Digital Watchdog DWC-PVX20WATW 4x 5MP Night Vision Outdoor Multi-sensor IP Security Camera with IVA, 2.8~8.0mm Motorized Lens

Brand: Digital Watchdog
Part Number: DWC-PVX20WATW
Write a Review
Replacement: Digital Watchdog DWC-PVX20WATX 4x5MP Multi-sensor Outdoor Dome IP Security Camera with Vari-focal Lenses and Analytics
Check other similar products:
Outdoor Security Cameras
Digital Watchdog Security Cameras
Digital Watchdog IP Security Cameras
5MP (3K) Security Cameras
Ultra Low Light Security Cameras
Digital Watchdog NDAA Compliant
NDAA Compliant Cameras
Multi-sensor Security Cameras
Discontinued
  • Digital Watchdog DWC-PVX20WATW 4x 5MP Night Vision Outdoor Multi-sensor IP Security Camera with IVA, 2.8~8.0mm Motorized Lens - 1
  • Digital Watchdog DWC-PVX20WATW 4x 5MP Night Vision Outdoor Multi-sensor IP Security Camera with IVA, 2.8~8.0mm Motorized Lens - 2
  • Digital Watchdog DWC-PVX20WATW 4x 5MP Night Vision Outdoor Multi-sensor IP Security Camera with IVA, 2.8~8.0mm Motorized Lens - 3
  • Digital Watchdog DWC-PVX20WATW 4x 5MP Night Vision Outdoor Multi-sensor IP Security Camera with IVA, 2.8~8.0mm Motorized Lens - 4
  • Digital Watchdog DWC-PVX20WATW 4x 5MP Night Vision Outdoor Multi-sensor IP Security Camera with IVA, 2.8~8.0mm Motorized Lens - 5
  • Digital Watchdog DWC-PVX20WATW 4x 5MP Night Vision Outdoor Multi-sensor IP Security Camera with IVA, 2.8~8.0mm Motorized Lens - 6
  • Digital Watchdog DWC-PVX20WATW 4x 5MP Night Vision Outdoor Multi-sensor IP Security Camera with IVA, 2.8~8.0mm Motorized Lens - 7
  • Digital Watchdog DWC-PVX20WATW 4x 5MP Night Vision Outdoor Multi-sensor IP Security Camera with IVA, 2.8~8.0mm Motorized Lens - 8
  • Digital Watchdog DWC-PVX20WATW 4x 5MP Night Vision Outdoor Multi-sensor IP Security Camera with IVA, 2.8~8.0mm Motorized Lens - 9
  • Digital Watchdog DWC-PVX20WATW 4x 5MP Night Vision Outdoor Multi-sensor IP Security Camera with IVA, 2.8~8.0mm Motorized Lens - 10
  • Digital Watchdog DWC-PVX20WATW 4x 5MP Night Vision Outdoor Multi-sensor IP Security Camera with IVA, 2.8~8.0mm Motorized Lens - 11
  • Digital Watchdog DWC-PVX20WATW 4x 5MP Night Vision Outdoor Multi-sensor IP Security Camera with IVA, 2.8~8.0mm Motorized Lens - 5 Years Warranty

? Help me pick a security camera

Free shipping over $300 Free Shipping
Technical Support Technical Support
5 Year Warranty 5 Year Warranty
  • Compression : H.265, H.264, MJPEG,
  • Field of View (Horizontal) : 51°Field of View 93°Field of View
  • Max. FPS and Resolution : 30fps at 2592 x 1944
  • Lens Type : Motorized (Automatic Zoom) Lens
  • Lens Size : 2.8~8mm Lens
  • Sensor Type : CMOS
  • Sensor Size : 1/2.8" Sensor
  • Video Output : 1x CVBS
  • Protection Code : IP67 IK10
  • Color : White
  • Material : Aluminum Poly-carbonate (PC)
  • Environmental : Outdoor
  • Aperture : F1.6

Related Products

Digital Watchdog DWC-MV85WIATW 5MP Night Vision Outdoor Dome IP Security Camera with Motorized Lens - 1

Digital Watchdog DWC-MV85WIATW 5MP Night Vision Outdoor Dome IP Security Camera with Motorized Lens

DWC-MV85WIATW
$867.00
$642.40
  • Compression : H.265, H.264, MJPEG,
  • Field of View (Horizontal) : 96°Field of View 31°Field of View
  • Max. FPS and Resolution : 30fps at 2592 x 1944
  • Lens Type : Motorized (Automatic Zoom) Lens
  • Lens Size : 2.7~13.5mm Lens
  • Sensor Type : CMOS
  • Sensor Size : 1/2.8" Sensor
  • Video Output : 1x CVBS
  • Protection Code : IP66 IK10
  • Color : White
  • Material : Aluminum Poly-carbonate (PC)
  • Environmental : Outdoor
  • Aperture : F1.4
Free shipping over $300 Free Shipping
Network (IP) Network (IP)
5MP (3K) 5MP (3K)
100 100 Night Vision
White White
Aluminum Aluminum
Poly-carbonate (PC) Poly-carbonate (PC)
Digital Watchdog DWC-MV75WI28TW 5MP Night Vision H.265 Outdoor Dome IP Security Camera with 2.8mm Fixed Lens - 1

Digital Watchdog DWC-MV75WI28TW 5MP Night Vision H.265 Outdoor Dome IP Security Camera with 2.8mm Fixed Lens

