AXIS 216FD-V Vandal Proof Network Dome IP Security Camera

Brand:
Part Number: 216FD-V
Write a Review
Discontinued
$577.00

Help me pick a security camera

🖥 Connect Your Axis Camera to YouTube

Free shipping over $300 Free Shipping
Technical Support Technical Support

Description

Axis 216FD-V Vandal Proof IP Network Dome Security Camera series are compact high performance Axis network Dome cameras with superior image quality via Progressive Scan and advanced image processing. Axis 216FD-V Vandal IP Dome offers Dual Streaming of Motion JPEG and MPEG-4 and allows for efficeint IP video surveillance with configuration of frame rate, resolution, compression level and format. Axis 216FD-V Vandal Resistant Network Dome IP security Camera provides up to VGA resolution (640 x 480 pixels) in real-time 30fps.
& Axis 216FD-V IP Network Dome Security camera utlilizes an adjustable camera bracket and 2.8-10mm Varifocal DC Auto Iris Lens to give superior versatility. Axis 216FD-V Vandal Network Dome is easy to install and supports PoE (Power Over Ethernet) and has surface and flush mount capabilities as well as smoked dome options. Axis 216FD-V Network IP Vandal Proof Dome Camera is contructed of a impact resistant Metal base and rugged Polycarbonate Dome making it ideal for a wide range of indoor IP video Surveilance needs especially those exposed to possible vandalism. Whats more IP Remote Video surveillance and Audio surveillance combine in Axis 216FD-V Vandal IP dome to give users full awareness of live and/or recorded video and audio. Axis 216FD-V Network IP Dome Camera features two way Audio with a built-in microphone, optional external mics and speakers and can be disabled when audio is not desired.
& Axis 216FD-V Vandal Proof IP Network Dome security cameras produce and excellent blend of advanced hardware and network functionality. With Built in I/O inputs for alarm signals and relay outputs for connecting devices to trigger lights or open and close doors the possibilities are endless. The Hardware functionality is further backed by high end software abilities from industry standard AXIS VAPIX API support for custom software development and integration, to IPv6 and QoS support to ensure Axis 216FD-V Network Dome Camera will meet the needs of even the most strict requirements, with even more attributes like& multi-level Password protection, IP address filtering and Https encrytion.
& Axis 216FD-V is a high performance Vandal Proof IP Dome security camera loaded with the latest in hardware and software advanced features and is certainly a professional's Choice!

Axis 216FD-W Main Features:

  • Vandal Proof, Impact Resistant
  • Progessive Scan w/30fps VGA Resolution
  • Dual Streaming Motion JPEG and MPEG-4
  • Two Way Audio including built-in Microphone
  • PoE Power Over Ethernet Supported
  • Motion Detection, Audio Detection, Alarm buffering
  • Alarm inputs / Relay Outputs
  • 2.8-10mm Vari-focal DC Auto Iris Lens

Axis 216FD-V Specifications:

