Alarm Input:
|
4 Channel
|
|
Alarm Output:
|
2 Channel
|
|
Aperture:
|
F1.6
F4.4
|
|
Audio Capability:
|
Two-way Audio
|
|
Audio Compression:
|
G.711ulaw
G.711
G.726
AAC-LC
|
|
Audio Input:
|
1x 3.5mm
|
|
Audio Output:
|
1x 3.5mm
|
|
Camera Style:
|
PTZ
|
|
Color:
|
Ivory
|
|
Compatible Integration (API):
|
ONVIF Profile S
ONVIF Profile G
SUNAPI
Wisenet open platform
|
|
Compliance:
|
NDAA Compliant
|
|
Compression:
|
H.265
MJPEG
H.264
|
|
Day/Night:
|
Auto
Day (Color)
ICR (True Day/Night)
Night (B/W)
|
|
Digital Zoom:
|
32
|
|
Dimensions:
|
152.0 x 218.0 mm (5.98 x 8.58 in)
|
|
Environmental:
|
Indoor
|
|
Field of View (Horizontal):
|
61.8
2.19
|
|
Image Enhancements:
|
Digital Image Stabilizer (DIS)
|
|
Iris:
|
Auto (DC-iris)
|
|
Languages:
|
English
Spanish
Korean
Italian
Turkish
German
|
|
Lens Size:
|
4.44~142.6mm
|
|
Lens Type:
|
Motorized (Automatic Zoom) Lens
|
|
Manufacturer Website:
|
https://hanwhavisionamerica.com/
|
|
Material:
|
Plastic
Metal
|
|
Max Power Consumption:
|
20 Watts
|
|
Max. Storage Capacity:
|
512 GB
|
|
Minimum Illumination (B/W):
|
0.005 Lux at F1.6
|
|
Minimum Illumination (Color):
|
0.05 Lux at F1.6
|
|
Network Interface:
|
1x RJ-45 10M/100M Base-TX Ethernet
|
|
Noise Reduction:
|
2D DNR
3D DNR
SSNRV
|
|
Operating Humidity:
|
0% to 90% RH
|
|
Operating Temperature:
|
-10 °C to 55 °C (14 °F to 131 °F)
|
|
Optical Zoom:
|
32x Optical Zoom
|
|
Power Supply:
|
24 VAC
PoE+ (IEEE802.3at Class 4)
|
|
Product Series:
|
Samsung Hanwha Wisenet X Series
|
|
Remote Users:
|
Up to 20
|
|
Resolution:
|
2.4MP
|
|
S/N Ratio:
|
50 dB
|
|
SD Card Support:
|
SD Card Supported
|
|
Sensor Size:
|
1/2.8"
|
|
Sensor Type:
|
CMOS
|
|
Serial Interface:
|
1x RS485
|
|
Storage Humidity:
|
0% to 90% RH
|
|
Storage Temperature:
|
-30 °C to 60 °C (-22 °F to 140 °F)
|
|
Technology:
|
Network (IP)
|
|
USB Interface:
|
1x USB 2.0
|
|
Video Output:
|
1x CVBS
|
|
Warranty:
|
3-year Manufacturer Warranty
|
|
Web Browser:
|
Chrome
Edge
Firefox
Safari 10
|
|
Wide Dynamic Range (WDR):
|
WDR 150dB
|
