Sony SNC-WR632C 2.3MP Outdoor PTZ Dome IP Security Camera

Sony UNI-PMA1 Pole Mount Adaptor - For Pendant Mount Housings, Aluminum, White Powdercoat Finish

Hikvision DS-9632NI-ST 32 Channel Enterprise Network Video Recorder - No HDD Included

Sony SNC-EM631 E-Series Vandal-Resistant Mini Dome PTZ IP Security Camera - Built-in Varifocal Lens

Ubiquiti NSM365 Nanostation Indoor/Outdoor airMAX CPE Wireless Bridge

The Sony SNC-WR632C 1080p HD Outdoor 30x Rapid Dome IP Camera is a surveillance camera that is suited for challenging outdoor environments. The camera is provided with an Exmor CMOS sensor that enables it to produce high resolution images. The Sony’s new Ipela Engine Pro processing platform gives you excellent HD videos.

With the 60fps frame rate, this camera allows you to capture fast moving objects without motion blur. The PTZ feature provides you with extra control of tilt, zoom, and panning the video up to 700 degrees/sec. 30x optical zoom along with integrated Defog technology enhances recordings, give you clear images even in hazy conditions. The on-board Gyroscopic Image Stabilizer keeps images blur free even if the camera is shaken violently. The network camera is also IP66 compliant which keeps it protected against dust and water. With its IK10 rating, the Sony SNC-WR632C 1080p HD Outdoor 30x Rapid Dome IP Camerai is also resistant against acts of vandalism.

Key Features of the Sony SNC-WR632C

Defog Technology: improves images taken in hazy conditions
30x Optical Zoom
60 fps Frame Rate: helps capture fast moving objects
Blue Iris Compatible
Gyroscopic Image Stabilizer: helps in producing blur-free images even when the camera is shaken
IP66 Compliant: protects against dust and water damage
IK10 Rated: resists unwanted tampering and vandalism
1/2.8-type progressive scan Exmor CMOS sensor
True Day/Night, XDNR

Compatible Products:

AXIS T8124-E 1-port 60W Outdoor Midspan
AXIS T8134 60 W Midspan PoE Injector
Sony YT-LDR632S Smoked Dome Cover
UNI-RMB1 Parapet Mount Bracket 2ft
UNI-RMB1 Parapet Mount Bracket 3ft
UNI-WMB3 Low Profile Wall Mount Bracket

Manufacturer:

Sony

Product Type:

Cameras

Warranty:

3-year Manufacturer Warranty

Color:

White

Environmental:

Outdoor

Compression:

H.264
MJPEG

Discontinued:

no

Security Camera Features

Lens Size:

4.3~129mm

Lens Type :

Motorized (Automatic Zoom) Lens

Max. FPS and Resolution:

60fps at 1080P

Resolution:

2.3MP

Sensor Size:

1/2.8"

Sensor Type:

CMOS

Technology:

Network (IP)

Camera Style:

Dome
PTZ

Key Features:

Extreme WDR (130dB)
ONVIF
SD Card Storage Support
True Day/Night
Vandal Proof
Weatherproof

Optical Zoom:

30x Optical Zoom

Vandal Proof:

Yes

SD Card Support:

Yes

Weatherproof:

