Geovision GV-LPR2800-DL 2MP IR H.265 Deep-Learning LPR Outdoor Box IP Security Camera, Starlight, Super Low Lux WDR Pro

Brand: Geovision
Part Number: GV-LPR2800-DL
Write a Review
  • Geovision GV-LPR2800-DL 2MP IR H.265 Deep-Learning LPR Outdoor Box IP Security Camera, Starlight, Super Low Lux WDR Pro
  • Geovision GV-LPR2800-DL 2MP IR H.265 Deep-Learning LPR Outdoor Box IP Security Camera, Starlight, Super Low Lux WDR Pro
  • Geovision GV-LPR2800-DL 2MP IR H.265 Deep-Learning LPR Outdoor Box IP Security Camera, Starlight, Super Low Lux WDR Pro
  • Geovision GV-LPR2800-DL 2MP IR H.265 Deep-Learning LPR Outdoor Box IP Security Camera, Starlight, Super Low Lux WDR Pro
  • Geovision GV-LPR2800-DL 2MP IR H.265 Deep-Learning LPR Outdoor Box IP Security Camera, Starlight, Super Low Lux WDR Pro
$1,600.00

Help me pick a security camera

OR
Free shipping over $300 Free Shipping
Technical Support Technical Support
2 Year Warranty 2 Year Warranty
  • Compression : H.265, H.264, MJPEG,
  • Field of View (Horizontal) : 50.9°Field of View 7.6°Field of View
  • Max. FPS and Resolution : 60fps at 1080P
  • Lens Type : Varifocal (Manual Zoom) Lens
  • Lens Size : 5~50mm Lens
  • Sensor Type : CMOS
  • Sensor Size : 1/2.8" Sensor
  • Dimensions : 360 x 157 x 137.5 mm (14.17 x 6.18 x 5.41 in)
  • Protection Code : IP68 IK10
  • Color : White
  • Environmental : Outdoor
  • Sensor Size : 1/2.8"
  • Aperture : F1.6

Description

Geovision GV-LPR2800-DL 2MP IR H.265 Deep-Learning LPR Outdoor Box IP Security Camera, Starlight, Super Low Lux WDR Pro

GV-LPR2800-DL is capable of recognizing license plate numbers with its built-in deep learning LPR processor. GV-LPR2800-DL can compare captured license plates either with its on-the-edge standalone database, or the database stored at GV-ASManager, an access control system. When there is a match, GV-LPR2800-DL can grant access for the vehicle by opening a gate or barrier.

GV-LPR2800-DL is a 2 MP color network camera designed for recognition of non-reflective license plates on vehicles traveling at up to 100 km/h (62 mph). With its multiple high-power LEDs and intelligent IR, the camera is able to automatically adjust its shutter speed to the scene and capture clear license plate images for single- or dual-lane scenarios under low-light conditions. It adheres to IP68 and IK10 standards and is able to operate within a temperature range of -40°C (-40°F) to 50°C (122°F).

Key Features:

  • Built-in deep learning LPR processor for license plate recognition
  • Double-lane recognition
  • Min. illumination at 0.04 lux
  • Iris: DC-Iris
  • Focal Length (mm): 5~50mm
  • Horizontal FOV : 50.9°~7.6°
  • Maximum Aperture: F/1.6
  • Triple streams from H.265, H.264 and MJPEG
  • Up to 60 fps at 1920 × 1080
  • Intelligent IR
  • IR distance up to 30 m (100ft)
  • Day and Night function (with removable IR-cut filter)
  • Wide Dynamic Range Pro (WDR Pro)
  • DC 12 V / PoE (IEEE 802.3bt)
  • Ingress protection (IP68)
  • Vandal resistance (IK10 for metal casing)
  • Standalone database
  • Built-in micro SD card slot (SD/SDHC/SDXC/UHS-I, Class 10) for local storage
  • Digital I/O (2 in / 2 out)
  • Built-in heater and fan
  • Recognize vehicles with speeds up to 100 km/h (62 mph)
  • Two-way audio
  • Recognized plate numbers export
  • Defog
  • Motion detection
  • Text Overlay
  • IP address filtering
  • Supports iPhone, iPad, Android & 3GPP
  • 31 languages on Web interface
  • CE, FCC, LVD, RoHS compliant
Packing List:
  • GV-LPR2800-DL Camera
  • Sun Shield Cover
  • Sun Shield Cover Short Screw x 2
  • Screw Anchor x 4
  • 1/4"-10 Screw (32 mm) x 4
  • M4 Screw (5 mm) x 2
  • Washer x 4
  • Hex Wrench
  • Silica Gel Bag
  • Adhesive Tape for Silica Gel Bag
  • micro SD card (already inserted and formatted)
  • Installation Guide
  • Download Guide
  • Warranty Card
All Security BrandsClose

Compatible products

Camera mounts - enclosures are essential to install security cameras. Each surface will require different type of mount and bracket combination. Please check with our sales team if you need help. You can call us at (866) 441-2288 or email us at sales@a1securitycameras.com with any design questions.

Additional Information

Aperture:
F1.6
Audio Capability:
Two-way Audio
Audio Compression:
G.711
Audio Input:
1x 3.5mm
Audio Output:
1x 3.5mm
Blower (Fan):
Camera Style:
Bullet
Captures license plates up to (mph):
62
Certifications:
CE FCC LVD RoHS
Color:
White
Compression:
H.265 H.264 MJPEG
Day/Night:
ICR (True Day/Night)
Digital Input:
2
Digital Output:
2
Dimensions:
360 x 157 x 137.5 mm (14.17 x 6.18 x 5.41 in)
Durability:
Vandal Proof Weatherproof
Environmental:
Outdoor
Field of View (Horizontal):
50.9 7.6
Heater:
IR LED Quantity:
10
Iris:
Auto (DC-iris)
Languages:
English Turkish German French Italian
Lens Size:
5~50mm
Lens Type:
Varifocal (Manual Zoom) Lens
Max. FPS and Resolution:
60fps at 1080P
Minimum Illumination (B/W):
0.04 Lux
Minimum Illumination (Color):
0.05 Lux
Mobile Apps:
Android iOS
Network Interface:
1x RJ-45 10M/100M/1000M self-adaptive Ethernet Interface
Night Vision Range (ft):
100
Operating Temperature:
-40 °C to 50 °C (-40 °F to 122 °F)
Power Consumption:
45 Watts
Power Supply:
12 VDC 5A Hi-PoE (IEEE802.3bt)
Protection Code:
IP68 IK10
Resolution:
2MP
S/N Ratio:
56 dB
SD Card Support:
Sensor Size:
1/2.8"
Sensor Type:
CMOS
Serial Interface:
1x RS485
Specialized Camera Feature:
License Plate Recognition (LPR)
Technology:
Network (IP)
Warranty:
2-year Manufacturer Warranty
Wide Dynamic Range (WDR):
WDR Pro
