Bosch MIC-9502-Z30BVF 640x480 Thermal/Optical H.265 PTZ IP Security Camera

Bosch MIC-9502-Z30BVF 640x480 Thermal/Optical H.265 PTZ IP Security Camera

The MIC IP fusion 9000i camera is an advanced PTZ surveillance platform designed to provide early detection in mission-critical applications. With its dual visible/thermal imaging capabilities, the MIC IP fusion 9000i camera is the perfect solution for robust and high-quality imaging needs.

The camera’s distinctive, ruggedized design is wellsuited for extreme environments and adverse weather conditions such as high winds, rain, fog, ice, and snow.

Precision engineered using Bosch’s domain expertise in material and mechanical engineering, the camera offers the most advanced imaging and positioning system solution available on the market.

The MIC IP fusion 9000i camera incorporates a highperformance thermal imaging core and a 1080p starlight camera integrated in the same housing. This allows the camera to deliver simultaneous thermal and visible video streams, maximizing the ability to detect and react to long-range threats.

The thermal imager incorporates the latest un-cooled vanadium oxide microbolometer technology. This high sensitivity thermal imager is equipped with a fixed focal length Athermal lens that balances the field-ofview with maximizing the detection distance. User-adjustable settings for contrast and gain allow operators to optimize the image, ensuring delivery of the highest quality video. In addition, a wide variety of user-selectable thermal color modes are available allowing further optimization of the thermal image. Depending on model mix, QVGA resolution (320 pixels) and VGA resolution (640 pixels) versions are available, with choice of low (<9Hz) or high (30/60Hz) frame rates.

The 1080p60-capable visible imager has starlight technology and a 30x optical/12x digital zoom lens that provides high-quality images, excellent color performance, and unbeatable low-light sensitivity. High dynamic range ensures clear image reproduction in the most challenging high-contrast scenes.

The camera is designed on the most efficient and powerful H.264 and H.265/HEVC encoding platform. The camera is capable of delivering high-quality and high-resolution video with very low network load. With a doubling of encoding efficiency, H.265 is the new compression standard of choice for IP video surveillance systems.

Key Features:

• 640x480 thermal resolution
• 2MP visible resolution
• 50mm Thermal Lens
• 30x Optical Zoom
• Ruggedized IP PTZ camera with high performance thermal imager and HD visible imager sitting side-by-side
• Designed to provide the highest availability of useable images regardless of lighting conditions in extreme environments (weather, dust/debris/smoke, etc.)
• Unique metadata fusion feature provides the ultimate in situation awareness
• Exceptional early detection capabilities: Object detection up to 4517 m (14,820ft) based on DRI criteria
• Advanced on-board intelligent video tracking, object detection even when camera is on tours
• Ingress: The camera is environmentally sealed and complies with Type 6P and IP68 standards, when attached to a MIC-DCA or a MIC-WMB. This level of protection eliminates any risk of dust or water ingress, making the camera a perfect choice for use in extreme environments with rain, dust, snow, flying debris, and other challenging conditions. In addition, the MIC camera’s ingress protection method does not need periodic maintenance, which is required on cameras with pressurized housings.
• Wide operating temperature range: The camera’s operating temperature range of -40 degreeC to +65 degreeC (-40 degreeF to +149 degreeF) enables reliable surveillance monitoring in global locations from cold northern latitudes to hot equatorial and desert regions.
• Rugged construction: The all-metal body has been engineered to withstand IK10-level impacts, and continuous low-frequency vibration. With its symmetrical, cross-section designed surfaces, the camera is also well-suited to operating in sites with high wind conditions.
• Excellent corrosion protection: The camera benefits from Bosch Automotive domain knowledge in material engineering and coatings. As a result, the superior metallurgy, chromate based precoating, and paint finish of the camera provides unprecedented protection against corrosion. Reliability is ensured by the camera’s ability to withstand a 2000-hour salt atmosphere at elevated temperature corrosion resistance test, according to the ASTM B117 test method.
• Window Wiper and Defroster: The camera features a highly durable, silicone wiper which removes moisture from both the glass and germanium windows. In addition, both windows incorporate embedded defrosters that minimize build-up of snow and ice, ensuring the highestpossible image details in extreme cold and moist conditions. The wiper can also be integrated with third-party washer systems for regular cleaning and maintenance activities.