DWC-MV75WI28TW
$618.00
$454.40
  • Compression : H.265, H.264, MJPEG,
  • Field of View (Horizontal) : 102.4°Field of View
  • Lens Type : Fixed Lens
  • Lens Size : 2.8mm Lens
  • Sensor Type : CMOS
  • Sensor Size : 1/2.8" Sensor
  • Protection Code : IP67 IK10
  • Material : Aluminum Poly-carbonate (PC)
  • Environmental : Outdoor
  • Aperture : F2.0
Free shipping over $300 Free Shipping
Network (IP) Network (IP)
5MP (3K) 5MP (3K)
80 80 Night Vision
Aluminum Aluminum
Poly-carbonate (PC) Poly-carbonate (PC)

Description

Digital Watchdog DWC-PVX20WATW 4x 5MP Night Vision Outdoor Multi-sensor IP Security Camera with IVA, 2.8~8.0mm Motorized Lens

Key Features:

  • 20MP (4x 5MP) 1/3" image sensors at real-time 30fps
  • Star-Light Plus™ color in near-total darkness technology
  • Intelligent Video Analytics (IVA pre-loaded models)
  • Extended Intelligent Video Analytics (IVA+ pre-loaded models)
  • Seamless integration and control of IVA rules with DW Spectrum® IPVMS
  • Reduce false alarms
  • Increase your recording storage with logic rules and smart recording
  • 360° and 180° flexible panoramic view IP camera
  • 4x 2.8~8.0mm vari-focal p-iris lens with motorized zoom and auto-focus
  • Four cameras in one installation
  • 3-axis gimbal for wide range lens positioning
  • Flexible sensor positioning on a magnetic base
  • True wide dynamic range (WDR)
  • PoE injector included
  • Triple codecs (H.265, H.264, MJPEG) with simultaneous streaming
  • Two-way audio
  • Smart DNR™ 3D digital noise reduction
  • True day/night with mechanical IR cut filter
  • Auto gain control (AGC)
  • Auto white balance (AWB)
  • Motion detection
  • Micro SD/SDHC/SDXC class 10 card (card not included)
  • Alarm sensor input
  • Relay output
  • Web server built-in
  • ONVIF conformant, profile S
  • PoE class 5 and DC12V
  • NDAA compliant
  • IP67 dust-tight and waterproof to 3 feet
  • 5 year warranty
Replacement of: DWC-PVX16WW DWC-PVX16W2W DWC-PVX16W4W

Downloads

Popular Search

Outdoor Security Cameras
Digital Watchdog Security Cameras
Digital Watchdog IP Security Cameras
5MP (3K) Security Cameras
Ultra Low Light Security Cameras
Digital Watchdog NDAA Compliant
NDAA Compliant Cameras
Multi-sensor Security Cameras

Compatible products

Camera mounts - enclosures are essential to install security cameras. Each surface will require different type of mount and bracket combination. Please check with our sales team if you need help. You can call us at (866) 441-2288 or email us at sales@a1securitycameras.com with any design questions.

Additional Information

Alarm Input:
1 Channel
Alarm Output:
1 Channel
Analytics:
Intelligent Video Analysis (IVA) Motion Detection
Aperture:
F1.6
Audio Capability:
Two-Way Audio
Audio Compression:
G.711
Audio Input:
1x Channel
Audio Output:
1x Channel
Built-in Features:
Built-in Analytics
Camera Style:
Multi-sensor
Certifications:
FCC CE RoHS UL Listed
Color:
White
Compatible Integration (API):
ONVIF
Compliance:
NDAA Compliant
Compression:
H.265 H.264 MJPEG
Connection Type:
Wired
Day/Night:
Day (Color) Night (B/W) Auto ICR (True Day/Night)
Dimensions:
210 x 91.8 mm (8.26 x 3.61 in)
Durability:
Weatherproof Vandal Proof
Environmental:
Outdoor
Field of View (Horizontal):
51 93
Image Enhancements:
Ultra Low Light Auto Gain Control (AGC)
Lens Size:
2.8~8mm
Lens Type:
Motorized (Automatic Zoom) Lens
Material:
Aluminum Poly-carbonate (PC)
Max Power Consumption:
31 Watts
Max. FPS and Resolution:
30fps at 2592 x 1944
Minimum Illumination (B/W):
0.1 Lux
Minimum Illumination (Color):
0.05 Lux
Mounting:
Corner Mount Wall Mount Pole Mount Ceiling Mount In-Ceiling Mount
Network Interface:
1x RJ-45 10/100 Mbps
Night Vision Type:
Night Vision (IR)
Noise Reduction:
Smart DNR 3D DNR
Operating Humidity:
10% to 90% RH (non-condensing)
Operating Temperature:
-20 °C to 50 °C (-4 °F to 122 °F)
Optical Zoom:
2.9x Optical Zoom
Power Supply:
Hi-PoE (IEEE802.3bt) 12 VDC
Product Series:
Digital Watchdog MEGApix FLEX Series
Protection Code:
IP67 IK10
Resolution:
5MP (3K)
S/N Ratio:
50 dB
SD Card Support:
SD Card Supported
Sensor Size:
1/2.8"
Sensor Type:
CMOS
Shutter Speed:
1/15-1/32000s
Special Technologies:
Digital Watchdog Star-Light Plus
Specialized Camera Feature:
Color in Near-Total Darkness Multi-directional
Technology:
Network (IP)
Video Output:
1x CVBS
Warranty:
5-year Manufacturer Warranty
Wide Dynamic Range (WDR):
True WDR 120dB
