bitrate ControlH.264/H.265: CBR or VBR
MJPEG: VBR
StreamingUnicast(6 users) / Multicast
Multiple streaming(Up to 3 profiles)
Audio CompressionG.711 u-law /G.726 Selectable
G.726(ADPCM) 8KHz, G.711 8KHz
G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps
ProtocolIPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP
SecurityHTTPS(SSL) Login Authentication
Digest Login Authentication
IP Address Filtering
User access log
802.1X Authentication(EAP-TLS, EAP-LEAP)
Edge StorageMicro SD/SDHC/SDXC 1slot 128GB
Application Programming InterfaceONVIF Profile S/G/T
SUNAPI(HTTP API)
Wisenet open platform
Web ViewerSupported OS: Windows 7, 8.1, 10, Mac OS X 10.12, 10.13, 10.14
Recommended Browser: Google Chrome
Supported Browser: MS Explore11, MS Edge, Mozilla Firefox(Window 64bit only), Apple Safari(Mac OS X only)
Memory512MB RAM, 256MB Flash
Environmental
Operating Temperature / Humidity-10°C ~ +55°C(-14°F ~ +131°F) / Less than 90% RH
Storage Temperature / Humidity-30°C ~ +60°C(-22°F ~ +140°F) / Less than 90% RH
Electrical
Input VoltagePoE(IEEE802.3af, Class3), 12VDC
Power ConsumptionPoE: Max 7.40W, typical 6.00W
12VDC: Max 6.40W, typical 5.10W
Mechanical
Color / MaterialWhite / Plastic
RAL CodeRAL9003
Product dimensions / weightØ110.0x86.0mm(Ø4.33x3.39"), 255g(0.56 lb)
DORI
Detect (25PPM/ 8PPF)40.0m(131.36ft)
Observe (63PPM/ 19PPF)16.0m(52.54ft)
Recognize (125PPM/ 38PPF)8.0m(26.27ft)
Identify (250PPM/ 76PPF)4.0m(13.14ft)
View AllClose

Additional Information

Built-in Microphone:
Built-in Microphone
Camera Style:
Dome
Color:
White
Compression:
H.265
Environmental:
Indoor
Key Features:
Night Vision (IR) Motion Detection ONVIF
Lens Size:
4mm
Lens Type:
Fixed Lens
NDAA Compliant:
Resolution:
2MP
SD Card Support:
Sensor Size:
1/2.8"
Sensor Type:
CMOS
Technology:
Network (IP)
Warranty:
3-year Manufacturer Warranty
Wide Dynamic Range (WDR):
True WDR (120dB)
View AllClose