  • Image Sensor:1/4” Micron progressive scan RGB CMOS
  • Lens: Fujinon, F1.3 varifocal 2.8-10 mm, DC-iris Focus range: 0.3 m to infinity
  • Angle of view :Horizontal: 20°-73°
  • Camera angle adjustment: Pan 360°, tilt 170°, rotation 340°
  • Minimum illumination: 1 lux, F1.3
  • Video compression
    & - Motion JPEG
    & - MPEG-4 Part 2 (ISO/IEC 14496-2) with motion estimation
  • Profiles: Advanced Simple Profile and Simple Profile
  • Resolutions:
    & - 9 resolutions from 640x480 to 160x120 via API
    & - 6 selections via configuration Web page
  • Frame rate
    & - Up to 30 fps in all resolutions (Motion JPEG or MPEG-4)
  • Video streaming
    & - Simultaneous Motion JPEG and MPEG-4
    & - Controllable frame rate and bandwidth
    & - Constant and variable bit rate (MPEG-4)
  • Image settings
    & - Compression levels: 100
    & - Rotation: 0º, 180º
    & - Configurable color level, brightness, sharpness, contrast, white balance, exposure control
    & - Overlay capabilities: time, date, text, image or privacy mask
  • Shutter time: 1/4 s to 1/15000 s
  • Audio
    & - Configurable for built-in or external microphone
    & - Audio compression
    & - Audio in: AAC LC 8-32 kbit/s, G.711 PCM 64 kbit/s, G.726 ADPCM 32 or 24 kbit/s
    & - Audio out: G.711 PCM 64 kbit/s, G.726 ADPCM 32 or 24 kbit/s Half duplex, simplex or audio off
  • Security
    & - Multiple user access levels with password protection
    & - IP address filtering
    & - HTTPS encryption
    & - Network control IEEE 802.1X
  • Users
    & - 20 simultaneous users
    & - Unlimited number of users using multicast (MPEG-4)
  • Alarm and event management
    & - Events triggered by built-in multi-window motion detection, audio detection, external input or according to a schedule
    & - Image upload over FTP, email and HTTP
    & - Notification over TCP, email, HTTP and external output
    & - Pre- and post alarm buffer of 9 MB (approx 5 min of 320x240 resolution video at 4 frames per sec)
  • Connectors
    & - Ethernet 10BaseT/100BaseTX, RJ-45
    & - Mini DC power jack
    & - Terminal block for 1 alarm input and 1 output
    & - 3.5 mm jack for Mic in (max 80 mVpp) or Line mono input (max 6.4 Vpp)
    & - 3.5 mm jack for Line mono output (max 1.3 Vpp) to active speaker
  • Casing
    & - Impact Resistant Casing w/metal base and rugged polycarbonate transparent cover
  • Processors, memory and clock
    & - CPU, video processing and compression: ARTPEC-A
    & - RAM: 32 MB, Flash: 8 MB
    & - Battery backed-up real-time clock
  • Power
    & - 4.9-5.1 V DC max 3.6 W, or Power over Ethernet (IEEE 802.3af) with power classification:& - Class 1 (max 3.84 W)
  • Operating conditions
    & - 0-50 ºC (32-122 ºF)
    & - Humidity 20-80% RH (non-condensing)
  • Installation, management and maintenance
    & - AXIS Camera Management tool on CD and web-based configuration
    & - Configuration of backup and restore
    & - Firmware upgrades over HTTP or FTP, firmware available at www.axis.com
  • Video access from Web browser
    & - Camera live view
    & - Video recording to file (ASF)
    & - Sequence tour for up to 20 Axis video sources
    & - Customizable HTML pages
  • Minimum Web browsing requirements
    & - Pentium III CPU 500 MHz or higher, or equivalent AMD
    & - 128 MB RAM, AGP graphics card 32 MB RAM, Direct Draw
    & - Windows XP, 2000, DirectX 9.0 or later
    & - Internet Explorer 6.x or later
    & - For other operating systems and browsers see www.axis.com/techsup
  • System integration support
    & - Open API for application integration including AXIS VAPIX API*, AXIS Media Control SDK*, event trigger data in video stream
    & - Quality of Service (QoS) Layer 3, DiffServ Model
    & - Embedded Linux operating system
    & - * Available at www.axis.com
  • Supported protocols
    & - IPv4/v6, HTTP, HTTPS, SSL/TLS*, TCP, ICMP, QoS, RTSP, SNMPv1/v2c/v3 (MIB-II), RTP, UDP
    & - IGMP, RTCP, SMTP, FTP, DHCP, UPnP, ARP, DNS, DynDNS, SOCKS, NTP, etc.
    & - More information on protocol usage available at www.axis.com
    & - * This product includes software developed by the Open SSL Project for use in the Open SSL Tool kit (www.openssl.org)
  • Included accessories
    & - Installation Guide, CD with User’s Manual, software, installation and management tools, mounting and connector kits, power supply 5.1 V DC, MPEG-4 licenses
    & - (1 encoder, 1 decoder), MPEG-4 decoder (Windows)
    & - Video management software (not incl.)
  • Approvals
    & - EN 55022 Class B, EN 61000-3-2, EN 61000-3-3,
    & - EN 55024, FCC Part 15 Subpart B Class B, ICES-003 Class B, VCCI Class B, C-tick AS/NZS CISPR 22, EN 60950-1
    & - Power supply: EN 60950, UL, CSA
  • Dimensions (HxWxD) and weight 94 x 144 x 132 mm (3.7” x 5.7” x 5.2”) Weight: 580g (1.28 lb)
