Description
Vivotek FD9187-HT-A 5MP Night Vision H.265 Indoor Dome IP Security Camera with Motion Detection Sensor
VIVOTEK FD9187-HT-A is indoor dome network camera offering up to 30 fps @ 5-Megapixel or 60 fps @ full HD sensor with superb image quality at all resolutions or frame rates. Featuring VIVOTEK SNV and WDR Pro technology, FD9187-HT-A is capable of capturing high quality image whether in high contrast or low light environment.
The FD9187-HT-A offers remote focus lens for different user scenario. IR illuminators are equipped with 50 meter effective range for better night visibility. For indoor applications, PIR sensor and microphone are built-in to detect unexpected events.
Employing VIVOTEK's Smart Stream III technology and H.265 codec support, the FD9187-HT-A reduces bandwidth up to 90%* while keeping great image quality. Additionally, VIVOTEK VADP (VIVOTEK Application Development Platform) allows users to add customized application for various application and user scenarios.
The FD9187-HT-A also now includes a new wave of advanced Video Content Analysis (VCA) - Smart VCA, including intrusion detection, loitering detection, line crossing detection, unattended object detection, missing object detection, face detection. These features are the next steps in elevating surveillance cameras from image capturing devices to advanced notification instruments, allowing users to see more in smarter ways.
Key Features:
- 30 fps @ 2560x1920, 60 fps @ 1920x1080
- H.265 Compression Technology
- Smart Stream III to Optimize Bandwidth Efficiency
- SNV (Supreme Night Visibility) for Low Light Conditions
- WDR Pro for Unparalleled Visibility in Extremely Bright and Dark Environments
- Built-in IR Illuminators, Effective up to 50 Meters
- Smart IR II Technology to Avoid Overexposure
- Smart Motion Detection to Reduce False Alarms
- Smart VCA (Intrusion Detection, Loitering Detection, Line Crossing Detection)
- Trend Micro IoT Security
- Built-in PIR Sensor for Human Detection
Downloads
Videos
View AllClose
Compatible products
Additional Information
|
Analytics:
|
Smart Motion Detection
Intrusion Detection
Face Detection
Line Crossing
Object Detection
|
|
Aperture:
|
F1.4
F2.8
|
|
Audio Capability:
|
Two-way Audio
|
|
Audio Compression:
|
G.711
G.726
|
|
Audio Support:
|
Built-in Microphone
|
|
Built-in Features:
|
Built-in PIR Sensor
|
|
Camera Style:
|
Dome
|
|
Color:
|
White
|
|
Compatible Integration (API):
|
ONVIF Profile G
ONVIF Profile S
|
|
Compression:
|
H.265
H.264
MJPEG
|
|
Digital Input:
|
2
|
|
Digital Output:
|
2
|
|
Digital Zoom:
|
48
|
|
Environmental:
|
Indoor
|
|
Field of View (Horizontal):
|
30
100
|
|
IR LED Quantity:
|
4
|
|
Iris:
|
P-iris
|
|
Languages:
|
English
|
|
Lens Size:
|
2.7~13.5mm
|
|
Lens Type:
|
Motorized (Automatic Zoom) Lens
|
|
Max Power Consumption:
|
12 Watts
|
|
Max. FPS and Resolution:
|
60fps at 1080P
|
|
Network Interface:
|
1x RJ-45 10M/100M Base-TX Ethernet
|
|
Night Vision Range (ft):
|
164
|
|
Night Vision Type:
|
Night Vision (IR)
|
|
Power Supply:
|
12 VDC
PoE (IEEE 802.3af)
|
|
Processor (CPU):
|
Multimedia SoC (System-on-Chip)
|
|
Product Series:
|
Vivotek V (Versatlile) Series
|
|
RAM:
|
1GB
|
|
Remote Users:
|
Up to 10
|
|
Resolution:
|
5MP (3K)
|
|
S/N Ratio:
|
57 dB
|
|
SD Card Support:
|
SD Card Supported
|
|
Sensor Size:
|
1/2.7"
|
|
Sensor Type:
|
CMOS
|
|
Shutter Speed:
|
1/5-1/32000s
|
|
Special Technologies:
|
Vivotek Smart Stream III
Vivotek SNV (Supreme Night Visibility)
Trend Micro IoT Security
Vivotek Stratocast
|
|
Technology:
|
Network (IP)
|
|
Warranty:
|
3-year Manufacturer Warranty
|
|
Wide Dynamic Range (WDR):
|
WDR Pro
|
