Description
Digital Watchdog DWC-B6263WTIR650 2.1MP IR Star-Light UHDoC Outdoor Bullet HD CCTV Security Camera
Star-Light Universal HD over COAX cameras deliver crystal-clear images and support real-time 30fps HD-Analog, HD-TVI, HD-CVI at 2.1MP/1080p and CVBS at 960H. The vandal weather resistant bullet cameras are IP66 rated. Star-Light Universal HD over Coax cameras are engineered to work with our VMAX A1 Universal HD over Coax DVRs using your existing Coax infrastructure for a cost-effective, high resolution surveillance solution.
Key Features:
- Universal HD over Coax Technology with HD-Analog, HD-TVI, HD-CVI and all Analog to 960H Signal Support
- STAR-LIGHT Super Low Light Technology
- 2.1MP 1/3" Image Sensor at Real-time 30fps
- 6~50mm Varifocal P-Iris Lens
- True Wide Dynamic Range (WDR)
- OSD Control Via Coaxial (UTC)
- 150' Smart IR™ with Intelligent Camera Sync.
- Smart DNR™ 3D Digital Noise Reduction
- True Day/Night Mechanical IR Cut Filter
- De-Fog™ Extreme Weather Image Compensation
- Highlight Masking Exposure (HME)
- Auto Sensing 24VAC/12VDC with Line Lock
- Easy Icon Driven OSD Menu with Built-in Joystick
- Programmable Privacy Zones
- Auto Gain Control (AGC)
- Backlight Compensation (BLC)
- Dynamic Range Compressor (DRC) Reveals Low Light Detail
- Auto White Balance (AWB)
- RS-485 Built-in
- NDAA/TAA compliant
- IP66 Certified Weather and Tamper Resistant
- 5 Year Warranty
Downloads
User Manual
Digital-Watchdog-DWC-B6263WTIR650-User-Manual-A1
Quick Start Guide
Digital-Watchdog-DWC-B6263WTIR650-Quick-Start-Guide-A1
Videos
View AllClose
Specifications
IMAGE |
|
|
Image sensor
|
2.1MP/1080p 1/3" CMOS
|
|
Active pixels
|
1944 (H) x 1092 (V)
|
|
Scanning system
|
Progressive scan
|
|
Frequency
|
60Hz / 50Hz
|
|
Signal technology
|
Universal HD over Coax® technology with HD-Analog, HD-TVI, HD-CVI and all analog to 960H signal support
|
|
Synchronization
|
Internal
|
|
Resolution
|
1920 x 1080 (1080p)
|
|
Minimum scene illumination
|
0.39 lux (color)
|
|
0 lux (B&W)
|
|
|
S/N ratio
|
55dB
|
|
Video output
|
HD-Analog, HD-TVI, HD-CVI 2.1MP/1080p CVBS Analog up to 960H
|
I/O |
|
|
Alarm output
|
1 alarm output
|
LENS |
|
|
Focal length
|
6 ~ 50mm
|
|
Lens type
|
Varifocal p-iris lens
|
|
Field of view (FoV)
|
45.3° ~ 5.7°
|
|
IR distance
|
150ft range
|
OPERATIONAL |
|
|
Shutter mode
|
Auto, manual, FLC
|
|
Shutter speed
|
1/30-1/30,000
|
|
Backlight
|
On, off
|
|
Star-Light (sense-up)
|
Off, x2 – x32
|
|
Wide dynamic range (WDR)
|
True WDR, off, on
|
|
Wide dynamic range (WDR) dB
|
100dB
|
|
Dynamic range compressor (DRC)
|
Off, low, middle, high
|
|
Smart DNR™ 3D digital noise reduction
|
Off, low, middle, high
|
|
White balance
|
Auto / auto-ex / preset / manual
|
|
Day / night
|
Auto, day (color), night (B/W)
|
|
Mirror / flip
|
Yes
|
|
Auto gain control
|
0~10
|
|
Motion detection
|
Yes
|
|
Privacy zones
|
16 programmable privacy zones
|
|
Sharpness
|
0 ~ 10
|
|
Gamma
|
0.45 ~ 0.75
|
|
De-fog
|
On, off
|
|
RS485 / UTP built-in
|
Pelco D / Pelco C
|
ENVIRONMENTAL |
|
|
Operating temperature
|
-4°F ~ 122°F (-20°C ~ 50°C)
|
|
Operating humidity
|
10–90% RH (non–condensing)
|
|
IP rating
|
IP66 certified weather and tamper resistant
|
|
Other certifications
|
FCC, CE, ROHS
|
ELECTRICAL |
|
|
Power requirement
|
DC12V/AC24V dual voltage
|
|
Power consumption
|
DC12V (LED OFF): 3.0W DC12V (LED ON): 6.0W
|
|
AC24V (LED OFF): 2.7W AC24V (LED ON): 5.5W
|
|
MECHANICAL |
|
|
Material
|
Aluminum bullet housing
|
|
Dimensions
|
9.92" x 3.81" (252 x 96.7 mm)
|
|
Weight
|
2.05 lbs (0.83kg)
|
Compatible products
Camera mounts - enclosures are essential to install security cameras. Each surface will require different type of mount and bracket combination. Please check with our sales team if you need help. You can call us at (866) 441-2288 or email us at sales@a1securitycameras.com with any design questions.
Additional Information
|
Camera Style:
|
Bullet
|
|
Durability:
|
Weatherproof
|
|
Environmental:
|
Outdoor
|
|
Image Enhancements:
|
Auto Gain Control (AGC)
|
|
Lens Size:
|
6~50mm
|
|
Lens Type:
|
Varifocal (Manual Zoom) Lens
|
|
NDAA Compliance:
|
NDAA Compliant
|
|
Product Series:
|
Digital Watchdog Universal HD over COAX Series
Digital Watchdog Star-Light Series
|
|
Protection Code:
|
IP66
|
|
Resolution:
|
2.1MP
|
|
Sensor Size:
|
1/3"
|
|
Technology:
|
HD CCTV
|
|
Warranty:
|
5-year Manufacturer Warranty
|
