Description
Samsung Hanwha XNP-6400R 2MP H.265 Outdoor PTZ IP Security Camera with Long-range Night Vision, 40x Optical Zoom
Key Features:
- 2MP resolution
- 40x optical zoom
- IR illumination, 200m (656.17ft), Wise IR
- Increased look-up tilt range
- 360⁰ endless pan
- Triple codec H.265/H.264/MJPEG
- WiseStream II technology
- extreme WDR 150dB
- advanced video analytics and sound classification (I/O box required for audio detection/classification)
- True D/N
- Micro SD/SDHC/SDXC 2x slot 1TB
- DIS (Gyro)
- HPoE (IEEE802.3bt, Class6, Type3, Injector included)
- Weatherproof IP66
- Vandal Proof IK10
- NEMA4X, NEMA-TS 2(2.2.8, 2.2.9)
- Temperature range from -40 F ~ +131 F
Downloads
Datasheet
Samsung-XNP-6400R-Datasheet-A1
Compatible products
Camera mounts - enclosures are essential to install security cameras. Each surface will require different type of mount and bracket combination. Please check with our sales team if you need help. You can call us at (866) 441-2288 or email us at sales@a1securitycameras.com with any design questions.
Additional Information
|
Analytics:
|
Audio Detection
|
|
Aperture:
|
F1.6
F4.95
|
|
Camera Style:
|
PTZ
|
|
Compatible Integration (API):
|
ONVIF Profile S
ONVIF Profile G
ONVIF Profile T
SUNAPI
Wisenet open platform
|
|
Compliance:
|
NDAA Compliant
|
|
Compression:
|
H.265
H.264
MJPEG
|
|
Detect (ft):
|
195
7678
|
|
Digital Zoom:
|
32
|
|
Durability:
|
Vandal Proof
Weatherproof
|
|
Environmental:
|
Outdoor
|
|
Field of View (Horizontal):
|
65.66
1.88
|
|
Identify (ft):
|
19.5
767
|
|
Image Enhancements:
|
Digital Image Stabilizer (DIS)
|
|
Iris:
|
Auto (DC-iris)
|
|
Languages:
|
English
Turkish
Spanish
Italian
German
|
|
Lens Size:
|
4.25~170mm
|
|
Lens Type:
|
Motorized (Automatic Zoom) Lens
|
|
Manufacturer Website:
|
https://hanwhavisionamerica.com/
|
|
Max Power Consumption:
|
40 Watts
|
|
Max. FPS and Resolution:
|
60fps at 1080P
|
|
Max. Storage Capacity:
|
1 TB
|
|
Network Interface:
|
1x RJ-45 10M/100M Base-TX Ethernet
|
|
Night Vision Range (ft):
|
656
|
|
Night Vision Type:
|
Night Vision (IR)
|
|
Noise Reduction:
|
SSNRV
|
|
Observe (ft):
|
78.1
3071
|
|
Optical Zoom:
|
40x Optical Zoom
|
|
Power Supply:
|
Hi-PoE (IEEE802.3bt)
|
|
Product Series:
|
Samsung Hanwha Wisenet X Series
|
|
Protection Code:
|
IP66
IK10
NEMA 4X
NEMA-TS 2
|
|
RAM:
|
4GB
|
|
Recognize (ft):
|
39.1
1535
|
|
Resolution:
|
2MP
|
|
SD Card Support:
|
SD Card Supported
|
|
Sensor Size:
|
1/2.8"
|
|
Sensor Type:
|
CMOS
|
|
Storage Humidity:
|
0% to 95% RH (non-condensing)
|
|
Storage Temperature:
|
-50 °C to 60 °C (-58 °F to 140 °F)
|
|
Technology:
|
Network (IP)
|
|
Warranty:
|
3-year Manufacturer Warranty
|
|
Wide Dynamic Range (WDR):
|
WDR 150dB
|
