Oculur C5DF 5MP EXIR Outdoor Dome HD-TVI Security Camera with 3.6mm Fixed Lens
✅ Help me pick a security camera
- Field of View (Horizontal) : 70.1°Field of View
- Max. FPS and Resolution : 20fps at 2592 x 1944
- Lens Type : Fixed Lens
- Lens Size : 3.6mm Lens
- Sensor Type : CMOS
- Protection Code : IP67 IK10
- Color : White
- Environmental : Outdoor
Related Products

Dahua A52BL62 5MP Night Vision Outdoor Dome HD-CVI Security Camera, ArcticPro, 2.8mm Fixed Lens
Brand: Dahua
- Environmental : Outdoor

Samsung Hanwha SCB-6005 2MP Box HD CCTV Security Camera, No Lens
Brand: Hanwha Techwin (Samsung)
- Max. FPS and Resolution : 30fps at 1080P
- Lens Size : No Lens Lens
- Sensor Type : CMOS
- Sensor Size : 1/2.8" Sensor
- Environmental : Indoor
- Sensor Size : 1/2.8"

Samsung Hanwha 4MP Outdoor Bullet HD CCTV Security Camera with Night Vision and 4mm Fixed Lens - HCO-7020RA
Brand: Hanwha Techwin (Samsung)
- Field of View (Horizontal) : 78.2°Field of View
- Max. FPS and Resolution : 30fps at 4MP
- Lens Type : Fixed Lens
- Lens Size : 4mm Lens
- Sensor Type : CMOS
- Sensor Size : 1/3" Sensor
- Protection Code : IP66 IK10
- Color : Dark Gray
- Material : Aluminum
- Environmental : Outdoor
- Sensor Size : 1/3"
- Aperture : F2.0

Speco CVC607CMT2.2 2MP Indoor Corner Mount HD-TVI Security Camera with 2.2mm Fixed Lens
Brand: Speco
- Environmental : Indoor

Samsung Hanwha SCD-6085R 2MP Night Vision Indoor Dome HD CCTV Security Camera with Varifocal Lens
Brand: Hanwha Techwin (Samsung)
- Field of View (Horizontal) : 110.2°Field of View 32°Field of View
- Lens Type : Varifocal (Manual Zoom) Lens
- Lens Size : 3.2~10mm Lens
- Sensor Type : CMOS
- Sensor Size : 1/2.8" Sensor
- Environmental : Indoor
- Sensor Size : 1/2.8"
- Aperture : F1.6
Customers Also Viewed

Oculur ADF-J Junction Box For Mini Dome Cameras
Brand: Oculur
- Color : White
- Material : Aluminum

Oculur C5DV 5MP EXIR Outdoor Dome HD-TVI Security Camera with Motorized Lens
Brand: Oculur
- Max. FPS and Resolution : 20fps at 2592 x 1944
- Lens Type : Motorized (Automatic Zoom) Lens
- Lens Size : 2.8~12mm Lens
- Sensor Type : CMOS
- Color : White
- Environmental : Outdoor

Oculur C2DF 2MP EXIR Outdoor Mini Dome HD-TVI Security Camera
Brand: Oculur
- Max. FPS and Resolution : 30fps at 1080P
- Lens Type : Fixed Lens
- Lens Size : 2.8mm Lens
- Sensor Type : CMOS
- Sensor Size : 1/3" Sensor
- Protection Code : IP66 IK10
- Color : White
- Environmental : Outdoor
- Sensor Size : 1/3"

LTS LTB379 Corner Mount Bracket
Brand: LTS Security
- Material : Aluminum

LTS LTB378 Vertical Pole Mount, Universal, Steel
Brand: LTS Security
- Color : White
- Material : Steel
- Mount Type : Pole Mount

Oculur X4DF5 4MP IR H.265 Outdoor Dome IP Security Camera - 2.8mm Fixed Lens
Brand: Oculur
- Compression : MJPEG, H.264, H.264 Plus, H.265, H.265 Plus,
- Field of View (Horizontal) : 98°Field of View
- Max. FPS and Resolution : 30fps at 2560 x 1440
- Lens Type : Fixed Lens
- Lens Size : 2.8mm Lens
- Sensor Type : CMOS
- Sensor Size : 1/3" Sensor
- Protection Code : IP67 IK10
- Color : White
- Environmental : Outdoor
- Sensor Size : 1/3"

LTS LTB376 Pendant Mounting Bracket
Brand: LTS Security
- Color : White
- Material : Plastic
- Environmental : Indoor

4 Megapixel InfraRed for Night Vision Outdoor Dome Network (IP) Security Camera, H.265 Plus Compression, Weatherproof, SD Card Support, 2.8mm Fixed Lens, CMIP7342W-28M
Brand: LTS Security
- Compression : MJPEG, H.264, H.264 Plus, H.265, H.265 Plus,
- Field of View (Horizontal) : 103°Field of View
- Max. FPS and Resolution : 30fps at 2688 x 1520
- Lens Type : Fixed Lens
- Lens Size : 2.8mm Lens
- Sensor Type : CMOS
- Sensor Size : 1/3" Sensor
- Protection Code : IP67 IK10
- Color : White
- Environmental : Outdoor
- Sensor Size : 1/3"

LTS LTB348 Indoor Wall Mount - ABS Plastic
Brand: LTS Security
- Color : White
- Material : Plastic
- Mount Type : Wall Mount
- Environmental : Indoor

Oculur C5MD 5MP EXIR Outdoor Turret HD-TVI Security Camera with 2.8mm Fixed Lens
Brand: Oculur
- Max. FPS and Resolution : 20fps at 2592 x 1944
- Lens Type : Fixed Lens
- Lens Size : 2.8mm Lens
- Sensor Type : CMOS
- Color : White
- Environmental : Outdoor

