Description
Vivotek IP9165-HT-v2 2MP Indoor Box IP Security Camera with H.265, 3.9~10mm, SNV II, WDR Pro II, i-CS
VIVOTEK's IP9165-HT-v2 is a professional H.265 box network camera with new generation SoC and embed 2 GB RAM and 8 GB storage offering up to 60 fps 1080p with superior image quality. Equipped with an i-CS (intelligent-CS mount) lens with LSC (Lens Shading Correction) calibration functions to obtain better images than traditional lenses, the camera also enables installers to efficiently adjust zoom/focus remotely via remote focus system.
Employing VIVOTEK's SNV II, WDR Pro II and Smart Stream III technologies, the IP9165-HT-v2 is capable of capturing the highest quality images in both low light and high contrast environments. These features provide impressive reduction of bandwidth and storage while still maintaining excellent image quality when compared to traditional H.264 devices without smart streaming. Such function-rich combinations make the IP9165-HT-v2 suitable for a wide range of video surveillance applications, including government and industrial buildings, airports, railway stations, traffic intersections and university campuses.
Key Features:
- 60 fps @ 1920x1080
- H.265 Compression Technology
- 3.9 ~ 10 mm, Remote Focus, i-CS Lens (Intelligent-CS)
- SNV II (Supreme Night Visibility II) for Low Light Conditions
- WDR Pro II (140dB) to Provide Extreme Visibility in Extremely Bright or Dark Environments
- Smart Stream III to Optimize Bandwidth Efficiency
- EIS (Electronic Image Stabilization) to Control Image Stability
- Video Rotation for Corridor View
- Lens Profile for Camera Quality Optimization
- Trend Micro IoT Security
Downloads
Compatible products
Additional Information
|
Aperture:
|
F1.5
F2.7
|
|
Audio Capability:
|
Two-Way Audio
|
|
Audio Compression:
|
G.711
G.726
|
|
Audio Input:
|
1x Channel
|
|
Audio Output:
|
1x Channel
|
|
Audio Support:
|
External Microphone
|
|
Camera Style:
|
Box
|
|
Certifications:
|
CE
LVD
FCC Class B
VCCI
C-Tick
UL Listed
cUL
BIS
BSMI
|
|
Compatible Integration (API):
|
ONVIF Profile G
ONVIF Profile S
ONVIF Profile T
|
|
Compliance:
|
NDAA Compliant
|
|
Compression:
|
H.265
H.264
MJPEG
|
|
Connection Type:
|
Wired
|
|
Day/Night:
|
ICR (True Day/Night)
|
|
Digital Input:
|
2
|
|
Digital Output:
|
2
|
|
Digital Zoom:
|
48
|
|
Environmental:
|
Indoor
|
|
Field of View (Horizontal):
|
109.7
42.7
|
|
Image Enhancements:
|
Electronic Image Stabilization (EIS)
|
|
Iris:
|
i-CS
Auto (DC-iris)
P-iris
|
|
LED Indicator:
|
Status LED
|
|
Languages:
|
English
|
|
Lens Size:
|
3.9~10mm
|
|
Lens Type:
|
Varifocal (Manual Zoom) Lens
|
|
Max Power Consumption:
|
18 Watts
|
|
Minimum Illumination (B/W):
|
0.005 Lux at F1.5
|
|
Minimum Illumination (Color):
|
0.01 Lux at F1.5
|
|
Network Interface:
|
1x RJ-45 10/100/1000 Base-T
|
|
Noise Reduction:
|
3D DNR
|
|
Power Supply:
|
12 VDC
24 VDC
PoE (IEEE 802.3af)
|
|
Processor (CPU):
|
Multimedia SoC (System-on-Chip)
|
|
Product Series:
|
Vivotek Supreme Series
|
|
RAM:
|
2GB
|
|
Remote Users:
|
Up to 10
|
|
Resolution:
|
2MP
|
|
S/N Ratio:
|
66.2 dB
|
|
SD Card Support:
|
SD Card Supported
|
|
Sensor Size:
|
1/2"
|
|
Sensor Type:
|
CMOS
|
|
Serial Interface:
|
1x RS485
|
|
Shutter Speed:
|
1/5-1/32000s
|
|
Special Technologies:
|
Trend Micro IoT Security
Vivotek Smart Stream III
Vivotek SNV II
|
|
Technology:
|
Network (IP)
|
|
Video Output:
|
1x BNC
|
|
Warranty:
|
3-year Manufacturer Warranty
|
|
Web Browser:
|
Chrome
Internet Explorer
|
|
Wide Dynamic Range (WDR):
|
WDR Pro II 140dB
|