Yes

Sony SNC-WR632 1080p HD Outdoor 30x Rapid Dome IP Camera Specifications

Image Sensor: 1/2.8-type progressive scan Exmor CMOS sensor
Number of Effective Pixels: Approx. 2.38 Megapixels
Signal System: NTSC/PAL (switchable)
Sync System: Internal synchronization
Minimum Illumination (50 IRE): Color: 1.4 lx (F1.6, View-DR OFF, VE OFF, AGC ON, 1/30 s, 30 fps) B/W: 0.15 lx (F1.6, View-DR OFF, VE OFF, AGC ON, 1/30 s, 30 fps)
Minimum Illumination (30 IRE): Color: 1.0 lx (F1.6, View-DR OFF, VE OFF, AGC ON, 1/30 s, 30 fps) B/W: 0.1 lx (F1.6, View-DR OFF, VE OFF, AGC ON, 1/30 s, 30 fps)
Dynamic Range: Equivalent to 130 dB with View-DR technology
S/N Ratio (Gain 0 dB): More than 50 dB
Gain: Auto/Manual (-3 dB to +28 dB)
Shutter Speed: 1/1 s to 1/10,000 s
Exposure Control: Full auto, Shutter priority, Iris priority, Manual
White Balance: ATW, ATW-PRO, Indoor, Outdoor, Fluorescent lamp, Mercury lamp, Sodium vapour lamp, Metal halide lamp, White LED, One push WB, Manual
Lens: Auto-focus zoom lens
Powered Zoom: Yes
Zoom Ratio: Optical zoom 30x
Digital zoom: 12x
Total zoom: 360x
Powered Focus: Yes
Auto Focus: Yes
Horizontal Viewing Angle: 63.7° to 2.3°
Vertical Viewing Angle: 38.5° to 1.3°
Focal Length: f = 4.3 mm to 129.0 mm
F-Number: F1.6 (Wide) to F4.7 (Tele)
Minimum Object Distance: 300 mm
Pan/Tilt Angle (powered): 360° endless rotation/220°
Pan Speed: 700°/s (max.)*1
Tilt Speed: 700°/s (max.)*1
Number of Preset Positions: 256
Number of Tour Programs: 5
Day/Night: True D/N
e-Flip: Yes
Wide-D: View-DR
Tone Correction: Visibility Enhancer (VE)
Defog Image Processing: Yes
Noise Reduction: XDNR
Image Stabilizer: Yes
Picture Mode: Yes
Privacy Masking (number): 12
Privacy Masking (shape) : Quadrangle formed by any four corner points
Privacy Masking (color/effect): Opaque: 14 colors (Black, White, Red, Green, Blue, Cyan, Yellow, Magenta, Gray (6 scales)), Mosaic
Edge Storage: Yes
Voice Alert: Yes
Vandal Resistant: IK10
Ingress Protection: IP66
Superimpose Number: 3 independent positions for characters (Codec, Date & Time, Event, Text (Max. 64 characters)), 1 independent position for a logo mark
Superimpose Language: English
Menu Language: English, Japanese, Chinese (simplified), Chinese (traditional), French, Spanish, German, Italian, Korean, Portuguese, Russian, Arabic, Hindi, Vietnamese, Thai
Smartphone viewer: Yes
Resolution: 1920 x 1080, 1280 x 720, 1024 x 576, 720 x 576, 720 x 480, 704 x 576, 640 x 480, 640 x 360, 352 x 288, 320 x 184, (H.264, JPEG)
Compression Format: H.264 (High/Main/Baseline Profile), JPEG
Maximum Frame Rate: H.264: 60 fps (1280 x 720), JPEG: 60 fps (1280 x 720)
Bitrate Compression Mode: CBR/VBR (selectable)
Range of Bit Rate Setting: 64 Kbps to 32 Mbps
Adaptive Rate Control: H.264
Bandwidth Control: JPEG
Multi streaming Capability: Triple streaming
Number of Clients: 20
Analytics Architecture: DEPA Advanced
Intelligent Motion Detection: Yes
Face Detection: Yes
Tamper Alarm: Yes
Scene Analytics: Passing, Intrusion, Left Object Detection, Removed Object Detection
Compression Format: G.711/G.726/AAC (16 kHz, 48 kHz)
Operating System: Windows XP (32 bit) Professional Edition, Windows Vista (32 bit) Ultimate, Business Edition, Windows 7 (32/64 bit) Ultimate, Professional Edition, Windows 8 Pro (32/64 bit)
Processor: Intel Corei7 2.8 GHz or higher
Memory: 2 GB or more
Web Browser: Microsoft Internet Explorer Ver. 7.0, Ver. 8.0, Ver. 9.0, Ver. 10.0
Firefox: Ver. 19.02 (plug-in free viewer only)
Safari: Ver. 5.1 (plug-in free viewer only)
Google Chrome: Ver. 25.0 (plug-in free viewer only)
Protocols: IPv4, TCP, UDP, ARP, ICMP, IGMP, HTTP, DHCP, DNS, NTP, RTP/RTCP, RTSP over TCP, SMTP over HTTP, IPv6, HTTPS, SNMP (v1, v2c, v3), SSL *SSM (Source Specific Multicast) is supported."
Number of IP Address/Mac ADDRESS: 1
QoS: DSCP
Multicast Streaming Support: Yes
ONVIF Conformance: Profile S
Authentication: IEEE 802.1X
Analog Video Output: BNC x1, 1.0 Vp-p, 75 Ω, unbalance, sync negative
Microphone Input: Mini jack (monaural), MIC IN/LINE IN: 2.5 V DC plug-in power
Line Input: Mini jack (monaural)
Line Output: Mini jack (monaural), Maximum output level: 1 Vrms
Network Port: 10BASE-T/100BASE-TX (RJ-45)
Alarm Input (Sensor Input): x4, make contact, break contact
Alarm Output: x2, 24 V AC/DC, 1 A (mechanical relay outputs electrically isolated from the camera)
Serial Interface: RS-422/RS-485 (PELCO D protocol)
Card Slots: SD Card x 1
Confirmed SD Card Type: 4/8/16/32 GB SDHC (no support for SDXC)
Power Requirements: HPoE+ system*2, AC 24 V
Power Consumption: 80.0 W max
Operating Temperature : -40°C to +50°C (AC 24V), -5°C to +50°C (HPoE+)*2, -40°F to +122°F (AC 24V), 23°F to 122°F (HPoE+)*2
Cold Start Temperature : -40°C to +50°C (AC 24V), 0°C to +50°C (HPoE+)*2, -40°F to +122°F (AC 24V), 32°F to 122°F (HPoE+)*2
Storage Temperature: -20â„ƒ to +60â„ƒ, -4°F to +140°F
Operating Humidity: 20% to 80%
Storage Humidity: 20% to 95%
Built-in Heater: Yes
Dimensions (W x H x D)*3: φ222.0 x 324.1 mm, φ8 3/4 inches x 12 7/8 inches
Mass: Approx. 4.1kg, 9 lb 0.6 oz