LTS LTB349 Angled Ceiling Mount
Brand: LTS Security
- Color : White
- Material : Plastic
- Environmental : Outdoor

LTS LTB342-110 Wall Mount Bracket
Brand: LTS Security
- Material : Aluminum
- Mount Type : Wall Mount

LTS LTB347 Wire Intake Box
Brand: LTS Security
- Color : White
- Material : Aluminum
- Mount Type : Back Box

Oculur C5BF 5MP EXIR Outdoor Bullet HD-TVI Security Camera with 2.8mm Fixed Lens
Brand: Oculur
- Field of View (Horizontal) : 86°Field of View
- Max. FPS and Resolution : 20fps at 2592 x 1944
- Lens Type : Fixed Lens
- Lens Size : 2.8mm Lens
- Color : White
- Environmental : Outdoor

Oculur C5BP 5MP EXIR Outdoor Bullet HD-TVI Security Camera with 3.6mm Fixed Lens
Brand: Oculur
- Max. FPS and Resolution : 20fps at 2592 x 1944
- Lens Type : Fixed Lens
- Lens Size : 3.6mm Lens
- Sensor Type : CMOS
- Color : White
- Environmental : Outdoor

LTS LTB307 Wire Intake with Junction Box Mount
Brand: LTS Security
- Material : Aluminum
- Mount Type : Junction Box

LTS LTB342-140B Wall Mount Bracket with Junction Box
Brand: LTS Security
- Material : Aluminum
- Mount Type : Wall Mount

5 Megapixel InfraRed for Night Vision Outdoor Turret HD-TVI Security Camera, Weatherproof, 2.8mm Fixed Lens, CMHT1752WE-28F
Brand: LTS Security
- Field of View (Horizontal) : 98°Field of View
- Lens Type : Fixed Lens
- Lens Size : 2.8mm Lens
- Protection Code : IP67
- Environmental : Outdoor
Description
Oculur C5DF 5MP EXIR Outdoor Dome HD-TVI Security Camera
Key Features:
- 5MP,
- 2592x1944@20fps
- 3.6mm fixed lens
- True WDR 120dB
- Support coax protocol
- Support OSD menu
- IR up to 66ft
- IP67 Weatherproof
- IK10 Vandal Proof
Downloads
Popular Search
Videos
View AllCloseCompatible products
Additional Information
Alternative SKUs: |
TAC316-OD
|
Camera Style: |
Dome
|
Color: |
White
|
Day/Night: |
ICR (True Day/Night)
|
Durability: |
Weatherproof
Vandal Proof
|
Environmental: |
Outdoor
|
Field of View (Horizontal): |
70.1
|
Key Features: |
Night Vision (IR)
|
Lens Mount: |
M12
|
Lens Size: |
3.6mm
|
Lens Type: |
Fixed Lens
|
Max. FPS and Resolution: |
20fps at 2592 x 1944
|
Minimum Illumination (B/W): |
0 lux with IR illumination on
|
Minimum Illumination (Color): |
0.01 Lux at F1.2 AGC ON
|
NDAA Compliance: |
|
Night Vision Range (ft): |
66
|
Operating Humidity: |
0% to 90% (non-condensing)
|
Operating Temperature: |
-40 °C to 60 °C (-40 °F to 140 °F)
|
Power Consumption: |
5 Watts
|
Power Supply: |
12 VDC
|
Protection Code: |
IP67
IK10
|
Resolution: |
5MP (3K)
|
S/N Ratio: |
>62 dB
|
Sensor Type: |
CMOS
|
Shutter Speed: |
1/30-1/50000s
|
Technology: |
HD-TVI
|
Warranty: |
3-year Manufacturer Warranty
|
Wide Dynamic Range (WDR): |
True WDR 120dB
|
5 Reviews
-
5 Posted by Greg O. on Dec 11th 2017
One thing works in the camera’s favor and one against it. The downside of the camera is that there are cheaper cameras available that can perform the same function. The bright side is the wide angle of coverage. More coverage means less hardware needed to cover a space. The video is good enough for the cost.
-
5 Posted by Brad P. on Nov 13th 2017
I’m not completely sold on the strength of the camera to handle damage. Even though it has a IP67 rating for the price I feel like it may or may not be up to the challenge. Besides that it works pretty decent. Don’t expect much as you get what you paid for.
-
5 Posted by Thomas K. on Nov 9th 2017
Something is missing and that happens to be video quality. The camera captures in 5 MP but if its placed near a source of bright light the video will be dodgy. Another thing to keep in mind is where the camera will be mounted as too high means bad footage and too low leaves it open to damage.
-
5 Posted by Bob D. on Nov 7th 2017
In combination with other oculur products you are looking at a very affordable security system. Oculur offers a wide range of products that jam well with each other. An area of concern for me would be the video encryption. All cameras and recorders have built in security fail safe that prevents the stealing or tampering of feed. I don’t know if the camera shares a high level of security and it makes me slightly uneasy. The network tech does make for easy installation and handling of the camera which is great as it lets lets me record and stream the video separately.
-
5 Posted by Larry S. on Oct 31st 2017
The water resistance I can personally attest to. I had to install a cheap camera in my car wash. As the ceiling is low hanging and we have to pressure hose mud covered cars the camera gets splashed every once in a while. For a cheap camera it does an ok job. There is nothing special about the thing it is very simple and straightforward. I like that it doesn’t rely on glitz and glam to sell itself. The wide range meant that one camera is enough to capture a bay made to fit two pretty large GMCs at the same time.
