Description
Ubiquiti UVC-G6-180-B 16MP Panoramic Outdoor Bullet IP Security Camera with Dual 4mm Lens and Built-In IR
The Ubiquiti UniFi G6 180 is a dual-sensor 16MP IP security camera delivering full panoramic 180° coverage in a single unit. Powered by a Quad-core ARM Cortex-A53 Multi-TOPS AI Engine, it supports real-time face recognition, license plate recognition, and smart detection of people, vehicles, and animals — all processed on-device. The dual 1/1.8" 8MP sensors combine to produce a seamless 7680×2160 resolution image at up to 20 FPS, covering wide-angle scenes without blind spots.
Rated IP66 and IK04, this camera is built for both indoor and outdoor deployment. Built-in IR LEDs provide up to 65 ft (20 m) of night vision, while the IR cut filter ensures accurate color reproduction during the day. With PoE+ power delivery (37–57V DC, max 15W), installation is simplified to a single Ethernet run. A MicroSD expansion slot adds local storage redundancy. The G6 180 integrates seamlessly into the UniFi Protect ecosystem for centralized management. This is the black color variant.
Key Features:
- Dual 1/1.8" 8MP sensors, 16MP total at 180° FOV; eliminates coverage gaps with a single panoramic camera replacing multiple units.
- Multi-TOPS AI Engine with face recognition, LPR, and smart detection; enables intelligent, automated security monitoring.
- IP66 weatherproofing and IK04 impact resistance; reliable performance in demanding indoor and outdoor environments.
- Built-in IR up to 65 ft (20 m) with IR cut filter; delivers clear color imaging by day and effective night surveillance.
- PoE+ powered (max 15W) with MicroSD slot; simplifies installation and adds local edge storage redundancy.
Additional Information
|
Aperture:
|
F1.0
|
|
Camera Style:
|
Panoramic
|
|
Color:
|
Black
|
|
Compliance:
|
NDAA Compliant
|
|
Compression:
|
H.265
H.264
|
|
Dimensions:
|
5.6x3.6x2.5in
|
|
Environmental:
|
Outdoor
|
|
Field of View (Horizontal):
|
180
|
|
Lens Size:
|
4mm
|
|
Lens Type:
|
Fixed Lens
|
|
Max Power Consumption:
|
15 Watts
|
|
Night Vision Range (ft):
|
65
|
|
Power Supply:
|
PoE+ (IEEE 802.3at)
|
|
Protection Code:
|
IP66
IK04
|
|
Resolution:
|
16MP
|
|
SD Card Support:
|
|
|
Sensor Size:
|
1/1.8"
|
|
Sensor Type:
|
Progressive CMOS
|
|
Technology:
|
Network (IP)
|
