Vivotek IT9389-HT-B 5MP IR H.265 Outdoor Turret IP Security Camera - Built-in mic

Brand: Vivotek
Part Number: IT9389-HT-B
Write a Review
  • Vivotek IT9389-HT-B 5MP IR H.265 Outdoor Turret IP Security Camera - Built-in mic
  • Vivotek IT9389-HT-B 5MP IR H.265 Outdoor Turret IP Security Camera - Built-in mic
  • Vivotek IT9389-HT-B 5MP IR H.265 Outdoor Turret IP Security Camera - Built-in mic
  • Vivotek IT9389-HT-B 5MP IR H.265 Outdoor Turret IP Security Camera - Built-in mic
  • Vivotek IT9389-HT-B 5MP IR H.265 Outdoor Turret IP Security Camera - Built-in mic
$550.00
$412.50

Help me pick a security camera

OR
Free shipping over $300 Free Shipping
Technical Support Technical Support
  • Compression : H.265,
  • Field of View (Horizontal) : 38°Field of View 80°Field of View
  • Lens Type : Fixed Lens
  • Lens Size : 3.7~7.7mm Lens
  • Color : Black
  • Environmental : Outdoor

Description

Vivotek IT9389-HT-B 5MP IR H.265 Outdoor Turret IP Security Camera - Built-in mic

VIVOTEK’s IT9389-HT is a H.265 outdoor turret network camera equipped with a 5-Megapixel sensor, enabling resolution of 2560x1920 at 30 fps. Featuring VIVOTEK SNV and WDR Pro technology, the IT9389-HT is capable of capturing high-quality imagery in both high contrast and low light environments.

The IT9389-HT offers a remote focus lens for different user scenarios. IR illuminators are equipped with 30-meter effective range for better night visibility. To provide reliable coverage in harsh outdoor environments, the IT9389-HT is encased in IP66 and IK08 housing.

By employing VIVOTEK's Smart Stream III technology and H.265 compression, the IT9389-HT is able to reduce bandwidth up to 90%* while maintaining supreme image quality. Additionally, VIVOTEK VADP (VIVOTEK Application Development Platform) allows users to customize applications for the ever-expanding number of user scenarios in the diversified surveillance market.

VIVOTEK’s IT9389-HT is a H.265 outdoor turret network camera equipped with a 5-Megapixel sensor, enabling resolution of 2560x1920 at 30 fps. Featuring VIVOTEK SNV and WDR Pro technology, the IT9389-HT is capable of capturing high-quality imagery in both high contrast and low light environments.

Key Features:

  • 5MP
  • H.265 Compression Technology
  • 30 fps @ 2560x1920 (WDR Pro on)
  • 3.7 ~ 7.7 mm, Remote Focus
  • 1/2.7" Progressive CMOS
  • Smart Stream III to Optimize Bandwidth Efficiency
  • WDR Pro for Unparalleled Visibility in Extremely Bright and Dark Environments
  • SNV (Supreme Night Visibility) for Low Light Conditions
  • Built-in IR illuminators, effective up to 30 meters
  • Smart Motion Detection to Reduce False Alarms
  • Trend Micro IoT Security
  • Weather-proof IP66-rated and Vandal-proof IK08-rated Housing
  • Built-in Microphone
  • ONVIF
  • Black color

