IMAGE |
Image sensor | 5MP 1/2.8” CMOS |
Total pixels | 2592 (H) × 1944 (V) |
Minimum scene illumination | 0.08 lux (color) |
0.0 lux (B/W) |
Video output | Local video output CVBS 1.0V p-p (75?), 4:3 aspect ratio |
LENS |
Focal length | 2.7 ~ 13.5mm, F1.4
|
Lens type | Vari-focal p-iris lens with motorized-zoom and auto-focus
|
Field of view (FoV) | 85° ~ 31° |
IR distance | 140ft range |
Optical zoom | x5 optical zoom |
I/O |
Audio in / out | 1/1 |
Audio compression | G.711 |
Alarm in / out | 1/1 |
OPERATIONAL |
Shutter mode | Auto, manual, anti-flicker, slow shutter |
Shutter speed | 1/30 ~ 1/32,000 |
| Slow shutter | 1/2,1/3,1/5,1/6,1/7.5, 1/10 |
Auto gain control | Auto |
Day / night | Auto, day (color), night (B/W) |
Smart DNR™ 3D digital noise reduction | 3D DNR |
Wide dynamic range (WDR) | True WDR (T-WDR) On, Off |
| Wide dynamic range (WDR) dB | 120dB |
| Privacy zones | 16 programmable privacy masks |
| Mirror and flip | Yes |
Alarm notifications | Notifications via e-mail, FTP, alarm output and SD card recording |
Memory slot | Micro SD / SDHC / SDXC (card not included) |
NETWORK |
LAN | RJ45 (10/100Base-T) |
Video compression type | H.265, H.264, MJPEG |
Resolution | H.265: 2592x1944, 2304x1296, 2.1MP/1080p, 720p, VGA, D1, CIF H.264: 2592x1944, 2304x1296, 2.1MP/1080p, 720p, VGA, D1, CIF MJPEG: 2.1MP/1080p, 720p, 800x600, VGA, 768x432, D1, CIF |
Frame rate | Up to 30fps at all resolutions |
Video bitrate | H.264 / H.265 : 32Kbps ~ 14Mbps MJPEG : 1Mbps ~ 40Mbps |
Bitrate control | H.265 dual-stream or simultaneous H.265 / H.264 / MJPEG |
Streaming capability | Dual-stream at different rates and resolutions |
IP | IPv4, IPv6 |
Protocol | TCP/IP, UDP, AutoIP, RTP(UDP/TCP), RTSP, NTP, HTTP, HTTPS, SSL, DNS, DDNS, DHCP, FTP, SMTP, ICMP, SNMPv1/v2/v3(MIB-2), ONVIF |
Security | HTTPS(TLS), IP filtering, 802.1x, digest authentication(ID/PW) |
ONVIF conformance | Yes |
Web viewer | OS: Windows®, Mac® OS, Linux® Browser: Internet Explorer®, Google Chrome®, Mozilla Firefox®, Safari® |
Video management software | DW Spectrum® IPVMS |
ENVIRONMENTAL |
Operating temperature | -40°F ~ 122°F (-40°C ~ 50°C) |
Operating humidity | 10–90% RH (non–condensing) |
IP rating | IP66 certified |
Other certifications | CE, FCC, RoHS |
ELECTRICAL |
Power requirement | DC12V, POE IEEE 802.3af class 3 (adaptor not Included) |
Power consumption | DC12V: max 9W PoE: max 10.5W |
MECHANICAL |
Material | Aluminum bullet housing |
Dimensions | 9.73” x 3.8” (247.2 x 96.7mm) *Dimensions based on the position of the sun shield cover |
Weight | 1.98 lbs (0.9kg) |
| Warranty | 5 year warranty |
