Samsung Hanwha SCO-6085R 2MP IR Outdoor Bullet HD CCTV Security Camera
WiseNet HD+ IR Bullet cameras allow users to upgrade their surveillance systems to HD using legacy coax cabling without the costly process of ripping and replacing coax with Ethernet cabling. The new WiseNet HD+ cameras offer a variety of high-performance features including Day/Night operation, motion detection, defog, IR illuminators and more depending on model. Setup functions are easily controlled by OSD with the built-in joystick or control over coaxial cable with WiseNet HD+ DVRs. Low power consumption, compact form factors, and transmission up to 1,640 feet further enhance the lineup.
Key Features:
- Full HD(1920 x 1080) resolution
- 0.11Lux@F1.6, 0Lux(B/W IR LED on)
- 3.2~10mm(3.1x) varifocal lens
- Day & Night (ICR),
- DWDR< Motion detection
- IR viewable length 30m,
- Weatherproof IP66,
- Vandal Proof IK10
- Transmission distance max. 500m
- Easy installation (Plug & play)
Downloads
Specifications
| Video | |
|---|---|
| Imaging Device | 1/2.8" 2M CMOS |
| Effective Pixels | 1945(H)x1097(V) |
| Min. Illumination | Color: 0.11Lux (F1.6, 1/30sec) BW: 0Lux(IR LED on) |
| Video Out | BNC(AHD / CVBS Selectable) |
| Lens | |
| Focal Length (Zoom Ratio) | 3.2~10mm(3.1x) manual varifocal |
| Max. Aperture Ratio | F1.6 |
| Angular Field of View | H: 110.2°(Wide)~32.0°(Tele) / V: 55.4°(Wide)~18.0°(Tele) / D: 128.4°(Wide)~36.6°(Tele) |
| Min. Object Distance | 0.5m(1.64ft) |
| Focus Control | Manual |
| Lens Type | DC auto iris |
| Operational | |
| IR Viewable Length | 30m(98.42ft) |
| Camera Title | Displayed 15 characters |
| Day & Night | Auto(ICR) |
| Backlight Compensation | BLC, HLC, DWDR |
| Digital Noise Reduction | SSNRⅣ |
| Defog | Support |
| Motion Detection | 4ea |
| Privacy Masking | 8ea |
| Gain Control | Low / Middle / High / Very high |
| White Balance | ATW / AWC / Manual / Indoor / Outdoor |
| Electronic Shutter Speed | 1~1/12,000sec |
| Video Rotation | H-Rev/V-Rev |
| Analytics | Motion detection |
| Alarm I/O | Output 1ea |
| Alarm Triggers | Analytics |
| Alarm Events | Alarm output |
| Coaxial Protocol | ACP(AHD Coax Protocol), CVBS: Pelco-C(Coaxitron) |
| Video Transmission Distance | 500m(5C2V Coaxial Cable) |
| Environmental | |
| Operating Temperature / Humidity | -30°C ~ +55°C (-22°F ~ +131°F) / Less than 90% RH |
| Certification | IP66, IK10 |
| Electrical | |
| Input Voltage | 24VAC, 12VDC |
| Power Consumption | 24VAC: Max 5.4W, typical 3.4W 12VDC: Max 5.4W, typical 3.4W |
| Mechanical | |
| Color / Material | Dark grey / Aluminum |
Compatible products
Camera mounts - enclosures are essential to install security cameras. Each surface will require different type of mount and bracket combination. Please check with our sales team if you need help. You can call us at (866) 441-2288 or email us at sales@a1securitycameras.com with any design questions.
Additional Information
|
Additional Features:
|
Day/Night
|
|
Analytics:
|
Motion Detection
|
|
Camera Style:
|
Bullet
|
|
Color:
|
Dark Gray
|
|
Compliance:
|
NDAA Compliant
|
|
Durability:
|
Vandal Proof
Weatherproof
|
|
Environmental:
|
Outdoor
|
|
Lens Size:
|
3.2~10mm
|
|
Lens Type:
|
Varifocal (Manual Zoom) Lens
|
|
Manufacturer Website:
|
https://hanwhavisionamerica.com/
|
|
Night Vision Type:
|
Night Vision (IR)
|
|
Product Series:
|
Samsung Hanwha WiseNet HD+ Series
|
|
Protection Code:
|
IP66
|
|
Resolution:
|
2MP
|
|
Sensor Size:
|
1/2.8"
|
|
Sensor Type:
|
CMOS
|
|
Technology:
|
HD CCTV
|
|
Warranty:
|
3-year Manufacturer Warranty
|
|
Wide Dynamic Range (WDR):
|
Digital WDR (D-WDR)
|
