Description
Vivotek TB9331-E(35mm) IR H.265 Outdoor Thermal Bullet IP Security Camera
VIVOTEK’s TB9331-E is an H.265 outdoor thermal bullet network camera designed to detect people and vehicles in wild weather, difficult lighting conditions, and any situation that create poor visibility. With heat based thermal imagery and lens options of 8.8/19/35/50mm,, the TB9331-E supports long distance monitoring of vehicles up to 4,500m away even in complete darkness or under challenging climate conditions such as fog, rain, smoke and dust.
The TB9331-E offers 720x480 resolution with an uncooled thermal sensor and VIVOTEK’s VCA (Video Content Analysis) to enhance perimeter protection and boarder security. This camera is also embedded with Trend Micro IoT Security software to provide users with higher levels of network protection. With an IP66, IK10 and NEMA 4X-rated rugged design, the TB9331-E will withstand shock &vibration, humidity, dust, and even extreme temperature fluctuations to maintain stable and reliable video no matter how harsh the environment.
Key Features:
- 35mm Fixed Thermal Lens
- Uncooled VOx Infrared Detector
- 720x480 Resolution
- NETD < 50 mk @ F1.0
- H.265 Compression Technology
- Trend Micro IoT Security
- Two-way Audio
- Supports ONVIF Standard to Simplify Integration and Enhance Interoperability
- UL Certification
- Weather-proof IP66/IP67, Vandal-proof IK10 and NEMA 4X-rated Housing
- VIVOTEK VCA (Video Content Analysis) Support
Downloads
Datasheet
Vivotek-TB9331-E(35mm)-Datasheet-A1
Specifications
Technical Specifications
System Information
- Model
- TB9331-E(8.8mm)
TB9331-E(19mm)
TB9331-E(35mm)
TB9331-E(50mm)
- CPU
- Multimedia SoC (System-on-Chip)
- Flash
- 128MB
- RAM
- 512MB
Camera Features
- Image Sensor
- Uncooled VOx infrared detector
- Max. Resolution
- Effective pixels: 720x480
Image scale up to: 960x640
- Pixel Size
- 17 µm
- Spectral Range
- 8 ~ 14 µm
- Sensitivity
- NETD < 50 mk
- Lens Type
- Fixed-focal (Thermal Lens)
- Focal Length
- TB9331-E(8.8mm): f = 8.8 mm
TB9331-E(19mm): f = 19 mm
TB9331-E(35mm): f = 35 mm
TB9331-E(50mm): f = 50 mm
- Aperture
- F1.0
- Auto-iris
- Fixed-iris
- Field of View
- TB9331-E(8.8mm):
69.6° (Horizontal)
49.7° (Vertical)
79.8° (Diagonal)
TB9331-E(19mm):
35.7° (Horizontal)
24.2° (Vertical)
42.3° (Diagonal)
TB9331-E(35mm):
19.8° (Horizontal)
13.3° (Vertical)
23.7° (Diagonal)
TB9331-E(50mm):
14° (Horizontal)
9.3° (Vertical)
16.7° (Diagonal)
- Pan/Tilt/Zoom Functionalities
- ePTZ: 20x digital zoom (4x on IE plug-in, 5x built-in)
- On-board Storage
- Slot type: MicroSD/SDHC/SDXC card slot
Seamless Recording
Video
- Video Compression
- H.265, H.264, MJPEG
- Maximum Frame Rate
- 30 fps @ 720x480
- Maximum Streams
- 4 simultaneous streams
- Video Streaming
- Adjustable resolution, quality and bit rate control, Smart Stream II
- Image Settings
- Timestamp, text overlay, flip & mirror, configurable brightness, contrast, sharpness
Audio
- Audio Capability
- Two-way Audio (full duplex)
- Audio Compression
- G.726, G.711
- Audio Interface
- External microphone input
External line output
Network
- Users
- Live viewing for up to 10 clients
- Protocols
- 802.1X, ARP, CIFS/SMB, CoS, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, IPv6, NTP, PPPoE, QoS, RTSP/RTP/RTCP, SMTP, SNMP, SSL, TCP/IP, TLS, UDP, UPnP
- Interface
- 10 Base-T/100 Base-TX Ethernet (RJ-45)
*It is highly recommended to use standard CAT5e & CAT6 cables which are compliant with the 3P/ETL standard.
- ONVIF
- Supported, specification available at www.onvif.org
Solution Integration
- Video Motion Detection
- Five-window video motion detection
- VCA
- Line crossing detection, field detection, loitering detection
- VADP Package
- Trend Micro IoT Security, Stratocast
Alarm and Event
- Alarm Triggers
- Motion detection, manual trigger, digital input, periodical trigger, system boot, recording notification, camera tampering detection, audio detection, SD card life expectancy, cybersecurity events (block brute force attack, block cyberattack, quarantine event)
- Alarm Events
- Event notification via digital output, email, HTTP, FTP, NAS server, SD card, push notification
File upload via email, HTTP, FTP, NAS server, SD card
General
- Connectors
- RJ-45 cable connector for 10/100Mpbs Network/PoE connection
Audio input
Audio output
DC 12V power input
AC 24V power input
Digital input*1
Digital output*1
BNC
RS485
- LED Indicator
- System power and status indicator
- Power Input
- DC12V
AC24V (Redundant Power)
IEEE 802.3at PoE Class 4
- Power Consumption
- PoE: Max. 14 W
DC 12V: Max. 11 W
AC 24V: Max. 12.4 W
- Dimensions
- TB9331-E(8.8mm): 121 x 121 x 471.2 mm (with junction box)
TB9331-E(19mm): 121 x 121 x 452.2 mm (with junction box)
TB9331-E(35mm)/(50mm): 121 x 121 x 455.6 mm (with junction box)
- Weight
- TB9331-E(8.8mm)/(35mm)/(50mm): 2,115 g
TB9331-E(19mm): 2,050 g
- Casing
- IP66, IP67, IK10(Metal Housing), NEMA 4X
- Safety Certifications
- CE, LVD, FCC Class A, VCCI, C-Tick, UL, EN50121-4
- Operating Temperature
- Start Temperature: -40°C ~ 60°C (-40°F ~ 140°F)
Working temperature: -50°C ~ 60°C (-58°F ~ 140°F)
- Humidity
- 90%
- Warranty
- 36 months
System Requirements
- Operating System
- Microsoft Windows 8/7
Mac 10.12 (Chrome only)
- Web Browser
- Chrome version 58 or above
Internet Explorer 10/11
- Other Players
- VLC: 1.1.11 or above
QuickTime: 7 or above
Included Accessories
- Others
- Quick installation guide, warranty card, screw pack, alignment sticker, junction box
Compatible products
Camera mounts - enclosures are essential to install security cameras. Each surface will require different type of mount and bracket combination. Please check with our sales team if you need help. You can call us at (866) 441-2288 or email us at sales@a1securitycameras.com with any design questions.
Additional Information
|
Audio Capability:
|
Two-Way Audio
|
|
Camera Style:
|
Bullet
|
|
Compression:
|
H.265
|
|
Durability:
|
Weatherproof
|
|
Environmental:
|
Outdoor
|
|
Lens Size:
|
35mm
|
|
Lens Type:
|
Fixed Lens
|
|
Product Series:
|
Vivotek Supreme Series
|
|
Protection Code:
|
IP67
|
|
Resolution:
|
720 x 480 (D1)
|
|
Specialized Camera Feature:
|
Thermal
|
|
Technology:
|
Network (IP)
|