Vivotek Easy Installation and Compact Size

Part Number: 100210300G

Downloads

Datasheet Vivotek IT9389-HT
All Security BrandsClose

Specifications

System Information
Model
IT9389-HT
CPU
Multimedia SoC (System-on-Chip)
Flash
128MB
RAM
512MB
Camera Features
Image Sensor
1/2.7" Progressive CMOS
Max. Resolution
2560x1920 (5MP)
Lens Type
Motorized, Vari-focal, Remote Focus
Focal Length
f = 3.7 ~ 7.7 mm
Aperture
F1.9 ~ F2.9
Auto-iris
Fixed-iris
Field of View
38° ~ 80° (Horizontal)
29° ~ 60° (Vertical)
48° ~ 101° (Diagonal)
Shutter Time
1/5 sec. to 1/32,000 sec.
WDR Technology
WDR Pro
Day/Night
Yes
Removable IR-cut Filter
Yes
Minimum Illumination
0.09 Lux @ F1.9 (Color)
0.01 Lux @ F1.9 (B/W)
0 Lux with IR illumination on
Pan Range
359°
Tilt Range
75°
Rotation Range
180°
Pan/Tilt/Zoom Functionalities
ePTZ: 48x digital zoom (4x on IE plug-in, 12x built-in)
IR Illuminators
Built-in IR illuminators, effective up to 30 meters with Smart IR, IR LED*2
On-board Storage
Slot type: MicroSD/SDHC/SDXC card slot
Seamless Recording
Video
Video Compression
H.265, H.264, MJPEG
Maximum Frame Rate
30 fps @ 2560x1920
60 fps @ 1920x1080
Maximum Streams
3 simultaneous streams
S/N Ratio
52 dB
Dynamic Range
120 dB
Video Streaming
Adjustable resolution, quality and bit rate control, Smart Stream III
Image Settings
Time stamp, text overlay, flip & mirror; Configurable brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight compensation, privacy masks; Scheduled profile settings, HLC, defog, 3DNR, DIS, video rotation
Audio
Audio Capability
One-way Audio
Audio Compression
G.711, G.726
Audio Interface
Built-in microphone
Effective Range
5 meters
Network
Users
Live viewing for up to 10 clients
Protocols
802.1X, ARP, CIFS/SMB, CoS, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, IPv6, NTP, PPPoE, QoS, RTSP/RTP/RTCP, SMTP, SNMP, SSL, TCP/IP, TLS, UDP, UPnP
Interface
10 Base-T/100 Base-TX Ethernet (RJ-45)
*It is highly recommended to use standard CAT5e & CAT6 cables which are compliant with the 3P/ETL standard.
ONVIF
Supported, specification available at www.onvif.org
Intelligent Video
Smart Motion Detection
Five-window video motion detection, human detection, time filter
VCA
Standard VCA (optional)
*Including line crossing detection, field detection, loitering detection
VADP Package
Genetec package, Trend Micro IoT Security, Smart Motion Detection, Stratocast(support)
Alarm and Event
Alarm Triggers
Motion detection, manual trigger, periodical trigger, system boot, recording notification, camera tampering detection, audio detection, SD card life expectancy, shock detection, cybersecurity events (brute force attack event, cyberattack event, quarantine event)
Alarm Events
Event notification via email, HTTP, FTP, NAS server, SD card, push notification
File upload via email, HTTP, FTP, NAS server, SD card
General
Connectors
RJ-45 cable connector for Network 10/100 Mbps PoE connection*1
LED Indicator
System power and status indicator
Power Input
IEEE 802.3af PoE Class 0
Power Consumption
Max. 9 W (IR on)
Max. 8 W (IR off)
Dimensions
Ø 122 x 99 mm (w/ mounting bracket)
Ø 108 x 79 mm (w/o mounting bracket)
Weight
392 g (w/ mounting bracket)
332 g (w/o mounting bracket)
Casing
IP66, IK08
Safety Certifications
CE, FCC Class A, UL, LVD, VCCI, C-Tick
Operating Temperature
Starting Temperature: -10°C ~ 50°C (14°F ~ 122°F)
Working Temperature: -20°C ~ 50°C (-4°F ~ 122°F)
Humidity
90%
Warranty
36 months
System Requirements
Operating System
Microsoft Windows 8/7
Mac 10.12 (Chrome only)
Web Browser
Chrome 58.0 or above
Internet Explorer 10/11
Other Players
VLC: 1.1.11 or above
QuickTime: 7 or above
Included Accessories
Others
Quick installation guide, alignment sticker, screw pack, mounting bracket
All Security BrandsClose

Additional Information

Audio Support:
Built-in Microphone
Camera Style:
Turret
Color:
Black
Compression:
H.265
Environmental:
Outdoor
Field of View (Horizontal):
38 80
Key Features:
Night Vision (IR)
Lens Size:
3.7~7.7mm
Lens Type:
Fixed Lens
Night Vision Range (ft):
98
Resolution:
5MP
Technology:
Network (IP)
