Digital Watchdog DW-BJRR2X208TS Blackjack Rack 2U 18 Bay Server, Windows Server 2019, 208TB HDD

Part Number: DW-BJRR2X208TS
Write a Review
New Product!
  • Digital Watchdog DW-BJRR2X208TS Blackjack Rack 2U 18 Bay Server, Windows Server 2019, 208TB HDD
  • Digital Watchdog DW-BJRR2X208TS Blackjack Rack 2U 18 Bay Server, Windows Server 2019, 208TB HDD
  • Digital Watchdog DW-BJRR2X208TS Blackjack Rack 2U 18 Bay Server, Windows Server 2019, 208TB HDD
$38,962.00
Free shipping over $300 Free Shipping
Technical Support Technical Support
5 Year Warranty 5 Year Warranty
  • Pre-Installed Storage : 208 TB
  • Video Output : 3x Mini DisplayPort
  • Hard Drive Ports : 18 SAS Ports
  • Max. Storage Capacity : 288 TB Storage Capacity
  • Color : Black
  • Environmental : Indoor

Description

Digital Watchdog DW-BJRR2X208TS Blackjack Rack 2U 18 Bay Server, Windows Server 2019, 208TB HDD

This dual processor Blackjack® Rack™ server is the ultimate solution for recording multiple IP cameras of any resolution at up to 600Mbps throughput. The server is NDAA/TAA compliant, UL listed and includes Windows 10® IoT, Windows Server® 2019, or Linux® Ubuntu® OS on a separate mirrored 240GB SSD. The 2U rack-mountable hardware features dual Intel® Xeon® processors, 32GB memory, up to eight (8) 1GB and 10GB network cards and a dual power supply. The Blackjack Rack server comes preloaded with DW Spectrum® IPVMS and eight recording licenses, up to 288TB of raw internal storage with RAID5 and RAID6 options and removable hotswappable drives. The server comes complete with a 5-year, on-site, Next Business Day**, Keep Your Hard Drive warranty to ensure peace of mind.

Key Features:

  • 5 year warranty, next business day on-site hardware service*, keep your hard drive  - *after remote diagnosis
  • Supports all ONVIF conformant IP cameras
  • Storage options 208-288TB raw internal storage
  • Record and manage single- and multi-sensor IP cameras of any resolution up to 600Mbps throughput
  • Hot Swappable HDDs
  • OS RAID 1, Data RAID5, 6 options
  • Redundant power supply
  • 6x 1GB Base-T Etherner Ports, 2x 10G SFP+ Fiber
  • Windows 10® IoT, Ubuntu® Linux®, Windows Server 2019® OS options on separate SSD
  • Dedicated RAID controller
  • Hosting DW Spectrum® for setup, configuration, monitoring and recording
  • One-time recording license charge, fully transferable between cameras and encoders
  • Two (2) 4-channel licenses included for a total of 8 recording channels (DW-SPECTRUMLSC004).
  • No annual maintenance fees
  • Dual stream recording
  • Rail kit included
  • USB mouse and keyboard included
  • Designed, assembled and tested in the U.S.A.
  • UL Listed
  • NDAA/TAA compliant

Downloads

Quick Start Guide DW-BJRR2XxxT-Quick-Start-Guide

Additional Information

Alternative SKUs:
DW-BJRR2XxxT
Capacity for each disk:
up to 16TB
Certifications:
UL Listed CE FCC
Color:
Black
Compatible Integration (API):
ONVIF
Compliance:
TAA (Trade Agreements Act) NDAA Compliant
Dimensions:
447.04 x 810.26 x 86.61 mm (17.6 x 31.9 x 3.41 in)
Disk Form Factor:
2.5"
Environmental:
Indoor
Fiber Ports:
2x 10 Gbps SFP+ Ports
Hard Drive Ports:
18 SAS Ports
Included Licenses:
8 DW Spectrum IPVMS Recording Licenses
Max. Incoming Bandwidth:
600Mbps
Max. Storage Capacity:
288 TB
Mobile Apps:
iOS Android
Mounting:
Rack Mount
Network Interface:
6x RJ-45 1000 Mbps Port
Operating Humidity:
5% to 85% RH
Operating System:
Windows Server 2019
Operating Temperature:
5 °C to 40 °C (41 °F to 104 °F)
Outgoing Bandwidth:
600 Mbps
Power Supply:
1100W
Pre-Installed Storage:
208 TB
Processor (CPU):
Dual Intel Xeon Silver processor
Product Series:
Digital Watchdog Blackjack Rack Server Series Digital Watchdog DW-BJRR2XxxT Series
RAID:
RAID 1 RAID 5 RAID 6
RAM:
32GB
Rack Unit (U):
2U
Recorder Technology:
Video Server
SSD Capacity:
240GB
Special Recorder Features:
Keep Your Hard Drive Warranty Hotswap HDD Next Business Day Onsite Support Dual Power Redundancy DW Spectrum IPVMS
Video Output:
3x Mini DisplayPort
Warranty:
5-year Manufacturer Warranty
